F-PLS Power Line Security Camera
F-PLS Power Line Security Camera
This description applies to the following models:
F-PLS
User Manual
Model
Product Category
F-PLS200
Standard Edition
F-PLS210
Enhanced Edition
Four-Faith Corporation
Add：11th Floor, A-06 Area, No.370, Chengyi Street, Jimei,
Xiamen, Fujian, China.
Tel：+86 17750019379
Web: en.four-faith.net
en.four-faith.net
F-PLS User Manual
Version:
Model:
Page:
Fax: +86 592-5912735
V2.0.1
F-PLS
30
1
Advertisement
Table of Contents
Related Manuals for Four-Faith F-PLS Series
Summary of Contents for Four-Faith F-PLS Series
- Page 1 User Manual This description applies to the following models: Model Product Category F-PLS200 Standard Edition F-PLS210 Enhanced Edition Four-Faith Corporation Add：11th Floor, A-06 Area, No.370, Chengyi Street, Jimei, Xiamen, Fujian, China. Tel：+86 17750019379 Fax: +86 592-5912735 Web: en.four-faith.net F-PLS en.four-faith.net...
- Page 2 F-PLS User Manual Document Revision History Date version Description Author Aug. 2019 V2.0.0 Initial version Qiu Junhua Dec. 2019 V2.0.1 English translation Lucas Ma F-PLS en.four-faith.net...
- Page 3 All contents in the files are protected by copyright law, and all copyrights are reserved by Xiamen Four-Faith Communication Technology Co., Ltd. Without written permission, all commercial use of the files from Four-Faith are forbidden, such as copy, distribute, reproduce the files, etc., but non-commercial purpose, downloaded or printed by individual (all files shall be not revised, and the copyright and other proprietorship notice shall be reserved) are welcome.
-
Page 4: Table Of Contents
3.2 Platform Configuration....................16 3.3 Platform Features......................19 3.3.1. Login.......................19 3.3.2. Home Page...................... 19 3.3.3 GIS Positioning....................21 3.3.4. Real-time Monitoring..................22 3.3.5. Polling Monitoring..................23 3.3.6. Alarm Handling....................24 3.3.7. Historical Inquiry.................... 25 3.3.8 Device Management..................26 3.3.9 System Management..................29 F-PLS en.four-faith.net... -
Page 5: Introduction
Following picture shows the typical application Figure 1. Application Diagram F-PLS en.four-faith.net... -
Page 6: Features
Immediately into operation status after power-up Provide RS232/RS485, DI , DO and 12VDC, that can be directly extended to other line monitoring equipment WIFI Hot spot and wireless parameter configurable Integrated design with small size, light weight and compact structure F-PLS en.four-faith.net... - Page 7 Support Pan Tilt control function (optional) Support weather monitoring function (optional) Support acousto-optic alarm (optional) Support remote call function (optional) Support configuration of WIFI Hot spot parameters through web Support remote monitoring, parameters configuration and firmware upgrading F-PLS en.four-faith.net...
-
Page 8: Specifications
Transmit power < 24dBm Reception >-109dBm sensitivity 1.3.2 GNSS Parameters Content Item Receive Type GPS/GLONASS/BeiDou Cold Start: -146 dBm Sensitivity Capture: -158 dBm Tracing: -160 dBm Cold Start: 32s TTFF Warm Start: 30s Hot Start: 2s Static Drift F-PLS en.four-faith.net... -
Page 9: Wifi Parameters
Flash 16GB eMMC DDR3 Camera：normal 16 million pixels，night vision 2 million pixels （optional)，look down 16 million pixels（optional） Camera Video format：1920*1080P，30f/s Zoom：20 times（optional） TF Card 32GB(optional) 1.3.5 Software System Item Content Operating System Android 7.1 Compatible with Android system F-PLS en.four-faith.net... -
Page 10: Interface Type
Battery pictures per day) 1.3.8 Physical Characteristics Item Content Enclosure PC/ABS, IP67 Dimension Main unit: 224*120*127mm，Solar panel: 340*450*20mm Weight 5.5kg (without extended equipment) 1.3.9 Other Parameters Item Content Temperature Operating : -25～+70ºC; Store: -40～+85ºC Relative Humidity 100%（no condensation） F-PLS en.four-faith.net... -
Page 11: Installation
2pcs Installation Hook 1pcs tilt module (optional) 1pcs Meteorological module (optional) 1pcs acoustic-optical module (optional) 1pcs temperature measurement module (optional) 1pcs Pan Tilt module (optional) 1pcs quality certificate and warranty card F-PLS en.four-faith.net... -
Page 12: Installation
2) Turn off the power switch ( it is not allowed to install SIM / UIM or TF card with power) 3) Install SIM / UIM or TF card (metal contacts of SIM / UIM or TF card should face downwards) 4) Turn on the power switch 5) Install the card cover, tighten the screws F-PLS en.four-faith.net... -
Page 13: Main Unit Installation
3) Installation height: the lowest point of conductor sag is the best photo angle, try to install it at a high place to prevent theft, and try to select the cross brace for installation. F-PLS en.four-faith.net... -
Page 14: Operating Instructions
3) Use the WIFI of Computer or mobile phone to connect the hot spot (default password: 123456). 4) Use your browser and enter: http://192.168.43.1:8088/ 5) Log in the page, the default user name and password are both “admin”. Figure 8 F-PLS en.four-faith.net... - Page 15 F-PLS User Manual 6) Set the server IP and server port on the "Network" page (for example, server IP of the Four-Faith platform: 212.64.11.125, port: 1910). Figure 9. 7) Set parameters of camera, video recording and data acquisition in "Rule Info".
