Telco Sensors PABP Series User Manual

PABP USER MANUAL - PRELIMINARY
Photoelectric Amplifier Bus Programmable Series (PABP)
Multiplexed photoelectric amplifier
Product Data
Electrical Data
Supply voltage
Power consumption
Output: solid state
Alarm output: solid state
Environmental Data
Temperature, operation
Sealing class
Approvals
Applicable Remote Sensors & Sensing Ranges for Manual Gain mode
Remote Sensor Series
100
110
120
Comments: The range is reduced to 30 % in short range mode.
Applicable Remote Sensors & Sensing Ranges for Auto Gain mode
Remote Sensor Series
100
110
120
Illustration
PABP xx M
* Note: Baud rate selector is disabled for this series. Baud rate is set to 19200 bps for optimum functionality.
PABP xx S
Indicators
Power On Green light when power is on
Green light when amplifier is working as master
Master Status Indicator
Green flashing light if amplifier is master and in error state
Orange light when amplifier is slave
Slave Status Indicator
Orange flashing light if amplifier is slave and in error state
Website: www.telcosensors.com
E-Mail: info@telcosensors.com
Made in Denmark
10-30 V dc / 24V ac
Max. 3.6 VA
30 V dc / 100 mA
30 V dc / 100 mA
-10 to +50 °C
IP 40
Sensing Range
12 m
27 m
47 m
Sensing range
Short range Long range
0.4 m – 4 m 1 m – 10 m
0.9 m – 9 m 2.2 m – 22 m
1.6 m – 16 m 3.9 m – 39 m
! This device is not to be used for Personnel Protection in Machine
Guarding Safety applications. This device does not include the self-
checking redundant circuitry necessary to allow its use in personnel
machine guarding stand-alone safety applications.
EN
Green light when signal is sufficient and beam is unbroken
Signal OK / Regulation
Only Auto Gain Mode: Green light when signal beam is un-
Indicator
broken and still room for increasing transmission power.
Green light is flashing during adjustment excess gain.
Output Yellow light when output is activated
Red light for transmitter error (disconnection or shorted)
Yellow light for receiver error (disconnection or shorted)
Yellow and red light flashes for insufficient signal level (for
LT/LR error
instance caused by contamination on sensors)
Only Auto Gain Mode: Yellow and red light flashes if target
excess gain is not obtained and transmission power is maximum
Selectors
Select addresses 1,...,10 to set the amplifier address. Each of
Slave address selector the slaves must have a separate address in sequence starting
from 1.
Connection
Wiring Diagrams
PABP 10 – 1 Channel
Note: All outputs and alarm output are N.O. when the system is not powered.
RJ 45 wiring
Pin on RJ45 MODBUS IDv/Itr
4
5
8 Common
Warning
tel
PABP 20 – 2 Channel
PABP 30 – 3 Channels
EIA/TIA RS 485
D1 B/B' or B +
DO A/A' or A -
C/C'
V 1.27 Part Number: L40-0666220724
Telco A/S reserves the right to make changes without prior notice
Description
Signal
Signal
Ground
March 2019 edition
Page 1 of 5
