Summary of Contents for Four-Faith F-PLS
- Page 1 Document Version Pages F-PLS User Manual V1.0 Model：F-PLS Total:22 F-PLS User Manual Four-Faith Corporation Add：11th Floor, A-06 Area, No.370, Chengyi Street, Jimei, Xiamen, Fujian, China. Tel：+86 17750019379 Fax: +86 592-5912735 Web: en.four-faith.net...
- Page 2 F-PLS User Manual Files Revised Record Date Version Remark Author 2019.2.25 V1.0 F-PLS-V1.0 en.four-faith.net Page 2 of 22...
-
Page 3: Copyright Notice
Xiamen 、 、 Four-Faith Communication Technology Co., Ltd., illegal use of the name of Four-Faith, trademarks and other marks of Four-Faith is forbidden, unless written permission is authorized in advance. F-PLS-V1.0 en.four-faith.net Page 3 of 22... - Page 4 F-PLS User Manual F-PLS-V1.0 en.four-faith.net Page 4 of 22...
-
Page 5: Table Of Contents
F-PLS User Manual Contents 1 Brief Introduction..........................6 1.1 Overview..........................6 1.2 Feature........................... 6 1.2.1 Industrial Application Design..................6 1.2.2 Reliability........................6 1.2.3 Easy to use........................7 1.2.4 Function........................7 1.3 Specification..........................8 1.3.1 Basic Parameters......................8 1.3.2 Physical Feature......................8 1.3.3 Environment Parameter....................8 2 Installation............................ -
Page 6: Brief Introduction
F-PLS is a special camera which integrate with solar panel and battery inside. it also has 2G/3G/4 G communication, GPS positioning, 433MHz access, image recognition, line temperature measure ment, environmental monitoring, voice broadcast and other functions. -
Page 7: Easy To Use
F-PLS User Manual 2G/3G/4G antenna, GPS antenna, WIFI antenna, 433MHz antenna embedded SIM card embedded 1.2.3 Easy to use Support National Grid online monitoring standard, National Grid encryption, Southern Grid online monitoring standard Compliant with transmission line photo/video specification standard ... -
Page 8: Specification
F-PLS User Manual 1.3 Specification 1.3.1 Basic Parameters Content Item F-PLS100 F-PLS110 8 Mega pixel, max 2100 Mega 8 Mega pixel, max 2400 Mega pixel High definition lens pixel optional optional Low light lens 2 Mega pixel, min light 0.001Lux... -
Page 9: Installation
F-PLS User Manual Item Content Working -25～+70℃ temperature Storage temperature -40～+85℃ Relative Humidity 0~100%RH (No condensation) Table 4-Environment Parameter 2 Installation 2.1 Overview The equipment must be installed correctly to achieve the designed function, usually the equipment must be installed under the guidance of qualified engineers recognized by the company. -
Page 10: Installation Process
F-PLS User Manual shooting Angle, as far as possible to install on high to prevent theft, try to apply the cross-brace installation. 2.3.3 Installation Process Pic :2 -1 Pic:2-2 Remove the package.then pull out the solar panel cable and fix it to panel side (hide it in ... -
Page 11: Platform Software
F-PLS User Manual 3 Platform Software 3.1 Overview The software and hardware of the platform shall be used together. After the installation of the equipment, users can check the position, pictures, video, sensor data and other information on the platform. Users shall ask for the account number and password from the service staff before logging into the platform initially. - Page 12 F-PLS User Manual Pic 3-3 Step 2: Add SIM card and camera information (after that, it must be installed on the tower, and the installation of temperature measurement module and weather module is with the same steps.) Pic 3-4 图 3-5 F-PLS-V1.0...
- Page 13 F-PLS User Manual 图 3-6 图 3-7 Step 3: Correlate the devices to the group and user as required Pic 3-8 F-PLS-V1.0 en.four-faith.net Page 13 of 22...
-
Page 14: Real-Time Monitoring
F-PLS User Manual Pic 3-9 Pic 3-10 3.3Real-time Monitoring After adding the device, the data information of the device can be viewed in the real-time monitoring. Click "real-time monitoring" and select the device to view to see all pictures of the device, click any picture to enter the large picture display and operation page, then historical pictures, temperature data, weather data will be indicated in the picture.and it also can auto-take photos,... -
Page 15: Photo Rotation
F-PLS User Manual Pic 3-11 Pic 3-12 3.4Photo Rotation Picture rotation can replace manual view of equipment pictures. Set rotation conditions after entering this page, and then start rotation. F-PLS-V1.0 en.four-faith.net Page 15 of 22... -
Page 16: Warning Process
F-PLS User Manual Pic 3-13 3.5Warning Process The platform analyzes the pictures and video data reported by the monitoring and photographing device in real time, and displays the hidden trouble pictures in the first time when hidden trouble occurs near the corridor of the line. Users can also conduct corresponding operation for the hidden trouble. -
Page 17: Configuration Policy
F-PLS User Manual 3.7Configuration Policy The platform can set the rules of taking photos, temperature alarm, micro weather alarm, etc. Since the device is in a dormant state when it is not in working status, it takes a certain time to take effect after parameter setting. -
Page 18: Statistics
F-PLS User Manual Pic 3-18 3.8Statistics The platform carries out automatic statistics on warning and alarm, operation status and device information, and the corresponding statistical information can be viewed through the statistics interface. Pic 3-19 F-PLS-V1.0 en.four-faith.net Page 18 of 22... -
Page 19: System Management
F-PLS User Manual Pic 3-20 3.9System Management The platform supports the management of gourps, roles, users, and organizational parameters (not all users have this capability, depending on the level of the account). Pic 3-21 Pic 3-22 F-PLS-V1.0 en.four-faith.net Page 19 of 22... -
Page 20: Wechat Function
F-PLS User Manual Pic 3-23 Pic 3-24 4 Wechat Function Real-time Photo Delivery: every photo taken by the device is immediately delivered to the user, which can be turned on or off in the Settings. F-PLS-V1.0 en.four-faith.net Page 20 of 22... - Page 21 F-PLS User Manual Pic 4-1 Pic 4-2 Deliver Alarm: the platform automatically identifies hidden dangers and deliver them to users. Pic 4-3 Power Line Circuit inspection: automatic inspection on the latest photos of all equipment. F-PLS-V1.0 en.four-faith.net Page 21 of 22...
- Page 22 F-PLS User Manual Pic 4-4 Take photo and record video actively, historical data and acousto-lighting control: the device can be remotely controlled and the historical data can be checked through this function Pic 4-5 F-PLS-V1.0 en.four-faith.net Page 22 of 22...
