JACKKNIFE SOFA SUPPORT LEG INSTALLATION GUIDE
Purpose
This document describes the procedure for attaching legs to the jackknife sofa. The aftermarket leg kit is PN
364582 and contains two 11
Resources Required
• Socket wrench
1/2
•
" socket
1/2
•
" open-end wrench
Installation
1.
Stand sofa on its side to provide access to one leg bracket.
2.
Install bolts facing outward in the holes on the end of each side of the leg bracket (Figs 1 and 2).
3.
Insert leg section onto the bolts (Fig. 3).
Hole at End
of Bracket
Rev: 06.28.19
FURNITURE
1/2
5/16
" x 2" legs, four
" - 18 x
Fig. 1
Fig. 3
Page 1
3/4
" bolts and four nylon locknuts.
Hole at End
of Bracket
Fig. 2
Bolt Facing
Outward
CCD-0002702
Advertisement
Table of Contents
Related Manuals for Lippert Components TI-325
Summary of Contents for Lippert Components TI-325
- Page 1 JACKKNIFE SOFA SUPPORT LEG INSTALLATION GUIDE FURNITURE Purpose This document describes the procedure for attaching legs to the jackknife sofa. The aftermarket leg kit is PN 5/16 364582 and contains two 11 " x 2" legs, four " - 18 x "...
- Page 2 JACKKNIFE SOFA SUPPORT LEG INSTALLATION GUIDE FURNITURE Place nut on end of bolts. Apply open-end wrench to the bolt head to prevent movement while tightening the nut (Fig. 4). Using a 1/2" socket and socket wrench, firmly tighten the nut (Fig. 5). Repeat procedure to fasten the other bolt.
