Features
Very Long Range:
•
LoRA Spread Spectrum,
•
FM Technology
•
4 Channels Each Rated 1KW
•
Relay Changeover Contacts
•
Momentary or Latching or Timed
•
Pair any Tx Switch to Any Rx O/P
•
Power Supply either:
•
6-32Vdc/ac, 110Vac or 230Vac
•
IP68 Waterproof Enclosure
•
Signal Strength LED Indication
•
Transmits RF Acknowledge signal
•
back to Transmitter
Optional External Antenna mount
•
Systems supplied 'ready to Go'
•
Connections Via Screw Terminals
•
Description
A versatile general purpose Remote Control System for many different applications.
Housed in a rugged IP68 enclosure, This receiver is ideally suited to any outside Remote
switching. It has 4 changeover relay outputs, using the 'easy-learn' process each output
can be controlled from one or many switches form one or many transmitters.
Part No
ELITE-8R4
ESPRIT-9R4
16KM Range Professional Receiver
Description
Receiver 4 Channel 868MHz
Receiver 4 Channel 918MHz
DS ELITEESPRIT-1
ELITE / ESPRIT Series
Applications
Garden Lighting
•
Pond pumps
•
Remote outdoor Switching
•
Industrial control
•
Compatible with All RF Solutions 868 /
918MHz Transmitters
Supply Voltage
230Vac or 6-32Vdc
110Vac or 6-32Vdc
Advertisement
Related Manuals for RF SOLUTIONS ELITE Series
Summary of Contents for RF SOLUTIONS ELITE Series
- Page 1 Optional External Antenna mount • Industrial control • Systems supplied ’ready to Go’ • Compatible with All RF Solutions 868 / Connections Via Screw Terminals • 918MHz Transmitters Description A versatile general purpose Remote Control System for many different applications.
-
Page 2: Configuring The Receiver
ESPRIT & ELITE Receivers Configuring the Receiver Relay Operation Link fitted - MOMENTARY Link Removed - LATCHING Relay Supply Relaxed Active Either ac or dc NOT Both! NO COM NO COM Relay Outputs Each output relay is an independent isolated switch. - Page 3 ESPRIT & ELITE Receivers Timer Erase Mode Pair LED s Power Transmit Receive RF Signal Strength LED I ndication AUTO PAIR a new transmitter Timer ( Setting a Timed Output) (PAIR complete Transmitter to complete Receiver) 1. Repeat press the TIMER Switch to scroll 1.
-
Page 4: Mode Of Operation
This Receiver can be configured to operate in FSK or LoRA Modes. FSK = (FM) fixed frequency Carrier Frequency. Provides a fast Time of operation and is compatible with all other RF Solutions products at this frequency. LoRA– Long Range Spread Spectrum . - Page 5 ESPRIT & ELITE Receivers Application Drawing - Switching a Lamp RELAY 4 RELAY 3 RELAY 1 FUSE NO COM NC NO COM NC NO COM NC NO COM NC 230V INPUT SUPPLY Wall Mounting template (not to scale) All Dimensions in mm 125.50 251.00 DS ELITEESPRIT-1...
-
Page 6: Technical Specifications
ESPRIT & ELITE Receivers Technical specifications Enclosure Rating: IP68 Dimensions: 267 x 148 x 78mm (not including antenna) Operating Temperature: -10 to +60 Celsius. Electrical Characteristics TYPICAL DIMENSION Supply Voltage Vdc or ac Operating Frequency 869.5 868MHz Version 918.0 918MHz Version Supply Voltage for ac ESPRIT ELITE... - Page 7 Disclaimer: Whilst the information in this document is believed to be correct at the time of issue, RF Solutions Ltd does not accept any liability whatsoever for its accuracy, ade- quacy or completeness. No express or implied warranty or representation is given relating to the information contained in this document. RF Solutions Ltd reserves the right to make changes and improvements to the product(s) described herein without notice.
