FES PROPELLER MANUAL
Type:
Serial Number:
LZ design d.o.o., ● Brod 3D, 1370 Logatec, Slovenia ● tel +386 59 948 898
info@lzdesign.si
Joint Stock Company "SPORTINĖ AVIACIJA ir Ko"
Pociūnų km., Ašmintos sen., LT-59327, Prienai, Republic of Lithuania
tel:+370 319 60567 ● fax:+370 319 60568 ● e-mail:
Version 2.0
FES-LAK-P11-100
______________
●
www.front-electric-sustainer.com
UAB "SPORTINĖ AVIACIJA ir KO"
Chief designer
_____________ / K. Juočas /
2019-11-26
info@lak.lt
●
www.lak.lt
Advertisement
Table of Contents
Related Manuals for LZ design FES-LAK-P11-100
Summary of Contents for LZ design FES-LAK-P11-100
- Page 1 Version 2.0 Type: FES-LAK-P11-100 Serial Number: ______________ LZ design d.o.o., ● Brod 3D, 1370 Logatec, Slovenia ● tel +386 59 948 898 info@lzdesign.si ● www.front-electric-sustainer.com Joint Stock Company ”SPORTINĖ AVIACIJA ir Ko” Pociūnų km., Ašmintos sen., LT-59327, Prienai, Republic of Lithuania tel:+370 319 60567 ●...
-
Page 2: Table Of Contents
FES Propeller Manual v2.0 FES-LAK-P11-100 November 2019 Table of Contents 1. Important notices............................3 1.1. Limited Warranty..........................3 2. General...............................5 3. Model designation............................5 4. Construction...............................6 4.1. Certification standards........................6 4.2. Construction Material.........................6 4.3. Surface finish............................6 5. Installation..............................6 6. Inspection..............................7 7. Possible damages and allowables......................8 8. -
Page 3: Important Notices
FES Propeller Manual v2.0 FES-LAK-P11-100 November 2019 1. Important notices Please read this manual thoroughly. It contains important information about your system, having a vital importance to the flight safety. Information in this document is subject to change without notice. The manufacturer reserves the right to change or improve their products and to make changes in the content of this material in Manual of alternative procedures to DOA determinate order. - Page 4 FES Propeller Manual v2.0 FES-LAK-P11-100 November 2019 Warning: People who fly should recognize that various types of risks are involved, and they should take all precautions to minimize them, since they cannot be eliminated entirely. The propeller is a vital component of the aircraft.
-
Page 5: General
FES Propeller Manual v2.0 FES-LAK-P11-100 November 2019 2. General The foldable fixed pitch composite propeller FES-LAK-P11-100 is high quality product. Technical data and limitations of the propeller: Number of propeller blades: Maximum power on a propeller shaft: 30 kW (40.23 HP);... -
Page 6: Construction
4. Construction 4.1. Certification standards Propeller FES-LAK-P11-100 described herein is designed and tested according to CS 22 Subpart J. 4.2. Construction Material Propeller is made of GFC and CFC. It is made in accurate metal molds, which were manufactured using modern CNC technology. -
Page 7: Inspection
FES Propeller Manual v2.0 FES-LAK-P11-100 November 2019 Figure 1. Propeller blades mounting on the holder Tighten the spinner p.4 with special M4 Inox bolts p.3. Removal – refer to 4.1 through 4.6 but in reverse order. In any case, if hard tools are used, the propeller will be damaged. -
Page 8: Possible Damages And Allowables
FES Propeller Manual v2.0 FES-LAK-P11-100 November 2019 make the normal preflight inspection, but especially pay attention to the center part of the propeller, • leading and trailing edges of the blades for cracks and de-laminations and the lacquer surface for condition. -
Page 9: Maintenance And Repair
FES Propeller Manual v2.0 FES-LAK-P11-100 November 2019 8. Maintenance and repair Serious cracks which originate from the inside of the blade, are extending through the lacquer and so are visible from outside. These cracks are radial cracks or tangential Note cracks.
