Stelpro La Niña Installer's Manual
  1. Manuals
  2. Brands
  3. Stelpro Manuals
  4. Dryer
  5. La Niña
  6. Installer's manual
Stelpro La Niña Installer's Manual

Stelpro La Niña Installer's Manual

Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
WarnInG
Before installing and operating this product, the user and/or installer must read, understand and follow these instructions and keep them handy for future
reference. If these instructions are not followed, the warranty will be considered null and void and the manufacturer deems no further responsibility for this
product.
This product must be installed by a qualified person and connected by a certified electrician, according to the electrical and building codes effective
in your region.
The following instructions must be adhered to in order to avoid personal injuries or property damages, serious injuries and potentially fatal electric shocks.
Protect the heating unit with the appropriate circuit breaker or fuse, in accordance with the nameplate.
Make sure the line voltage (volt) is consistent with that indicated on the unit's nameplate.
This unit must be grounded.
Switch off the power at the circuit breaker/fuse before installing, repairing and cleaning the unit.
Make sure the unit is appropriate for the intended use (if needed, refer to the product catalog or a representative).
Do not install the unit where objects or pieces of furniture could be damaged by heat.
Respect distances and positions indicat ed in the installation section.
If the installer or user modifies the unit, they will be held responsible for any damage resulting from this modification, and the UL certification will be void.
This unit must not come into contact with a water source and must be protected from splashes (e.g. a wet mop). Do not use it if any part has been immersed.
For further information or to consult this guide online, please visit our website at www.stelpro.com
Installer's GUIDe
la nIña
Hand dryer
replacement component list included
This unit
complies with
UL standards
INSLAN0314

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the La Niña and is the answer not in the manual?

Questions and answers

Related Manuals for Stelpro La Niña

Summary of Contents for Stelpro La Niña

  • Page 1 This unit must not come into contact with a water source and must be protected from splashes (e.g. a wet mop). Do not use it if any part has been immersed. For further information or to consult this guide online, please visit our website at www.stelpro.com...

  • Page 2: Installation

    WarnInG When cutting or drilling into a wall, be careful not to damage electrical wiring and other hidden utilities. Because this unit is hot when in use, it may pose risks even in normal operation. Therefore, be careful and responsible when using it. Never block air vents.
  • Page 3 electRical connection 1. Turn off the power before connecting the unit. 2. check if the power supply corresponds to that indicated on the nameplate. connect the dryer to a bypass circuit according to electrical and building codes in your area. 3.
  • Page 4 controls your LA NINA hand dryer is equipped with electronic controls to customize the unit to meet your needs. fouR opeRational modes - descRiption and symbols ultimate – high air speed and full heating power for quick drying comfoRt – Reduced air speed and moderate heating power for a comfortable noise level and heat range economical –...

  • Page 5: Maintenance

    operation in maximal detection mode (standard) The hand dryer will start automatically when hands are placed 4 inches (10cm) below the opening of the air output. The unit will shut off once hands are removed. maximum duRation of opeRation As long as the sensor detects the presence of hands, the unit will function continuously for 60 seconds. After this delay, the user must withdraw his hands and put them back under in order for the unit to start up again.
  • Page 6 infRaRed sensoR Replacement • Disconnect sensor from the electronic board. (fiG.2) • eject sensor from the support by pushing the little tabs located on each side of the sensor. (fiG.3) • Replace sensor and execute the steps in reverse. CONNECTOR IR SENSOR CONNECTOR IR SENSOR...
  • Page 7 element Replacement • Disconnect element from the electronic board. (fiG.9) • Remove upper tunnel. (fiG. 10) • Remove element. (fiG. 11) • Replace element and execute the steps in reverse. ELEMENT ELEMENT ELEMENT L2/N ELEMENT L2/N fiG.9 fiG. 10 fiG. 11 replacement component list ITEM # PART #...

  • Page 8: Limited Warranty

    Stelpro reserves the right to examine or to ask one of its representatives to examine the product itself or any part of it before honoring the warranty. Stelpro reserves the right to replace the entire unit, refund its purchase price or repair a defective part.

Table of Contents
