User's manual VER-24 wifi
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VER-24 WiFi and is the answer not in the manual?

Questions and answers

Related Manuals for Verano VER-24 WiFi

Summary of Contents for Verano VER-24 WiFi

  • Page 1 User’s manual VER-24 wifi...

  • Page 2: Table Of Contents

    SPIS TREŚCI Safety..................................3 Device description ..............................4 III. How to install the controller ............................5 Principle of operation ..............................7 Main screen description ............................. 7 Controller operation modes ............................8 VII. Controller functions ..............................8 Block diagram - main menu ............................. 9 WiFi module ................................

  • Page 3: Safety

    SAFETY Before using the device for the first time the user should read the following regulations carefully. Not obeying the rules included in this manual may lead to personal injuries or controller damage. The user’s manual should be stored in a safe place for further reference.

  • Page 4: Device Description

    II. DEVICE DESCRIPTION VER-24 WiFi regulator enables convenient control of Verano fan-coil. VER-24 WiFi offers the following functions:  Room temperature control (heating/cooling)  Smooth control of fan speed  Smooth control of the actuator (0-10)  ON/OFF actuator control ...

  • Page 5: How To Install The Controller

    VER-24 WiFi regulator is intended to be installed on the wall. First, attach the back cover to the wall in the place where the room regulator in the electrical box will be installed. Next, connect the power supply wires and mount the device on the latches.
  • Page 6 6. Power supply 24V 7. 0-10V signal controlled fan 8. 0-10V signal controlled actuator 9. NC actuator 10. NO actuator 2. How to connect NO actuator 3. How to connect NC actuator...

  • Page 7: Principle Of Operation

    IV. PRINCIPLE OF OPERATION VER-24 WiFi controls the fan and the valves in order to maintain the pre-set room temperature. Depending on selected operation mode, the device may increase the temperature (heating mode) or decrease the temperature (cooling mode). It controls smoothly the fan operation (increasing or decreasing its speed when needed) and the valve operation (increasing or decreasing the level of valve opening depending on current needs).

  • Page 8: Controller Operation Modes

    - BOOST - the pre-set temperature will be reached in the shortest possible time. When the operation time is over or the pre-set temperature has been reached, the fan will enter automatic operation mode. - OFF NOTE Information about current fan operation mode is saved in the controller memory 6 seconds after the last parameter change.

  • Page 9: Block Diagram - Main Menu

    BLOCK DIAGRAM - MAIN MENU WiFi network selection Disconnect Registration DHCP IP address WiFi module Gate address DNS address MAC address Subnet mask Module version Comfort Profile selection Protection Schedule 1-3 Weekly schedule Comfort temperature Eco min temperature Temperature settings Eco max temperature Protection min temperature Protection max temperature...

  • Page 10: Wifi Module

    WIFI MODULE The controller features a built-in Internet module enabling the user to monitor the status of all system devices on a computer screen, a tablet or a mobile phone. Apart from the possibility to view the temperature of every sensor, the user may adjust the pre-set temperature values. After switching the module on and selecting DHCP option, the controller automatically downloads such parameters as IP address, IP mask, gateway address and DNS address from the local network.
  • Page 11 Figure 2. Chart of fan operation in the profile Comfort  ECO, PROTECTION - PROTECTION profile functions similarly to ECO profile. The only difference is the default pre-set temperature values: PROTECTION min temperature < ECO min temperature PROTECTION max temperature > ECO max temperature PROTECTION profile is intended for maintaining optimum room parameters in order to protect the heating/cooling system against freezing or overheating.

  • Page 12: Temperature Settings

    Figure 4. Chart of fan operation in the profile ECO, PROTECTION  Schedule 1,2,3 profile, weekly schedule - If one of the schedules is activated, the controller functions according to pre-defined program - Schedule settings parameter. Schedules enable the user to select set the temperature for a particular period of time. TEMPERATURE SETTINGS These parameters enable the user to configure pre-set temperatures for particular operation profiles (see: the previous section).

  • Page 13: Controller Settings

    Use arrows UP and DOWN to change the time period (with the accuracy of 15 minutes) and the corresponding pre-set temperature. Selecting the weekly schedule the user may copy the settings into next days. CONTROLLER SETTINGS 6.1. ROOM TEMPERATURE SET TINGS In this submenu the user may calibrate the room temperature sensor.

  • Page 14: Alarm Clock Settings

     Daytime screen brightness/nighttime screen brightness – once this option has been selected, the user may adjust the screen brightness in percent.  Screensaver – this function enables the user to enable and configure the screensaver. 7.3. ALARM CLOCK SETTINGS This function is used to configure the alarm clock.

  • Page 15: Factory Settings

    VIII. ALARMS The VER-24 WiFi room temperature regulator will signal all the alarms which occur in the controller. When an alarm is activated, the room regulator will inform about it with a sound signal and a corresponding message will appear on the display.
  • Page 18 EU Declaration of conformity Hereby, we declare under our sole responsibility that VER-24 WiFi manufactured by TECH, headquartered in Wieprz Biała Droga 31, 34-122 Wieprz, is compliant with: • Directive 2014/35/EU of the European Parliament and of the Council of February 26, 2014 on...
  • Page 20 The manufacturer reserves the right to change the structure or change the determined colors. The illustrations may contain additional equipment. The printing technology may affect differences in shown colors. Current information will be provided by dealers of Verano-konwektor products.