-
Page 16: Platform Configuration
F-PLS User Manual 3.2 Platform Configuration 1) Prepare a PC, enter “https://cs.four-faith.net/ffem-admin/login.html” in the browser, and log in to the system. (please contact our staff for initial account number and password) Figure 11. 2) After login, enter “Org Management”, click "Add" to establish a group. - Page 17 4) Select the newly added line in the organization tree on the left, click "Add" to build a “tower”, select "tower" in the “group type”. Figure 16. 5) Select the newly added tower in the organization tree on the left, click "Add" to create a device, select "device" in the “group type” Figure 17 F-PLS en.four-faith.net...
- Page 18 "OK" to complete the binding of device and platform.. Figure 18. Icon Description: : Group : Tower : Device (green icon indicates online, gray icon indicates Offline, red icon indicates an alarm, the question mark icon indicates not installed) F-PLS en.four-faith.net...
-
Page 19: Platform Features
You can view the number of alarms, the total number of devices, the number of online devices, the online rate, the number of alarm types and the installation of extended modules in the past seven days. Figure 20. F-PLS en.four-faith.net... - Page 20 You can view and process the alarm information, as shown in the following figure: Figure 21. Click "Device Count" to enter the list of equipment management information to view the details of the equipment, as shown in below figure: Figure 22. F-PLS en.four-faith.net...
-
Page 21: Gis Positioning
Figure 24. The system polls the alarm information regularly. If there is an alarm, the pop-up window on the right will display the alarm details. Click the alarm information, the page will jump into the alarm processing page. F-PLS en.four-faith.net... -
Page 22: Real-Time Monitoring
Clicking "AcquireData", the device can get the monitoring data immediately and send the data to the platform. Figure 26. Remote calling, real-time video, pan tilt control and focusing functions will be effective only after the device is activated. F-PLS en.four-faith.net... -
Page 23: Polling Monitoring
(the latest three unprocessed data), and the latest reported monitoring data. Click “Pause” or “Stop” button to pause or stop the polling of pictures / videos and data. F-PLS en.four-faith.net... -
Page 24: Alarm Handling
Click “Alarm” in main menu, you can view the alarm details and alarm processing results. Support condition search and batch processing for alarms. Figure 28. Click the alarm type in the alarm list, you can view specific alarms. Figure 29. F-PLS en.four-faith.net... -
Page 25: Historical Inquiry
F-PLS User Manual 3.3.7. Historical Inquiry Click “History” in the main menu, you can view historical pictures / videos, voltages, sensor data, etc., and search can be done by time and data type Figure 30. F-PLS en.four-faith.net... -
Page 26: Device Management
Click “Device” in the main menu, the equipment can be installed, dismantled, set parameters, upgraded remotely, imported and exported in batches Figure 31. During the installation operation in platform, the device number of device must be filled in. Figure 32. F-PLS en.four-faith.net... - Page 27 Select the device, click “Dismantle” to remove the device. Figure 33. Click “Batch SetParam” button to batch set network information, extended device threshold, rule information and contact person. It takes 1 minute after batch modification to modify again. Figure 34. F-PLS en.four-faith.net...
- Page 28 Click “Import” to batch import the devices into the system. On the right side of the device list, you can view device details, restart the device, modify device parameters, view logs, and upgrade firmware remotely. Figure 35. F-PLS en.four-faith.net...
-
Page 29: System Management
F-PLS User Manual 3.3.9 System Management Click “System” in the main menu, you can add, modify, or delete users, roles, and organizations. Figure 36. In the “User Management” page, you can add, modify or delete an account. Figure 37. F-PLS en.four-faith.net... - Page 30 In the “Org Management” page, you can add, modify or delete the organization tree. On the node adding page, as shown in the following figure, there are four types of organization tree node: group, line, tower and device. The operations for each type of node are similar. Figure 39. F-PLS en.four-faith.net...
