- Page 1 DS3002, DS3008 DS8000 networked soundmasking, paging and music processors Privacy Manager software with version 9.00 print date: 05-21-2014 Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275...
-
Page 3: Table Of Contents
Saving Device firmware and System settings Saving and Restoring Device and Total System Configurations Dynsound DS3002 / DS3008 / DS8000 hardware DS3002 and DS3008 Paging and music connections to the DS3002/DS3008 processors DS8000 Block Diagrams and Specifications DSM-16 Contact closure module... - Page 4 CobraNet is the registered trademark of Cirrus Logic. Windows XP, Windows Vista and Windows 7 are registered trademarks of Microsoft. Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275...
-
Page 5: Soundmasking Systems By Dynasound
DS3002 and DS3008 processors incorporate four separate soundmasking generators, each having 1/3 octave band equalization. Balanced audio inputs and outputs and multi-channel matrix mixers make the DS3002 / DS3008 processors an ideal choice for complex centralized masking and paging systems. Addressable systems An addressable soundmasking paging and music system incorporates very little centralized equipment. - Page 6 Main Network System Components Dynasound DS1356 speakers wire directly to DS8000 networked speaker controllers using standard two conductor audio cable. Dynasound’s DS1388 speakers may also be used with network systems. Dynasound DS8000 speaker controllers are PoE, 8 channel network receivers including full DSP and internal soundmasking generators.
- Page 7 Touch screen controller with Privacy Manager Software Cat 5 cable DS1356 speakers DS8000 PoE switch DS3008 Soundmasking, switch Paging and Music Processor DS1356 speakers speakers wired with 18-2 standard speaker cable DS8000 PoE switch Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275...
- Page 8 1 is selected. The Output Manager screen also illustrates the level of control available. Note that individual speakers have access to eight network audio channels and four independent masking generators. Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275...
-
Page 9: Installing Privacy Manager
If Privacy Manager is already installed and configured you can skip this section and proceed to the next page. If not proceed as follows: Insert the USB drive provided with the DS3002/DS3008/DS8000. Open the drive and run the setup program provided. can also download the latest version of Privacy Manager from www.soundmasking.com/support.html. -
Page 10: Speaker Layout And Identification
Privacy Manager Dynasound’s Privacy Manager software is used to control DS3002, DS3008 and DS8000 series soundmasking products. Privacy Manager is Windows based and runs on XP, Vista, Windows7 and Windows 8 operating systems. Home screen The home screen provides Menu Bar... -
Page 11: Home / Monitor Screen
Home screen - device view Device view is available after selecting a specific network device ( DS3002, DS3008 or DS8000) from the list. This screen gives access to the internal soundmasking generators as wel as the input and output processing for each device. -
Page 12: Monitor Screen - Quick Adjustment Utilities
DS8000. After using the “raise” button to select a change of 1.5 dB, click the “submit changes” button to appy the change to the selected speaker. This utility displays the current setting, before and after making the per speaker change. Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275... -
Page 13: System Profiles
Profiles can also be configured to automatically save the start-up firmware if required. Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275... -
Page 14: Inputs
Input manager as it appears when the user selects either input 7 or input 8. These two inputs are linked allowing A and B broadcast soundmasking to be adjusted together. EQ of the broadcast masking is done at the DS3002, DS3008 level. -
Page 15: Soundmasking
DS3008 Outputs The output manager is used to process the signals routed to any given output channel. In the case of a DS3002 or DS3008 the output signals are both line level analog signals and CobraNet digital network audio signals. -
Page 16: Device Properties
Broadcaster for a given bundle. For example you could not have two DS3008s broadcasting on the same bundle number. IP address: A static IP address is normally defined for each network device before leaving Dynasound. Once a system is in place and configured there is normally no need to change an IP address. -
Page 17: Transmit And Receive Settings
“bundles” instead of channels to avoid confusion as each bundle contains 8 audio channels. More than one DS3008 or DS3002 may be used to in- troduce additional transmit bundles into the network al- lowing up to 32 audio channels on a single system. -
Page 18: Control Zones
On the screen to the left the soundmasking levels for network channels 7 and 8 can be adjusted with one control, for all DS8000s in the Control Zone. Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275... - Page 19 Raising or lowering soundmasking levels per zone can be done via the user friendly home screen buttons, eliminating the need for most end users to worry about proper use of control zones. Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275...
