- Page 1 Power Dissipater IT-E500 Series User Manual Model: IT-E502/IT-E503/IT-E504/IT-E505/IT-E506/IT-E507 Version No.: V2.2...
- Page 2 Notices Warranty Safety Notices © Itech Electronic, Co., Ltd. 2018 The materials contained in this No part of this manual may be document are provided “as is”, and reproduced in any form or by any means is subject to change, without prior...
-
Page 3: Warranty
Warranty ITECH warrants that the product will be free from defects in material and workmanship under normal use for a period of one (1) year from the date of delivery (except those described in the Limitation of Warranty below). -
Page 4: Regulatory Markings
With reference to the equipment classifications described in the Annex 1 of the WEEE Directive, this instrument is classified as a “Monitoring and Control Instrument”. To return this unwanted instrument, contact your nearest ITECH office. Copyright© Itech Electronics Co., Ltd. -
Page 5: Compliance Information
Connection of the instrument to a test object may produce radiations beyond the specified limit. Use high-performance shielded interface cable to ensure conformity with the EMC standards listed above. Safety Standard IEC 61010-1:2010/ EN 61010-1:2010 Copyright© Itech Electronics Co., Ltd. -
Page 6: Table Of Contents
................................. 1 ENERAL 1.2 D ................................1 IMENSIONS 1.3 F ......................2 RONT ANEL AND ANEL NTRODUCTION 1.4 C ..........................3 ONNECTION ABLE NTRODUCTION 1.5 C ..........................3 ONNECTING OWER ISSIPATER CHAPTER2 SPECIFICATIONS ..........................6 Copyright© Itech Electronics Co., Ltd. -
Page 7: Chapter1 About It-E500
IT-E500 User Manual Chapter1 About IT-E500 1.1 General IT-E500 Series power dissipater is a simple and speedy electronic load provided by ITECH, which is an optional accessory of the IT6500C Series power supply sold separately. Work with IT6500C series power supplie, IT-E500 series power dissipater can help IT6500C series to realize external load function. -
Page 8: Front Panel And Rear Panel Introduction
IT-E500 User Manual 1.3 Front Panel and Rear Panel Introduction The front panel of IT-E500 power dissipater is as shown below. Handle Power Ventilation Instrument indicator legs hole Copyright© Itech Electronics Co., Ltd. -
Page 9: Connection Cable Introduction
IT-E500 power dissipater has a piece of standard network cable of system control bus, as shown below. IT-E500 Series power dissipater has a piece of standard three-core power line. This power line is connected to the IT6500C rear panel and the AC input terminal of power dissipater. - Page 10 The number of power dissipaters connected to each single machine should be kept consistent. Take IT6532C as an example, parallel 3 sets of power dissipaters. Example diagram is as shown below: Copyright© Itech Electronics Co., Ltd.
- Page 11 Connect the power supply and power dissipater based on the above schematic diagram. Connect the external load’s connection terminal of IT6500C Series power supply to the load input interface of IT-E500 Series power dissipater. Connections of other power dissipaters are as shown in blue lines in the figure.
-
Page 12: Chapter2 Specifications
IT-E500 User Manual Chapter2 Specifications This chapter introduces detailed specifications of IT-E500 series power dissipater. For details, refer to specifications of each model. IT-E502 Specification Parameters IT-E502 Voltage 0.1V-80V Input Rating Current 0.1A-120A Power 0W-3000W Interface System Bus Dimention(WxHxD) 483 mm x 133mm x 504.3mm... - Page 13 System Bus Dimention 483 mm x 133mm x 504.3mm (WxHxD) Weight 25Kg Voltage 100~240V AC Frequency 47~63 Hz AC Input Working <2.5A(110V), <1.25A(220V) current IT-E506 Specification Parameters IT-E506 DC Section Voltage 0.1~750V Input Rating Current 0.1~15A Copyright© Itech Electronics Co., Ltd.
- Page 14 System Bus Dimention 483 mm x 133mm x 504.3mm (WxHxD) Weight 25Kg Voltage 100~240V AC Frequency 47~63 Hz AC Input Working <2.5A(110V), <1.25A(220V) current The above specifications may be subject to change without prior notice. Copyright© Itech Electronics Co., Ltd.
- Page 15 Please refer to the CD-ROM of related user’s manual in package. 2. Click www.itechate.com or scan the right two-dimension code to visit the ITECH website. 3. Send E-mail to fae@itech.sh or dial the service hot-line in China: 4006025000 4. Select the most convenient contact method for further consultancy.
