- Page 1 VALI instruction Replacement of Vali fan...
- Page 2 Instruction – Replacement of Vali Fan (Requires Fan Replacement Kit) Remove power lead, then disconnect battery leads. also remove fluid PLEASE NOTE! Sensor and fluid Bottle to prevent possible damage during procedure. Remove the l/H side cover by removing the Hole plugs and loosening the four screws.
- Page 3 Instruction – Replacement of Vali Fan (Requires Fan Replacement Kit) now slide away the top cover of the electronics module to provide access to pcB. now remove the 2 x m4x10 Black taptite Screws holding the small fluid pipe Bracket in place as shown.
- Page 4 Instruction – Replacement of Vali Fan (Requires Fan Replacement Kit) place your replacement now connect the Header fan onto the mounting onto the pcB as shown, posts ensuring that the ensuring that the label on the center of the connection is secure and fan is facing outwards and covering all 3 pins.
- Page 5 Instruction – Replacement of Vali Fan (Requires Fan Replacement Kit) Once Fan is fitted and Secure the top cover with secure, reconnect the the 4 x m4x10 Black steel fluid pipe to the taptites removed earlier one-way valve as shown and then re-connect iDc and gently re-position cable and earth lead as...
- Page 6 Instruction – Replacement of Vali Fan Slide l/H and R/H covers back into place ensuring tabs on inside of each cover are correctly aligned with the central vertical strap. also, ensure that the earth leads are re- connected on both covers. finally, tighten the 4 x screws and replace the 4 x white hole plugs (l/H)
- Page 7 Rectory court High Street Kislingbury UK - northants, nn7 4aG phone +44 (o) 1604 839 000 +44(0) 1604 832 666 www.smokecloak.com contact: mSS professional a/S agerhatten 25 DK - 5220 odense SØ phone +45 7217 0011 +45 8617 0055...
