  • Page 1 391818 / 819 Video Server 1ch / 4ch Guida Rapida • Quick Start Guide Reset ACT Net ALM Video RS232...
  • Page 2 Video Server 1ch / 4 ch ITALIAN ENGLISH...
  • Page 3: Table Of Contents

    Video server 1 in / 4 in Indice 1 Accessori ........................... 4 2 Introduzione generale ......................5 2.1 Panoramica ............................5 2.2 Caratteristiche ............................. 5 2.3 Specifiche ............................6 3 Telaio ........................... 12 3.1 Pannello anteriore ..........................12 3.2 Pannello posteriore NVS a 1 canale ....................13 3.3 Pannello posteriore NVS a 4 canali ....................
  • Page 4: Accessori

    1 Accessori Nome Qtà Server video di rete Adattatore di alimentazione da 12 V Connettore multifunzione del cavo dati per cavo COM maschio DB9 Guida rapida all'installazione...
  • Page 5: Introduzione Generale

    Video server 1 in / 4 in 2 Introduzione generale 2.1 Panoramica Questo dispositivo consente la raccolta, la trasmissione e l'archiviazione di dati audio e video. Può collegarsi alla rete direttamente senza alcun dispositivo ausiliario. Questo dispositivo usa la tecnologia di compressione video H.264 standard, che garantisce la massima qualità dei video. Può...
  • Page 6: Specifiche

    2.3 Specifiche 2.3.1 Specifica delle funzioni Modello Rif. 391818 Rif. 391819 Parametro Ingresso video analogico a 1 canale Ingresso video analogico a 4 canali Porta Ingresso video Porta BNC. Livello: 1,0 Vp-p. Resistenza: BNC. Livello: 1,0 Vp-p. Resistenza: 75 Ω...
  • Page 7 Video server 1 in / 4 in Specifiche Nota Supporta al massimo 6 periodi Modalità Registrazione (Il prodotto di questa serie non supporta questa funzione). Dopo aver abilitato la registrazione manuale, indipendentemente dal fatto che il sistema sia in stato Registrazione manuale di allarme o programmazione o meno, il sistema inizia Registrazione...
  • Page 8 2.3.3 Impostazione predefinita di fabbrica Fare riferimento allo schema seguente per informazioni sull'impostazione predefinita di fabbrica. Tipo di configurazione delle funzioni Nome elemento Impostazione predefinita Date format (Formato data) Y-M-D (A-M-G) Disable by default (Disabilita in modo predefinito) Date separator (Separatore di data) ‘...
  • Page 9 Video server 1 in / 4 in Tipo di configurazione delle funzioni Nome elemento Impostazione predefinita Channel (Canale) Channel 01 (Canale 01) Pre-record (Preregistrazione) 5 seconds (5 secondi) Start Time (Ora 0:00:00 di inizio) End-time (Ora 23:59:59 Schedule setup (Configurazione di fine) programmazione) Time Setup...
  • Page 10 Tipo di configurazione delle funzioni Nome elemento Impostazione predefinita Event type (Tipo evento) Local input (Ingresso locale) Alarm input (Ingresso allarme) Input 01, disable (Ingresso 01, disabilita) Type (Tipo) Normal open (Normalmente aperta) Period: (Periodo:) Start time 0:00:00 (Ora di inizio 00:00:00) Setup (Configurazione) End time: (Ora di fine:) 23:59:59...
  • Page 11 Video server 1 in / 4 in Tipo di configurazione delle funzioni Nome elemento Impostazione predefinita All (Tutti) Disable (Disabilita) General (Generale) Disable (Disabilita) Encode (Codifica) Disable (Disabilita) Schedule (Programmazione) Disable (Disabilita) RS232 Disable (Disabilita) Default and Backup Rete Disable (Disabilita) (Default e backup) Allarme Disable (Disabilita)
  • Page 12: Telaio

    3 Telaio 3.1 Pannello anteriore Fare riferimento allo schema seguente per informazioni dettagliate. Spia/Porta Funzione/Porta Colore Nota Quando l'alimentazione è collegata: rossa Quando il dispositivo funziona correttamente: la Spia dello stato di alimentazione/ Rossa/verde spia verde è accesa. funzionamento Quando il dispositivo sta eseguendo un aggiornamento: la spia verde lampeggia.
  • Page 13: Pannello Posteriore Nvs A 1 Canale

