Skycut D Series User Manual

With sure cuts a lot
Hide thumbs Also See for D Series:
Table of Contents

Advertisement

Quick Links

Download this manual
You can expect updates to this manual over the next few months
Do NOT read this entire manual... unless you want to.
•
At the start of Chapters 1 - 4 are short sections with references to find what you need plus some important
reminders. PLEASE read these short sections at the very least and refer back to them, when needed.
•
Chapters 1 and 2 are very important in terms of correctly setting up your Skycut to work with SCAL and
learning the ins and outs of cutting.
•
Chapter 3 is for those owners wanting to perform print and cut applications.
•
Chapter 4 covers using the Skycut accessory tools and dual head applications.
•
Chapters 5 – 12 are specific to SCAL and present every function in the software, many of which you may
never need.
It's not practical to print this entire manual because:
•
It's a waste of paper and ink if you only ever need certain sections.
•
The live links to videos and section numbers in the manual will not work.
•
This manual will be updated from time to time.
•
You cannot search on individual words.
Also:
•
Note the green
videos will enhance your learning experience.
_______________________________________________________________
© 2018-2020
Sunrise Electronic Technology Co., Ltd. All Rights Reserved

Skycut Series D with Sure Cuts A Lot

August 20, 2020
icons which link to videos related to the section in which they are located. These
1
