- Page 1 PowerView Motorisation ® Smart shades that simplify your life Quickstart guide The Art of Window Styling...
- Page 2 A brilliant evolution in The Art of Window Styling.
- Page 3 This guide will help you get started with your PowerView® purchase. STEP 1 INSTALL YOUR SHADES Make sure you have properly installed your shades and that they are connected to a power source (battery pack or power Wall Surface supply). STEP 2 YOUR POWERVIEW®...
- Page 4 STEP 3 PAIRING REMOTES If you only have one Remote, please proceed to Step 4. By pairing PowerView® Remotes you make all your Remotes part of the same PowerView® Network. This is important for Stop seamless installation of the PowerView® system. For this instruction you use the STOP button on your Remote.
- Page 5 ”TARGET” REMOTE: PRESS THE RESET BUTTON FOR SIX SECONDS Using a paper clip, PRESS and HOLD recessed Reset reset button button on back of target remote for 6-10 seconds. If necessary, remove back cover. ”TARGET” REMOTE: CLOSE THE COVER IF NECESSARY ”SOURCE”...
- Page 6 ”TARGET” REMOTE: RELEASE STOP (As confirmation “TARGET” Remote will flash the group buttons). ”TARGET” REMOTE: IF THE BUTTONS ARE STILL FLASHING PRESS STOP FOR 6 SECONDS (Keep pressing until the flashing stops).
- Page 7 STEP 4 ADDING A SHADE TO A REMOTE Open A Remote can control 6 groups of shades (which are the Group 1 buttons 1 to 6). Stop The instructions below assign a shade to group 1. Depending on your preference you can choose your own group. This instruction will make use of the OPEN, GROUP 1, and STOP buttons on your Remote.
- Page 8 PRESS STOP FOR 6 SECONDS (Keep pressing until the Remote lights start blinking). PRESS GROUP 1 (This will activate the group 1 on the Remote). PRESS AND HOLD THE SHADE BUTTON PRESS THE OPEN BUTTON (You will see the shade move up and down shortly). RELEASE THE SHADE BUTTON IF YOUR REMOTE IS STILL FLASHING: PRESS STOP...
- Page 9 STEP 5 CONNECT AND SET UP HUB CONNECT POWER TO HUB: CONNECT ONE END OF THE USB POWER CABLE TO THE USB POWER SUPPLY PLUG THE USB POWER SUPPLY INTO AN AC OUTLET OR POWER STRIP Central Hub placement should be considered to obtain optimal range of the Hub.
- Page 10 CONNECT HUB TO INTERNET CONNECTED WIRELESS ROUTER: Connect using an active Wi-Fi network: OPEN THE POWERVIEW® APP ON YOUR MOBILE DEVICE AND FOLLOW THE ON-SCREEN INSTRUCTIONS TO PROPERLY CONNECT TO AN ACTIVE WI-FI NETWORK (The Hub will indicating it is ready to join the PowerView® Network, once the Hub has been connected to the home network).
- Page 11 Network. - Be sure the wall outlet has power. - No more than six Repeaters should be used in a home, unless otherwise instructed by a Luxaflex® PowerView® Motorisation specialist. - Do not place Repeater in direct sunlight. PAIR REPEATER TO POWERVIEW®...
- Page 12 PAIR REPEATER TO POWERVIEW® SHADE NETWORK (IF USING POWERVIEW® REMOTE) - Press and hold STOP on the remote that was used to create the PowerView® Shade Network until the lights on the remote flash (approx. 6 seconds). - With the remote no more than 3 feet from the Repeater, press and release STOP.
- Page 13 STEP 7 PAIRING YOUR HUB WITH AN (EXISTING) POWERVIEW® SHADE NETWORK If you have already established a PowerView® Shade Network between a PowerView® Remote and PowerView® shades, you should pair the Hub to the same network. To pair the Hub to the same network, open the PowerView®...
- Page 14 ADDITIONAL ACTIONS Your PowerView® Network is now setup and ready to be further Open adjusted to your preferences. Follow the steps in this chapter Group 1 or go to www.luxaflex.co.uk/powerview-installation for more information. Stop OPERATE A SHADE Close This instruction will make use of the OPEN, GROUP 1, STOP, ALL and...
- Page 15 SET A FAVOURITE POSITION This instruction will make use of the STOP and FAVOURITE buttons on your Remote. Stop Favourite Find the shade button on your shade. (Different shade types have different shade buttons. Consult the shade documentation for the exact location of the shade button).
- Page 16 MOVE YOUR SHADE TO THE DESIRED FAVOURITE POSITION (Use your OPEN, CLOSE and STOP buttons to move the shade). PRESS STOP FOR 6 SECONDS (Keep pressing until the Remote lights start blinking). PRESS AND HOLD THE SHADE BUTTON PRESS THE FAVOURITE BUTTON (You will see the shade move up and down briefly).
- Page 17 MOVE A SHADE TO A FAVOURITE POSITION This instruction will make use of the GROUP 1, FAVOURITE and ALL button on the Remote. Group 1 Move shades assigned to group 1 to their favourite Favourite position. PRESS GROUP 1 (Group 1 will light up). PRESS FAVOURITE (Shades assigned to group 1 will move to their favourite...
- Page 18 REMOVE A SHADE FROM A GROUP This will remove a shade from a group on your Remote. It will not remove the shade from the PowerView® Network. Group 1 This instruction will make use of the GROUP 1, STOP and Stop CLOSE buttons on the Remote.
- Page 19 The following instruction removes a product from group 1. PRESS STOP FOR 6 SECONDS (Keep pressing until the Remote lights start blinking). BRIEFLY PRESS ON GROUP 1 (This will activate the group 1 on the Remote). PRESS AND HOLD THE SHADE BUTTON BRIEFLY PRESS ON CLOSE (You will see the shade move up and down shortly).
- Page 20 INSTALL A SCENE CONTROLLER The Scene Controller works in combination with the App and can activate scenes which are created in the App. START THE APP AND OPEN THE SIDE MENU SELECT ACCESSORIES AND SCENE CONTROLLERS AND FOLLOW THE INSTRUCTIONS IN THE APP...
- Page 22 Smart design makes the difference.
- Page 24 A revolutionary new system that automatically moves your shades throughout the day, so you don’t have to. All rights reserved. Unauthorised copying is prohibited. Technical data subject to change without notice. No rights can be derived from copy, text pertaining to illustrations or samples.