    Video server 1 in / 4 in 3.2 Pannello posteriore NVS a 1 canale Fare riferimento allo schema seguente per informazioni dettagliate. Nome porta Collegamento Funzione Riceve il segnale dal dispositivo front-end, come una V-IN Porta ingresso video telecamera o una speed dome. Uscita segnale video analogico.
  • Page 14: Pannello Posteriore Nvs A 4 Canali

    3.3 Pannello posteriore NVS a 4 canali Fare riferimento allo schema seguente per informazioni dettagliate. Nome porta Collegamento Funzione 4 porte di ingresso video per ricevere il Porta ingresso video segnale dal dispositivo front-end, come una telecamera o una speed dome. 4 porte di ingresso audio per ricevere il Porta ingresso audio segnale audio analogico dal microfono o dal...
  • Page 15: Strumento Di Configurazione Rapida

    Video server 1 in / 4 in 4 Strumento di configurazione rapida Lo strumento di configurazione rapida consente di cercare l'indirizzo IP di un dispositivo, anche se si trova in un altro segmento (telecamere, DVR, NVR, encoder e decoder) e di modificarlo. Lo strumento di configurazione è disponibile sul CD fornito con il prodotto.
  • Page 16 Per collegarsi a un dispositivo e aprire l'applicazione Web: - Evidenziarlo (un clic sull'elenco). - Fare clic con il tasto destro sulla riga evidenziata.   - Fare clic su "Open Device Web" (Apri Web del dispositivo). - Si apre la seguente pagina Web:  ...
  • Page 17 Video server 1 in / 4 in 4.1.2 Connessione con lo strumento di configurazione (per cambiare l’indirizzo IP o aggiornare il software interno del dispositivo) Per cercare dispositivi collegati alla rete: - Fare clic sul pulsante «Refresh» (Aggiorna); lo strumento cerca i dispositivi collegati alla rete e li visualizza sotto forma di elenco (consultare il capitolo 4.1.1 per dettagli sull’interfaccia).
  • Page 18 - Riavviare la procedura. Si apre la seguente finestra:   - Fare clic su Login (Accesso) per accedere alle modifiche dei parametri.     Funzione Nota Enable DHCP (Abilita DHCP) Abilita o disabilita la funzione DHCP IP address (Indirizzo IP) Indirizzo IP del dispositivo Subnet mask (Maschera di Maschera di sottorete del dispositivo...
  • Page 19 Video server 1 in / 4 in 4.1.3 PPPoE Selezionare "PPPoE" sul lato destro dell'interfaccia:   Funzione Nota Enable PPPOE Abilita o disabilita la funzione PPPoE (Abilita PPPOE) User Name (Nome Nome utente PPPOE utente) Password Password PPPOE IP address Indirizzo IP del dispositivo nella WAN (Indirizzo IP) Save (Salva)
  • Page 20 4.1.4 Sistema Selezionare "System Information" (Informazioni sistema) sul lato destro dell'interfaccia.   Funzione Nota Numero di serie del dispositivo Software version (Versione Versione del software del dispositivo software) Device name Nome del modello (Nome dispositivo) Synchronization with PC Sincronizzazione della data e dell'ora del PC con la data e l'ora del PC. (Sincronizzazione con PC) Fare clic su "Sync"...
  • Page 21 Video server 1 in / 4 in 4.1.5 Aggiornamento del sistema Selezionare "System Upgrade" (Aggiornamento sistema) sul lato destro dell'interfaccia.   Funzione Nota Upgrade file/Open (Aggiorna file/Apri) Fare clic qui per selezionare il file di aggiornamento. Current Progress/Upgrade Fare clic qui per avviare la procedura di aggiornamento. (Avanzamento attuale/Aggiorna) Return (Invio) Riporta all'interfaccia di ricerca...
  • Page 22 - Dopo aver trasferito il file, il dispositivo si aggiorna automaticamente.   - Dopo aver aggiornato il dispositivo, si apre la seguente casella di dialogo:   - Fare clic su OK per completare la procedura.
  • Page 23: Connessione A Un Dispositivo E Apertura Dell'applicazione Web

