BL2000B
Doosan purchased Bobcat Company from Ingersoll-Rand Company in
2007. Any reference to Ingersoll-Rand Company or use of trademarks,
service marks, logos, or other proprietary identifying marks belonging
to Ingersoll-Rand Company in this manual is historical or nominative
in nature, and is not meant to suggest a current affiliation between
Ingersoll-Rand Company and Doosan Company or the products of
either.
This manual contains important safety information.
Do not destroy this manual.
This manual must be available to all personnel who operate and maintain this device.
4900059 (04-06)
Revised (01-13)
Operation and
Maintenance
Manual
April 2006

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BL2000B and is the answer not in the manual?

Questions and answers

Summary of Contents for Ingersoll-Rand BL2000B

  • Page 1 Maintenance Manual Doosan purchased Bobcat Company from Ingersoll-Rand Company in 2007. Any reference to Ingersoll-Rand Company or use of trademarks, service marks, logos, or other proprietary identifying marks belonging to Ingersoll-Rand Company in this manual is historical or nominative in nature, and is not meant to suggest a current affiliation between Ingersoll-Rand Company and Doosan Company or the products of either.
  • Page 2 Any modification of the part is absolutely prohibited and would result in the CE Certification and Marking being rendered invalid. A declaration of that conformity follows : DECLARATION OF CONFORMITY WITH EC DIRECTIVES 89/336/EEC Ingersoll-Rand Company Ingersoll-Rand European Sales Represented in EC by: Company Limited P.O. Box 868 Swan Lane, Hindley Green...
  • Page 3 Warranty..................................17 Foreword The contents of this manual are considered to be proprietary and confidential to Ingersoll-Rand and should not be reproduced without the prior written permission of Ingersoll-Rand. Nothing contained in this document is intended to extend any promise, warranty or representation, expressed or implied, regarding the Ingersoll-Rand products described herein.
  • Page 4 Foreword Balloon Light BL2000B 4900059 (04-06) Operation and Maintenance Manual...
  • Page 5: General Safety Information

    Use the glove provided. Do not cut the electric cable. Transport Do not switch on the Balloon BL2000B if the cable is wound up. Transport the Balloon BL2000B in its storage bag. Make sure that the tripod is stable and firmly anchored in windy conditions.
  • Page 6 Safety Balloon Light BL2000B 4900059 (04-06) Operation and Maintenance Manual...
  • Page 7 List of parts ................................6 Assembly and installation..............................7 Unfolding the envelope ............................7 Assembling (bulb installation) ..........................7 Installing the Balloon BL2000B ..........................8 Inflating and switching on the Balloon BL2000B.....................8 Disassembly..................................8 Switching off and deflating ............................8 Folding and storing ..............................8 4900059 (04-06) Balloon Light BL2000B...
  • Page 8: List Of Parts

    Operating Instructions Overview The Balloon BL2000B is an illumination device specifically List of parts designed for night work inside and outside to assist during rescue, safety, worksite operations etc. Figure 2 Identification of elements Figure 1 S1735 Reference Description 1 Envelope...
  • Page 9: Assembly And Installation

    3. Remove the protective bowl from the fan part. of glass. Figure 4 Use a vacuum cleaner to clean the equipment. Be careful not to cut your fingers when handling the fragments of glass. S1711 4900059 (04-06) Balloon Light BL2000B Operation and Maintenance Manual...
  • Page 10 Operating Instructions Installing the Balloon BL2000B Disassembly 1. Install the Balloon BL2000B on the telescopic pole. Switching off and deflating 2. The equipment is now ready for inflation. 1. Disconnect the Balloon BL2000B from its power supply. WARNING 2. Wait 5 minutes for the bulbs to cool down.
  • Page 11: Maintenance

    Regularly clean the envelope with soapy water or alcohol. Replacement To replace a bulb, refer to “Assembling (bulb installation)” on page 7. 4900059 (04-06) Balloon Light BL2000B Operation and Maintenance Manual...
  • Page 12: Air Filter

    Power supply cable Fabric grip ring 5. Procede in reverse order to install the new envelope. Make sure that the bottom side of the envelope is properly sealed by the fabric grip ring. Balloon Light BL2000B 4900059 (04-06) Operation and Maintenance Manual...
  • Page 13: Fault Finding

    2 PINS (TIP) 10/16A 3G 1.5mm² HO7RNF CABLE TERMINAL LOCABLE PLUG SAFETY TERMINAL SWITCH 120°C FIT IN FRONT OF THE LAMP (TIP) JUNCTION TERMINAL LAMP WIRES: 2.5mm² SILICONE WAGO 222-415 S3554 4900059 (04-06) Balloon Light BL2000B Operation and Maintenance Manual...
  • Page 14 SOLUTION SOLUTION SOLUTION Close zip Repair the Replace the Connect to Change the envelope bulbs another fuse on the power source south pole Type of product CONSULT YOUR DISTRIBUTOR S1717 Balloon Light BL2000B 4900059 (04-06) Operation and Maintenance Manual...
  • Page 15: General Specifications

    Average lamp life 2000 h Weight balloon 10 kg Inflation time 45 s Wind speed resistance 100 km/h (62 mp/h) Surface area lit 1 400 m 2000 S1701 Dimensions see [Figure 12] 4900059 (04-06) Balloon Light BL2000B Operation and Maintenance Manual...
  • Page 16 Specifications Balloon Light BL2000B 4900059 (04-06) Operation and Maintenance Manual...
  • Page 17: Spare Parts

    Repair Kit (2 self adhesives leaves) 17126152 Polycarbonate Bowl * Not showed 17126160 Connector Clip 17126178 Clip, Light Harness 18034330 Temperature Sensor 16534299 Inox Springs 18034348 R7S Kit 18034355 500W R7S Lamp 4900059 (04-06) Balloon Light BL2000B Operation and Maintenance Manual...
  • Page 18: Internal Equipment

    South Pole Plate 18034678 Leveling Leg 18034504 Protection Ring 18034686 Set of 2 bars 17126293 Mount Pole 18034694 Inferior plate 18034512 Cable + Plug Euro 18034520 Cable + Plug UK 17126301 Pole Mounting Balloon Light BL2000B 4900059 (04-06) Operation and Maintenance Manual...
  • Page 19: Warranty Registration

    General IMPORTANT Ingersoll-Rand, through its distributors, warrants to the initial user that each BL2000B, will be free of defects in THIS WARRANTY IS IN LIEU OF ALL OTHER WAR- material and workmanship for a period of twelve (12) RANTIES EXPRESSED OR IMPLIED, (EXCEPT THAT months from shipment to the initial user.
  • Page 20: Warranty Registration Form

    • The warranty and limitation of liability has been reviewed and understood by the owner/user. • Ingersoll-Rand reserves the right to make design changes or modifications of Ingersoll-Rand products at anytime without incurring any obligation to make similar changes or modifications on previously sold units.
