- Page 1 Owner’s Manual Model No. 168129800FI ST800FI FLAT INCLINE BENCH - Assembly - Operation - Adjustments - Parts - Warranty CAUTION: Read and understand this manual before operating unit Retain For Future Reference...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Product Registration ................... 2 Important Safety Instructions ..............3-4 Assembly Instructions ................. 6 Unpacking ....................6 Adjusting the Bench ..................8 Resistance Training Benefits and Tips ............9 General Maintenance ................10 Exploded View Diagram ................11 Parts List .................... -
Page 3: Product Registration
Congratulations on your new ST800FI Flat Incline Bench and welcome to the Dyaco Canada family! Thank you for your purchase of this Spirit ST800FI Flat Incline Bench from Dyaco Canada Inc. Your new ST800FI Flat Incline Bench was manufactured by one of the leading fitness manufacturers in the world and is backed by one of the most comprehensive warranties available. -
Page 4: Important Safety Instructions
BEFORE YOU BEGIN Thank you for choosing the SPIRIT ST800FI Flat Incline Bench. We take great pride in producing this quality product and hope it will provide many hours of quality exercise to make you feel better, look better, and enjoy life to its fullest. It's a proven fact that a regular exercise program can improve your physical and mental health. - Page 5 FACILITY SAFETY PRECAUTIONS • Read the Owner’s Manual carefully before assembling, servicing or using the equipment. • Make sure that each bench is set up and operated on a solid level surface. Do not install equipment on an uneven surface. •...
- Page 6 MAINTENANCE Preventative maintenance allows proper equipment operation and reduces the risk of injury. Perform the maintenance requirements as specified in the manual (see table on page 10). STANDARD COMPLIANCE Dyaco Canada products meet or exceed applicable ASTM and EN Standards WARNING/CAUTION DECALS •...
-
Page 7: Assembly Instructions
ST800FI ASSEMBLY INSTRUCTIONS To avoid possible damage to this ST800FI Flat Incline Bench, please follow these assembly steps in the correct order. Be sure to read your Assembly/Owner’s Guide before using your new ST800FI Flat Incline Bench. Please use the various lists in this manual to account for all parts included in the assembly. - Page 8 STEP ONE ST800FI Attach the Rear Bracket (No.2) to the Base Bracket (No.1). Secure with: 2 M10 x 130 Hex Head Bolts (No. 30), 2 Nylon Lock Nut M10 (No. 39) and 4 washers φ11 x φ20 x 2 (No. 43).
-
Page 9: Adjusting The Bench
ADJUSTING THE BENCH The seat and back pad are both adjustable for a wide range of exercises. The Back pad angle is adjustable to six different settings as seen in the image. Simply pull the pop-pin adjustment knob and adjust the angle to your desired setting. Once selected, make sure the pop-pin is fully engaged in the selected hole before doing any exercise. -
Page 10: Resistance Training Benefits And Tips
EXERCISE BANDS Some users will benefit from using exercise bands with this bench. There are two hooks located at the rear of the bench near the transport wheels for use with exercise bands. Make sure any exercise bands used are in good working condition and properly secured to the bench before doing any exercise. -
Page 11: General Maintenance
GENERAL MAINTENANCE For best performance, Dyaco Canada Inc. recommends the following maintenance schedule. Check the integrity and function of the following parts. Replace all worn components immediately. Your equipment comes with a commercial schedule decal. For in home use, please follow the maintenance schedule listed below: ROUTINE COMMERCIAL... -
Page 12: Exploded View Diagram
EXPLODED VIEW DIAGRAM Customer service: 1-888-707-1880 Dyaco Canada Inc 2020 Email: customerservice@dyaco.ca... -
Page 13: Parts List
PARTS LIST KEY NO PART NO DESCRIPTION Q’TY 9800FI01 Base Bracket 9800FI02 Rear Bracket 9800FI03 Front Adjustable Bracket (outer) 9800FI04 Back Pad Bracket 9800FI05 Seat Pad Bracket 9800FI06 Front Adjustable Bracket (Inner) 9800FI07 Back Adjustable Bracket (Inner) 9800FI08 Back Adjustable Bracket (Outer) 9800FI09 Seat Pad 9800FI10... - Page 14 KEY NO PART NO DESCRIPTION Q’TY 9800FI35 Flat Head Cap Screw M6 x 15 9800FI36 Socket Set Screw M6 x 15 9800FI37 Socket Set Screw M5 x 3 9800FI38 Nylon Lock Nut M12 9800FI39 Nylon Lock Nut M10 9800FI40 Nylon Lock Nut M8 9800FI41 Hex Thin Nut M6 9800FI42...
-
Page 15: Manufacturer's Limited Warranty
MANUFACTURER’S LIMITED WARRANTY Dyaco Canada Inc. warrants all its Flat Incline Bench parts for a period of time listed below, from the date of retail sale, as determined by a sales receipt. Dyaco Canada Inc.’s responsibilities include providing new or remanufactured parts, at Dyaco Canada Inc.’s option, and technical support to our independent dealers and servicing organizations. - Page 16 Please visit us online for information about our other brands and products manufactured and distributed by Dyaco Canada Inc. spiri�itness.ca solefitness.ca xterrafitness.ca dyaco.ca/products/everlast.html dyaco.ca/UFC/UFC-home.html spiri�itness.ca/johnnyg.html trainorsports.ca For more informa�on, please contact Dyaco Canada Inc. T: 1-888-707-1880 ⏐ 5955 Don Murie St., Niagara Falls, Ontario L2G 0A9 ⏐ sales@dyaco.ca...
