Master Lock 8184D Mounting Instructions

Bike u-lock

Download this manual

Master Lock Bike

U-Lock Mounting Instructions

Page 1 Master Lock Bike U-Lock Mounting Instructions...
Page 2 Mounting Instructions Multi-Purpose Fixed Bracket Mounting Instructions • Your standard Master Lock Bike U-Lock should include the following contents: (2) Keys U-Lock (4) screws with 2 bolts (1) wing nut Carrier Bracket Displayed: Model No. 8184D with Carrier Bracket...
Page 3 Mounting Instructions Multi-Purpose Fixed Bracket Mounting Instructions Step 1: Remove carrier bracket from U-Lock Step 2: Remove bracket insert Bracket Insert...
Page 4 Mounting Instructions Multi-Purpose Fixed Bracket Mounting Instructions Step 3: Insert the smaller circumference Step 4: Carrier should resemble picture portion of the carrier bracket into the U- below Lock. Bracket should fit snuggly on U-Lock Bracket Insert...
Page 5 Mounting Instructions Multi-Purpose Fixed Bracket Mounting Instructions Step 5a: Mount carrier bracket to your bike Step 5b: To adjust the carrier bracket frame and utilize the bracket insert for position, remove screw indicated below. different size frames Once screw is removed, adjust to your preference and tighten the screw *Not featured on all brackets Bracket Insert...
Page 6 Mounting Instructions Multi-Purpose Fixed Bracket Mounting Instructions Optional Step 7: An additional screw or wing nut (pictured on slide 2) may be used to provide added security on the upper portion of the carrier bracket tightened wing nut for added security location for optional screw or wing nut...
