- Page 1 EMAX Interceptor RaceView with Controller (Goggle Ready) Thanks for purchasing the Tinyhawk II. Designed in California, assembled in China.
- Page 2 Before every play, make sure the battery is fully charged and power connections are secure. DO NOT run around crowds, children, animals or objects. EMAX ACCEPTS NO LIABILITY FOR DAMAGE(S) OR INJURIES INCURRED DIRECTLY OR INDIRECTLY FROM THE USE OF THIS PRODUCT. Precautions Please follow the instructions to assemble and to operate this product in a proper way.
-
Page 3: Product List
Radio Maximum appearance size 180*180*75(mm) weight (without battery) 135g 2.4GHz ISM Band Transmission frequency 2400MHz~2483.5MHz） Output Power 22dbm Modulation GFSK battery 3×AA batteries Product list 1.Interceptor × 1 2.Radio × 1 3.Instruction manual × 1 4.USB cable × 1 5.Screwdriver x 1 6.Battery for Interceptor ×... -
Page 4: Operation
Battery This is a 2.4 GHz radio, The radio is powered with 3×AA batteries. Operation Power Power on and off by toggle the remote control switch button. The power indicator light will turn red when on. The red light flashes quickly when the remote control battery is low. - Page 5 CAUTIONS WHEN CHARGING 1.When charging, please put this product on a dried or ventilated area and keep it far away form heat source or explosive product. 2.A battery when not in use for a long time will lose its charge automatically. Charging or discharging too often may reduce the life of the battery.
- Page 6 3.Pull the throttle trigger backward, the car will forward. Adjusting the angle of throttle trigger can adjust forward speed of the car. During the car forward, quickly push the trigger forward to stop it. 4.Loosen the trigger to make it return the neutral position when brake.
- Page 7 Line of Sight driving To learn how to drive interceptor start by driving it line of sight (no goggles yet). 1.Turn on the remote control switch of radio, then turn on the car. 2.Put the car on the frame or stand, If wheel is running self-motion, adjust the turned to fine-tune of the radio until the wheel is still.
-
Page 8: Button Menu Diagram
VTX Channel Settings with the Button 1. Normal display All LEDs on the VTX are normally off until the button is pressed. To check band and channel status click the button once quickly, and LED starts to indicate frequency band and frequency channel. -
Page 9: Troubleshooting
By purchasing this equipment, the user is agreeing that they understand these responsibilities and will operate the equipment legally. Emax cannot be held responsible for your actions if you purchase an d/o r us e th is pro du ct in v io lat io n o f y ou r government's regulations.
