TS-C OPERATION
There are two ways to jam sync the TS-C: First is to feed an external time code (via the ¼" jack or LEMO) while the TS-C is off.
Select the desired frame rate with the rotary switch. Set the run/read toggle switch to run (up) and power the slate on. The TS-C
will jam to the external time code. Second is with the desired frame rate selected, and the slate already on. While the slate is
running, close the sticks, and with external time code fed to the TS-C, press the display brightness up button. The slate will auto-
matically jam to the external time code. With this new feature, powering down the TS-C to re-jam is not required.
Aaton serial communication with the TS-C is very simple. Connect the LEMO plug from the master to the LEMO input on the
TS-C. Send the serial data from the master. The TS-C automatically enters the serial data mode and jam syncs to the external
master. Frame rate is dependent on the frame rate rotary switch setting. To verify time code, simply send the serial data query
from the master and the TS-C automatically returns its current time data.
Display brightness is controlled by two push buttons located on the back panel's upper right corner. Pressing the up button in-
creases the display brightness and pressing the down button decreases the brightness. The display brightness has 12 steps, each
increment is exactly 1/2 f-stop and the adjustment range is 6 full f-stops.
Time Out: Display times out when sticks are left open.
Feed Alert: Reminds you when to jam.
Jam Lock: Inhibits running time code without jamming.
Flash Frame: Changes intensity to ensure exposure.
The mode switches are located behind the sliding battery door on the side of the slate
To set mode functions, switch off power and place the rotary switch in position 7 for mode A or position 6 for mode B. Switch
power on and the selected mode will display. Use the rotary switch to cycle through available functions. The display shows the
function and status. To select the desired mode status place the run/read switch in run (on) or read (off) position. Push the set
button to capture the chosen function. Use Mode B(6) to set values for the selected function. Pushing the set button will display
and increment the value. When the desired modes are set, switch to "Return"(0) and push the set button. The display will run.
[NOTE: the letter "M" is displayed as "n" on the 7 segment display.]
Mode "A" selects the mode status while mode "B" selects the mode value. All setup information is displayed on the LED readout.
To reset to default (all modes off), go to mode B(6), select Dflt(3), run/read switch in run (on), and push the set button. "Set" will
light and all functions will reset to the default values.
SET UP CHART
Version 1.6
0) Start
1) Time out/Display
2) Feed warning in UB
3) Jam lock
4) Flash held frames
5) Hold clap frame
6) EL backlight
7) -
8) Plus 1 frame reader
9) -
* Note: M is displayed as "n" on the 7 segment display.
Denecke, Inc.
25030 Avenue Stanford • Suite 240 • Valencia, CA 91355 • Phone (661) 607-0206 • Fax (661) 257-2236
Info@denecke.com • www.denecke.com
MODES
EL Backlight: Enable/disable in low brightness.
Hold Clap Frame: Displays the last time code after the user bits.
Plus 1 Frame Time code is displayed in real time when in read
Reader: mode.
Scroll back: Push Set button while sticks are closed to display
scroll back of previous claps.
Scroll back memory is cleared at power off.
Mode A Status
Return
Tout on/(off)
Feed "
Jloc "
Flsh "
Hold "
EL (on)/off
node* A
Pls1 on/(off)
-
Default settings indicated by parenthesis.
DISPLAY
Mode B Value
Return
15,30,(60),120 Seconds
2,(4),6,8 Hours
Dflt (Set)
1,(2),3,4,5 Frames
(5),15,30,60,120 Seconds
node* B
-
-
-
June 2005