-
Page 20: Soundmasking Schedules
The image on the left shows the DS8000 has been set to schedule 1. The Soft Start schedule described below may also be assigned per zone. Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275... -
Page 21: Soft-Start Schedules
Only one schedule is available for assignment to individual DS8000s. DS8000s or Zones may be assigned to both reoccuring soundmasking schedules and one-time Soft Start Schedules at the same time. Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275... -
Page 22: Saving And Restoring Device And Total System Configurations
It is important to understand this feature. Saving a configuration to a PC file does not save the configuration to permanent memory in the DS3002,DS3008 or Ds8000. Your PC connection must remain intact while saving configurations to the devices non-volatile firmware memory. - Page 23 In order to save all network device configurations to a disk file, ALL devices must be in the device list. Be sure to select “All Zones” and “refresh” before saving system files. Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275...
-
Page 24: Ds3002 And Ds3008
12x8 matrix mixer allowing any combination of audio channels to be routed to any of 8 balanced outputs The Dynasound DS3002 is a similar device incorporating four soundmasking generators, two balanced audio inputs, two balanced audio outputs and a 6x8 matrix mixer. -
Page 25: Ds8000
The DS8000 is shipped with hardware for either independent mounting or for attachment to speaker suspension wires. For independent mounting the eyebolt can be used to suspend the speaker in the same manner as the Dynasound DS1356 speaker. For attachment to speaker hanging wires, the supplied “grid-wire” clip can be used. -
Page 26: Block Diagrams And Specifications
DS3002 DSP block diagram The DS3002 provides two audio inputs which can be configured to be either analog or CobraNet. There are four internal soundmasking generators, each having 1/3 octave EQ, high and low pass filters. A six input matrix mixer feeds eight output channels which are routed to both analog and CobraNet outputs. - Page 27 1/3 octave EQ, high and low pass filters. A twelve input matrix mixer feeds eight output channels which are routed to both analog and CobraNet outputs. DS3008 Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275...
- Page 28 The DS8000 provides eight network audio inputs. There are four internal soundmasking generators, each having 1/3 octave EQ, high and low pass filters. A twelve input matrix mixer feeds each speaker output. DS8000 Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275...
- Page 29 DS8000 firmware version version 1 DS8000 firmware version 2 Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275...
-
Page 30: Dsm-16 Contact Closure Module
Comm Port 1 and 115200 Baud. The Interval can be specified to control how often the contact closure status is polled. DSM16 Contact Closure Module - Profile selection Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275... -
Page 31: Ds1404 Programmable Level Controller
Using the DS1404 programmable level controller Dynasound’s DS1404 prgrammable level controller is a level control scheduler for systems not having a touch screen controller. The DS1404 is a non-networked product that must be connected to the analog audio IO of the DS3008. The DS1404 can only schedule the broadcast soundmasking and not soundmasking generated locally in the DS8000. -
Page 32: Initial Installation And Configuration
DS8000 would be active in this scenario. Additional DS3008 and DS3002 processors may also be used in complex networks to provide Analog to Digital or Digital to Analog conversion used to introduce or extract audio signals to or from the digital audio network. -
Page 33: Ds3002, Ds3008, Ds8000 Specifications
Input power: Power over Ethernet Typical power consumption 3 -5 watts. Max 12 watts. Dimensions: 7.25 “ long x 5.25 inches wide x 1.25 inches deep. Max. Operating Temperature: Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275... -
Page 34: Network System Configuration Notes
2: ___________________________ network channel 3: ___________________________ network channel 4: ___________________________ network channel 5: ___________________________ network channel 6: ___________________________ network channel 7: masking A__________________ network channel 8: masking B__________________ System notes: Dynasound, Inc. 6439 Atlantic Blvd. Norcross, GA. 30071 800.989.6275... -
Page 35: Warranty
Tech support Software updates and the latest documentation can be downloaded from the Dynasound web site. Go to www.soundmasking.com/support For additional support: Patrick Gillilan, Dynasound, Inc. Nationwide (800) 989-6275 ext 14 In Georgia (770) 242-8176 ext 14 Cell / After business hours (770)-634-3000 email: gillilan@dynasound.com...
