Alert-it P139B Quick Start Manual page 3

Function/Menu Left Range
ID Number/Site No
On/menu key menu Press to scroll menu. Press any key also resets alarms
POWER off
Tick Volume off 1 8
Shallow Minimum off 0 10
10 60
Shallow Delay 1
Shallow Maximum off 20 30
1 8
Shallow Magnify 1
Spasm Delay off 5 60
1 8
Spasm Magnify 1
1 4
1
Spasm Rate
Sound Delay off 5 60
1 8
1
Sound Magnify
1 4
Sounds Rate 1
Moisture off 1 5
Bed Occupancy off 5 s 24h
Reload Default
1
Function hidden if alarm off
Other alarms without set-up parameters
Function Pager
Turned off Red Flash, No Alarm
Battery Low Red Flash, No Alarm
External Alarm Alarm
Radio Fail Steady Red, No Alarm
Unless otherwise agreed, the P139 will be shipped only to create alarms in response to Bed Movement, to prevent the confusion of many alarms activating as soon as the unit is turned on. Any unused sensors will have
their menu hidden (see handbook to change this) . The other alarm functions can then be enabled one at a time as confidence is gained at each level. The table below shows the recommended default start setting for
alarms and the pager indication that will occur. It can be used to record the actual settings used
Client set-up: Venue/Client Client set-up: Venue/Client
Alarm Setting & Pager Messages
Comment
Appears on screen at power up with software version
press to turn off (if enabled)
Volume of click on each shallow movement
MPM below which is alarm
Minimum time for Shallow movement alarm to be detected
MPM above which is alarm
Set for optimum movement detection using tick or * symbol
Time for spasm to set alarm
Set for optimum detection of spasm using # symbol
Seconds between movements: a spasm is assumed if faster
Time for sound level to set alarm
Sensitivity of microphone
Seconds between sound bursts: a spasm is assumed if faster
Fault alarm if sensor open circuit. Covers moist to wet
Time allowed for vacancy before alarm. Shallow alarm inhibited. 15 h
Snapshot saved in "hidden menu"
Comment
Unit has been turned off (warning)
Connect charger
Only on P139xxB with internal radio receiver
Must be corrected urgently
Date: Date:
Default Monitor Screen
Active or Suspend
Blank
8
OFF SHALLOW MIN
30 SHALLOW MOVEMENT
OFF SHALLOW MAX
6
15 SPASM MOVEMENT
4
2
OFF TRANSIENT SOUND
4
2
OFF MOISTURE
BED VACATION
Fault
All sensors are monitored
for signs of correct opera-
Red Flash, No Alarm
tion. If no sign of operation
occurs for 24 hours a fault
Red Flash, No Alarm
warning is given to force a
Red Flash, No Alarm
test of the sensor as shown
Red Flash, No Alarm
in the table
Red Flash, No Alarm
UQ1136B Quick-start P139-P168 Radio.ppp v5 Page 3of 4 26/4/17
Pager Client
Red Flash,
No Alarm
Alarm
Alarm
Alarm
Alarm
Alarm
Alarm
Alarm
Source Action to clear
/confirm fault
Movement Sensor Tap bed
Spasm Sensor Tap bed
Sound Sensor Clap hands
Occupancy Sensor Sit on bed
Moisture sensor Fit new dry sensor
