- Page 1 Dorado Handheld Reader User Manual Dorado Handheld Reader User Manual Version 2.4 Copyright © 2017 – 08 – 31 SSI reserves the right to change specifications without prior notice...
- Page 2 All other products names mentioned herein may be trademarks of their respective companies. Star Systems International Ltd. shall not be liable for technical or editorial errors or omissions contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
-
Page 3: Table Of Contents
Reading Different Memory Banks ....................5 Collecting Data ........................... 6 Reader Configuration ......................... 8 Setting System Time ........................9 Android + iOS Applications Support ..................11 Hardware Products Warranty Statement .................. 12 Appendix ..........................13 Dorado Handheld Reader - Version 2.4... -
Page 4: Reader Overview
Reader Overview Recharge LED Main Screen UP Button LEFT button CENTER button / POWER ON RIGHT button / POWER OFF Down Button Buzzer Antenna Connector Dorado Handheld Reader - Version 2.4... -
Page 5: Basic Operation
Reading tags Press the CENTER button while Dorado is ON. Put an ISOC tag under the antenna area and you should be able to read the tags EPC number. If you want to read other memory banks in the tag, please refer to “Read Different Memory Banks”... -
Page 6: Reading Different Memory Banks
Press the CENTER button to proceed with reading different memory banks in tag. The following are some examples of different memory banks read by Dorado. NOTE: Reading TID and User Memory banks may require more energy than reading the EPC number. -
Page 7: Collecting Data
Collecting Data Connect Dorado to a computer with the provided USB cable. At the startup menu, press the RIGHT button once to enter “mode”. Press DOWN button once and you should see the “U Disk” option highlighted in blue. ... - Page 8 [Date] [Time], [EPC],[TID],[UserData],[SerialNo] Examples: Reading EPC 08/04/14 16:31:12, 3000E2002075690301752800087B,,,DORADO6300021 Reading TID 08/04/14 16:31:20, ,E2003412012EF0000AD803A91A0A016130055FFBFFFFDC60,,DORADO6300021 Reading User Data 08/04/14 16:31:27, ,,0000000000000000000000000000000000000000000000000000000000000000000 0000000000000000000000000000000000000000000000000000000000000,DORADO6300021 Reading EPC+TID 08/04/14 16:31:33, 3000E20020756903017328000873,E20034120132F0000AD803A11A08016530055FFBFFFFDC60 ,,DORADO6300021 Reading All Data 08/04/14 16:31:40, 3000E2002075690301752800087B,E2003412012EF0000AD803A91A0A016230055FFBFFFFDC60 ,0000000000000000000000000000000000000000000000000000000000000000000000000000 0000000000000000000000000000000000000000000000000000,DORADO6300021 Dorado Handheld Reader - Version 2.4...
-
Page 9: Reader Configuration
EPC+TID Display Bank defines the memory bank displayed on the screen of Dorado during a EPC+TID read 0 = EPC, 1 = TID All Data Display Bank defines the memory bank displayed on the screen of Dorado during a All Data read 0 = EPC, 1 = TID, 2 = UserData NOTE: After changing the parameters in SysPar.ini, please save the setting in the file and reboot the... -
Page 10: Setting System Time
Setting System Time In order to change the system time of the Dorado, the following steps will have to be followed closely in sequence. Install virtual port driver Windows (VCPDriver_V1.1_Setup.exe) http://star-int.net/content/SDK/Dorado/VCPDriver_V1.1_Setup.exe Connect the Dorado to a PC via the USB cable At the startup menu, press the RIGHT button once to enter “mode”. - Page 11 Run the SetSYSTime.exe http://star-int.net/content/SDK/Dorado/SetSYSTime.exe Select the com port and press “Set Time”. Now the Dorado system time will be synchronized with the system time of the PC running the above procedures. Disconnect the USB cable immediately after time synchronization. It is critical to carry out this step immediately after time synchronization, because the system time of the Dorado will not run until the USB cable is disconnected.
-
Page 12: Android + Ios Applications Support
Android + iOS Applications Support The Dorado supports connecting with existing popular mobile platforms with enhanced data collection features. For details please download the applications from below: Dorado WiFi Android App: https://play.google.com/store/apps/details?id=com.ssi.dorado Dorado WiFi iOS App: https://itunes.apple.com/us/app/dorado-receiver/id830129900 Dorado Bluetooth (BLE) Android App: https://play.google.com/store/apps/details?id=com.ssi.doradoble... -
Page 13: Hardware Products Warranty Statement
Prior to shipping a product to STAR Systems International for warranty inspection, replacement or repair, an RMA number must be obtained from STAR Systems International’s RMA department at +852 3691 9925 or by email at helpdesk@star-int.net. RMA forms can be downloaded from the STAR Systems International website or the Customer can receive the form by fax (+852 37474065) or email by contacting the RMA department. -
Page 14: Appendix
(in PDF). Visit the Star Systems University at www.star-int.net and click Tech Support > Star Systems University to review technical information or to request technical support for your RFID product. Send Feedback Your feedback is crucial to the continual improvement of our documentation. To provide feedback about this manual, please visit the Contact Us at www.star-int.net. - Page 15 Dorado Handheld Reader User Manual Version 2.4 Copyright © 2017 – 08 – 31 SSI reserves the right to change specifications without prior notice...
