Summary of Contents for 3nStar BC1005
- Page 2 ERROR CODE & SOLUTIONS Self Detection Problem Reason Solution E-26 Left Counting Sensor Page 1 E-27 Right Counting Sensor Page 1 E-32 Speed Sensor Page 1 E-30 Stacker Sensor Page 2 E-29 Hopper/Fedding Sensor Page 2 Alarm Codes Meaning E-17 UV Detection Page 2 E-18...
- Page 3 1. Please make sure there is no object covering the sensor. 2. Please check if stacker sensor’s plugs (a pair) are all well connected to mainboard? 3. If it is well connected, please change the one by one using normal sensor and check if it can work.
- Page 4 1. Check the alarmed note, the dimension is different. 1. Check the alarmed note, it might have holes. 2. Check the alarmed note, the width might differ (not normal). 1. Check and make sure there is no other thing gets inside the machine and all condition is normal.
- Page 5 Software Version: Turn on the machine, LCD display will show software version: SETTING MENU: Hold press SET 5~6 second to enter the SET program. 1. MG sensitivity adjustment. Increased sensitivity Decreased sensitivity Press SET again, to enter UV sensitivity adjustment. Increased sensitivity Decreased...
- Page 6 3. Press SET again to enter IR sensitivity adjustment. Increased sensitivity Decreased sensitivity 4. Press SET again to enter Size sensitivity adjustment. Increased sensitivity Decreased sensitivity 5. Press SET again to enter Voice ON and OFF (some models might differ). Turn On Turn Off...
- Page 7 6. Press SET again to turn ON or OFF Half note detection (For certain models might be differ). Turn On Turn Off 7. Press SET again to set the alarmed note to be counted or ignored. Turn On (counted) Turn Off (ignored) 8.
- Page 8 9. Press SET again to turn ON or OFF the detection of the following note after an alarmed note. Turn On Turn Off 10. Press SET again to set breaking time (during batch or stop). NOTE: DO NOT NEED TO ADJUST (Please contact factory in advance) Press + and - to set.
