Connecting an External PC

To display video and sound from an external PC follow the instruc�ons below:
1.
Note: External PCs can also be connected to the display via HDMI cable.
• Connect a VGA cable (15-pin) from your external PC to the VGA IN port on the display.
• Connect an audio cable from the AUDIO OUT port on your external PC to the AUDIO IN port on
the display.
Connect a USB cable to the external PC from the TOUCH OUT port of the display.
2.
Note: For op�mal results, select 1920x1080p as the external computer's input resolu�on.
TOUCH2
VGA
AUDIO IN
RS232 Connections
When you use an RS232 serial port cable to connect your display to an external computer, certain
func�ons can be controlled by the PC, including power on/off, volume adjustment and more.
RS232
Serial Port Cable