    Video server 1 in / 4 in 5 Collegamento a un dispositivo e apertura dell'applicazione Web 5.1 Configurazione del PC Questo dispositivo supporta l'accesso al Web e la gestione tramite PC. Il Web comprende diversi moduli tra cui l'elenco dei canali del monitor, la ricerca delle registrazioni, la configurazione degli allarmi, la configurazione del sistema, il controllo PTZ, la finestra del monitor, ecc.
  • Page 24: Connessione Con Lo Strumento Di Ricerca

    5.2 Connessione con lo strumento di ricerca Per aprire il software, fare doppio clic sull'icona "ConfigTool.exe" nel CD fornito con il prodotto. Per cercare dispositivi collegati alla rete: - Fare clic sul pulsante "Refresh" (Aggiorna); lo strumento cerca i dispositivi collegati alla rete e li visualizza sotto forma di elenco.
  • Page 25: Collegamento Con Internet Explorer

    Video server 1 in / 4 in 5.3 Collegamento con Internet Explorer Impostazione predefinita in fabbrica della telecamera IP: - Indirizzo IP: 192.168.1.108. - Nome utente: admin - Password: admin Aprire Internet Explorer (IE) e digitare l'indirizzo IP della telecamera nella barra dell'indirizzo. Ad esempio, se la vostra telecamera IP è...
  • Page 26 Dopo l'accesso compare la finestra principale: Nota: se si usa IE8 o superiore utilizzare la Visualizzazione Compatibilità. Per l'interfaccia Web consultare la guida utente dettagliata.
  • Page 27 Video Server 1ch / 4ch Indice 1 Accessories ............................28 2 General Introduction ..........................29 2.1 Overview ............................29 2.2 Features ............................29 2.3 Specifications ............................30 3 Framework ............................36 3.1 Front panel ............................36 3.2 Rear panel 1ch NVS ..........................37 3.3 Rear panel 4ch NVS ..........................
  • Page 28: Accessories

    1 Accessories Name Network video server 12V power adapter Multiple function connector cable data to DB9 male com cable Quick Start Guide...
  • Page 29: General Introduction

    Video Server 1ch / 4ch 2 General Introduction 2.1 Overview This device adopts audio video data collection, transmission and storage. It can connect to the network directly without any auxiliary device. This device uses standard H.264 video compression technology which maximally guarantees the video quality. It can be used alone or used in a network area.
  • Page 30: Specifications

    2.3 Specifications 2.3.1 Function specification Model Ref. 391818 Ref. 391819 Parameter 1-ch analog video input. BNC port. 4-ch analog video input. BNC port. Video input Level: 1.0Vp-p. Resistance: 75Ω Level: 1.0Vp-p. Resistance: 75Ω 1-channel analog video output. BNC port. Level: 1.0Vp-p. Resistance: 75Ω...
  • Page 31 Video Server 1ch / 4ch Specifications Note Support max 6 periods Schedule Record (This series product does not support this function.) After enabling manual record, no matter system is in Manual Record schedule or alarm status or not, system just begins recording Record System automatically enables recording function...
  • Page 32 2.3.3 Factory Default Setup Please refer to the following sheet for factory default setup information. Function configuration type Item Name Default setup Date format Y-M-D Disable by default Date separator ‘ _ ’ Time format General Setup Language English When HDD is full Overwrite Record duration 60 min...
  • Page 33 Video Server 1ch / 4ch Function configuration type Item Name Default setup Snapshot Period 1 : Enable motion detection/alarm Schedule setup Time Setup Week Sunday Option COM01 Function Console Data bit RS232 Setup Stop bit Baud rate 115200 Parity None Ethernet Port 01 DHCP...
  • Page 34 Function configuration type Item Name Default setup Event type Motion detection Channel Ch01, Disable Sensitivity Period: Start time 0:00:00 Time period setup End time:23:59:59 Period 1:enable Week: Sunday Anti-dither 5 seconds Video detection Alarm output Disable Alarm latch 10 seconds Record channel Disable Record latch...
  • Page 35 Video Server 1ch / 4ch Function configuration type Item Name Default setup Snapshot Snapshot_Timing mode Frame rate 1f/s Snapshot Resolution Quality Advanced Auto reboot 2.00 each day Auto maintain Auto delete Never old files 0.0.0.0 Port 7000 221.123.33.228 DNS Setup Alternative DNS 221.12.1.228...
  • Page 36: Framework

