Dräger Babylog V Series Disassembly/Assembly
Dräger Babylog V Series Disassembly/Assembly

Dräger Babylog V Series Disassembly/Assembly

Neonatal expiratory valve

Advertisement

Quick Links

Dräger Babylog
®
Neonatal Expiratory Valve
Disassembly/Assembly
Disassembly
/Assembly
Open the flap by lifting the lower
edge upwards.
Close the flap.
Disassembly
/Assembly
Remove the muffler from the
expiratory valve.
Attach the muffler to the
expiratory valve.
The muffler is only used with the Babylog
This guideline does not replace or amend the instructions for use. Please always refer to the
reprocessing instruction in the latest instruction for use of the components. The instructions
for use and the hospital guidelines and policies always have to be observed.
V-Series
Neonatal Expiratory Valve
Turn the locking ring to the left
end position.
Turn the locking ring to the right
6
until it clicks into place.
Neonatal Expiratory Valve
Remove the diaphragm.
Do not disassemble further.
Attach the diaphragm onto the edge
of the expiratory valve housing.
Make sure that it fitts properly.
®
V-Series.
Remove the expiratory valve from
the fitting.
Turn the locking ring as far as
5
possible to the left and push the
expiratory valve into the fitting.
Remove and empty the water
6
trap container.
Connect the water trap container.
