LOCKABLE WALL CABINET
MODEL NO: CWC50
PART NO: 7640020
ASSEMBLY
INSTRUCTIONS
ORIGINAL INSTRUCTIONS
GC1118 - Issue 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CWC50 and is the answer not in the manual?

Questions and answers

Summary of Contents for Clarke CWC50

  • Page 1 LOCKABLE WALL CABINET MODEL NO: CWC50 PART NO: 7640020 ASSEMBLY INSTRUCTIONS ORIGINAL INSTRUCTIONS GC1118 - Issue 2...
  • Page 2: Specification

    INTRODUCTION Thank you for purchasing this CLARKE product. Before assembling the cabinet be sure to read these instructions thoroughly. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service.
  • Page 3: Component Parts

    COMPONENT PARTS Description No Description Large loose items Smaller items in sealed packet Back Panel Door Lock set inc key Top/Bottom Panel Bolt (M5 x 10mm) Dividing Panel M5 Nut End Panel Washer 5mm Door Panel Bolt (M4 x 10mm) Shelf Panel Nut M4 Wall Hanging Bracket...
  • Page 4: Safety Precautions

    2. Periodically inspect the unit to ensure it is in good condition, replace any damaged parts. 3. If replacing any parts, only use those supplied by Clarke International, referring to the parts list on page 3. Please keep these instructions in a safe place for future reference.
  • Page 5 3. Place the top panel in position on the assembly as shown in Fig 3, so that the edge with the return fold lies at the front, and secure loosely to both the rear and dividing panels with an M5 bolt, washer and nut.
  • Page 6 7. Attach the left hand door by inserting the pivot pins into the pivot holes in the top and bottom panels. • When inserting the door into the pivot holes you may need to loosen or temporarily remove the bolts close to the pivot points to be able to guide the door pivots into the holes.
  • Page 7: Spare Parts

    12. Attach the wall hanging brackets to the back panels as shown in Fig 11, using the M4 bolts, nuts and washers provided. • The brackets should not be in the centre of the back panels but slightly towards the middle of the cabinet., nearer the divisions.
