1.2.3 Operator terminal
[Chapter 1.2. in user manual]
The operator terminal is the interface between the operator and the control unit.
All switching, operating and control actions are carried out via this operator terminal.
fig. 3:
GSC operator terminal
A
System LED's
B
Function keys
C
soft keys
D
CPU operating mode setting
E
digital keybord
F
cursor keys
G
System keys
H
System keys LED's
FOR TWO STAGE CHILLER/ PACKAGES WITH SCREW
_805011_om_gsc_sp2_gbr_1_.doc
OPERATING INSTRUCTIONS
GRASSO SYSTEM CONTROL
COMPRESSORS
11
