Summary of Contents for German pool 450 Slim Series
Page 1
DWH-221 450 Slim Series Built-In Dishwasher Online Warranty Registration Please read these instructions and warranty information carefully before use and keep them handy for future reference. U S E R M A N U A L...
Content Content Important Safety Instructions Quick User Guide Product Structure Using Your Dishwasher Operation Instructions Control Panel Loading The Salt Into The Softener Operation (Button) Basket Used Tips Display Maintenance and Cleaning Water Softener External Care Preparing And Loading Dishes Internal Care Function Of The Rinse Aid And Detergent Caring For The Dishwasher...
Important Safety Instructions Important Safety Instructions • Do not place any heavy objects on or stand on the door when it is open. The appliance could tip Warning! When using your dishwasher, follow the precautions listed below: forward. • This appliance is intended to be used in household and similar applications such as: •...
Product Structure Operation Instructions Before using your dishwasher: IMPORTANT To get the best performance from your dishwasher, read all operating instructions before using it for the first time. Inside Outside Top spray arm Watch the video clip A. Set the water softener B.
Operation Instructions Operation Instructions 1. Remove the lower basket and unscrew the reservoir cap. 2. Place the end of the funnel (supplied) into the hole and pour in about 1.5kg of dishwasher salt. 3. Fill the salt container to its maximum limit with water, It is normal for a small amount of water to come out of the salt container.
Maintenance and Cleaning Maintenance and Cleaning External Care Internal Care Watch the video clip The door and the door seal Filtering system Clean the door seals regularly with a soft damp cloth to remove food deposits. The filtering system in the base of the wash cabinet retains coarse debris from the washing cycle. The When the dishwasher is being loaded, food and drink residues may drip onto collected coarse debris may cause the filters to clog.
Maintenance and Cleaning Maintenance and Cleaning Caring For The Dishwasher Warning Frost precaution • Do not over tighten the filters. Put the filters back in sequence securely, otherwise coarse Please take frost protection measures on the dishwasher in winter. After washing cycles, please debris could get into the system and cause a blockage.
Installation Instructions Installation Instructions How to Connect the AQUASTOP Safety Supply Hose Warning! Electrical Shock Hazard The appliance must be connected to the water mains using new hose-sets. The old hose-sets should not be reused. Disconnect electrical power before installing dishwasher. Water pressure must be between 0.04 MPa and 1 MPa.
Installation Instructions Installation Instructions How to drain excess water from hoses Built-In Installation (For The Integrated Model) If the sink is 1000mm higher from the floor, the excess water in hoses cannot be drained directly into the Step 1. Selecting the best location for the dishwasher sink.
Page 10
Installation Instructions Installation Instructions Step 2. Aesthetic panel’s dimensions and installation Step 3. Tension adjustment of the door spring The aesthetic wooden panel could be processed according to the installation drawings. 1. The door springs are set at the factory to the proper tension for the outer door. If aesthetic wooden panel are installed, you will have to adjust the door spring tension.
Page 11
Installation Instructions Troubleshooting Before Calling for Service Review the charts on the following pages may save you from calling for service. Problem Possible Causes Solution Shut the door completely and make sure it is Dishwasher won’t start latched Dishwasher Power supply or power line Check and connect the power supply doesn’t start is not connected Delay...
Troubleshooting Troubleshooting Problem Possible Causes Solution Problem Possible Causes Solution Detergent dispenser is Fill rinse aid dispenser or increase the amount of Black or gray Aluminum utensils have Rearrange the dishes Make sure the inlet water is empty rinse aid marks on dishes rubbed against dishes no less than 120H...
Loading The Baskets According To EN50242 Loading The Baskets According To EN50242 1. Upper basket 3.Cutlery basket: Number Item Number Item Soup spoons Cups Forks Saucers Knives Glasses Teaspoons Small serving bowl Dessert spoons Medium serving bowl Serving spoons Large serving bowl Serving forks Gravy ladles Information for comparability tests...
Quick User Guide Loading The Baskets According To EN50242 Cutlery Rack Used Tips Please read the corresponding content on the instruction manual for detailed operating method. Lift the left basket up, adjust it to lower position, left basket is flat and right basket is sideling. Lift the right basket up, both left and right baskets are flat.
Using Your Dishwasher Using Your Dishwasher Control Panel This is the standard program suitable for normally soiled loads, such as pots, plates, glasses and lightly soiled pans. For lightly soiled crockery and glass. Glass Program For normally soiled loads that need quick wash. indicator 90 Min A shorter wash for lightly soiled loads that do not need...
Using Your Dishwasher Using Your Dishwasher Water Softener NOTE: If your model does not have any water softener, you may skip this section. The water softener must be set manually, using the water hardness dial. The water softener is designed to remove minerals and salts from the water, which would have a Water Softener detrimental or adverse effect on the operation of the appliance.
Page 17
Using Your Dishwasher Using Your Dishwasher Recommendations for loading the dishwasher Loading the upper basket Scrape off any large amounts of leftover food. Soften remnants of burnt food in pans. It is not The upper basket is designed to hold more delicate and necessary to rinse the dishes under running water.
Using Your Dishwasher Using Your Dishwasher Function Of The Rinse Aid And Detergent Filling The Rinse Aid Reservoir The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can leave spots and streaks. It also improves drying by allowing water to roll off the dishes. Your dishwasher is designed to use liquid rinse aids.
Using Your Dishwasher Programming The Dishwasher Filling The Detergent Dispenser Wash Cycle Table The table below shows which programs are best for the levels of food residue on them and how much detergent is needed. It also show various information about the programs. ( ) Means: need to fill rinse into the Rinse-Aid Dispenser.
Programming The Dishwasher Programming The Dishwasher Forget To Add A Dish? Starting A Cycle Wash A forgotten dish can be added any time before the detergent dispenser opens. If this is the case, follow 1. Draw out the lower and upper basket, load the dishes and push them back. the instructions below: It is commended to load the lower basket first, then the upper one.
Technical Specifications Error Codes If there is a malfunction, the dishwasher will display error codes to identify these: Model No. DWH-221 Codes Meanings Possible Causes Rated Voltage/Frequency 220-240V~/50Hz Faucets is not opened, or water intake is Rated Power 1930W Longer inlet time. restricted, or water pressure is too low.
- the serial number is modified, damaged or removed from 本說明書的以上注意事項基於歐盟的標準和規則。 the product. - 機身編號被擅自塗改、破壞或刪除。 4. German Pool will, at its discretion, repair or replace any 4. 總代理有權選擇維修或更換配件或其損壞部份。 defective part. 5. This warranty will be void if there is any transfer of 5.