    3 Framework 3.1 Front panel Refer to the following sheet for detailed information. Indication light /Port Function / Port Color Note When connected to power: Red When device is working normally: Green Power/working status Red / Green light is on. indication light When device is upgrading: Green light is flashing.
  • Page 37: Rear Panel 1Ch Nvs

    Video Server 1ch / 4ch 3.2 Rear Panel 1ch NVS Refer to the following sheet for detailed information. Port name Connection Function Receive the signal from the front-end device such V-IN Video input port as camera or speed dome Output analog video signal. V-OUT Video output port It can connect to the TV monitor to view video...
  • Page 38: Rear Panel 4Ch Nvs

    3.3 Rear Panel 4ch NVS Refer to the following sheet for detailed information. Port name Connection Function 4 video input ports to receive the signal from Video input port the front-end device such as camera or speed dome. 4 audio input ports to receive the analog Audio input port AVIN audio signal from the pickup or mike.
  • Page 39: Quick Configuration Tool

    Video Server 1ch / 4ch 4 Quick Configuration Tool The quick configuration tool allows you to search for a device's IP address, even if it is in another segment (cameras, DVR, NVR, encoders and decoders) and to modify it. The configuration tool is available on the CD supplied with the product. It also allows the software to be upgraded or certain parameters to be modified.
  • Page 40 To connect to a device and open the web application: - Highlight it (single click in the list). - Right click the highlighted line.   - Click on "Open Device Web". - The following web page opens:   If the connection fails: - either the camera does not have an IP address in the same segment as the PC (see chapter 4.1.2 to change it), - or the Internet Explorer security parameters are not set correctly (see chapter 5 to change them).
  • Page 41 Video Server 1ch / 4ch 4.1.2 Connection with the configuration tool (to change the IP address or upgrade a device’s internal software) To search for devices connected to the network: - Click the «Refresh» button; the tool will search for devices connected to the network and display them in the form of a list (see chapter 4.1.1 for details of the interface).
  • Page 42 - Restart the procedure. The following window should open:   - Click Login to access the parameter modifications.     Function Note Enable DHCP Enable or disable the DHCP function IP address Device IP address Subnet mask Device subnet mask Gateway Device default gateway MAC address...
  • Page 43 Video Server 1ch / 4ch 4.1.3 PPPoE Select "PPPoE" on the right-hand side of the interface:   Function Note Enable PPPOE Enable or disable the PPPoE function User name PPPOE user name Password PPPOE password IP address Device IP address in the WAN Save Save Return...
  • Page 44 4.1.4 System Select "System Information" on the right-hand side of the interface.   Function Note Device serial number Software version Device software version Device name Model name Synchronization Synchronisation of the device date and time with the date and time on the PC. with PC Click "Sync"...
  • Page 45 Video Server 1ch / 4ch 4.1.5 System Upgrade Select "System Upgrade" on the right-hand side of the interface.   Function Note Upgrade file/Open Click here to select the upgrade file. Current progress/Upgrade Click here to start the upgrade procedure. Return Return to search interface Steps for updating the device's internal software - Click on the "Open"...
  • Page 46 - Once the file has been transferred, the device upgrades automatically.   - Once the device has been upgraded, the following dialogue box opens:   - Click OK to finish the procedure.
  • Page 47: Connecting To A Device And Opening The Web Application

    Video Server 1ch / 4ch 5 Connecting to a Device and Opening the Web Application 5.1 PC Configuration This device supports Web access and management via PC. Web includes several modules including monitor channel list, record search, alarm setup, system configuration, PTZ control, monitor window, etc.
  • Page 48: Connection With The Search Tool

    5.2 Connection with the Search Tool To open the software, double click the "ConfigTool.exe" icon on the CD supplied with the product. To search for devices connected to the network: - Click the "Refresh" button; the tool will search for devices connected to the network and display them in the form of a list.
  • Page 49: Connection With Internet Explorer

    Video Server 1ch / 4ch 5.3 Connection with Internet Explorer IP camera factory default setup: - IP address: 192.168.1.108. - User name: admin - Password: admin Open Internet Explorer (IE) and enter your camera IP address in the address bar. For example, if your camera IP is 192.168.1.108, then enter http://192.168.1.108 in the IE address bar.
  • Page 50 After you log in, the main window appears: Note: Use IE compatibility mode if you are using IE8 or above. See the detailed user guide for the Web interface.

This manual is also suitable for:

391819

Table of Contents
