- Page 1 User Manual Global Control 5 Sp. z o.o. Warsaw, Poland www.gc5.pl...
-
Page 2: Table Of Contents
Table of contents Introduction ................................. 3 Revision history .................................. 3 Safety rules ..................................4 EN 55022:2010+AC:2011 ..............................5 EN 61000-3-2:2014 ................................5 EN 61000-3-3:2013 ................................5 EN 55024:2010 + A1:2015 ............................... 5 EN 60950-1:2006 + A11:2002 + A1:2010 + A12:2011 + A2:2013 ................5 Technical specifications .............................. -
Page 3: Introduction
1 Introduction Revision history Date Description 2019.07.18 First edition Table 1. Revision history version 1.0 www.gc5.pl Page 3 /14... -
Page 4: Safety Rules
Safety rules Note: Incorrect wiring of this product can damage it and lead to other hazards. Make sure, the product has been correctly wired before turning the power ON. Before wiring, or removing/mounting the product, be sure to turn the power OFF. -
Page 5: 55022:2010+Ac:2011
EN 55022:2010+AC:2011 Electromagnetic compatibility of multimedia equipment. Emission Requirements. EN 61000-3-2:2014 Electromagnetic compatibility (EMC). Limits for harmonic current emissions for equipment input current ≤ 16 A per phase). EN 61000-3-3:2013 Electromagnetic compatibility (EMC). Limits for voltage changes, voltage fluctuations and flicker in public low-voltage supply systems, for equipment with rated current ≤... -
Page 6: Technical Specifications
Technical specifications Panel type Industrial TFT LCD Android 7.1 Operating system LED ; Backlight lifetime ≥50000h, Screen type Size 10.1’’/15.6” Aspect Ratio 16:9 Resolution 1366x768 Luminance 300nit, up to 800nit/300nit, up to 1000nit Contrast 800:1/1000:1 222.7x125.2 mm / 344.2x193.6 mm Active Area 16.7M... -
Page 7: Dimensions
Dimensions Figure 1. Dimensions of 10.1” Figure 2 Dimensions of 15.6 version 1.0 www.gc5.pl Page 7 /14... -
Page 8: Interface Details
1.10 Interface Details The Monitor will recognize and select the signal automatically. An exception is USB in OTG Mode, you need to set USB port to OTG Mode. Full instruction in point 1.11 Figure 2. DC power supply connection of 10.1”... - Page 9 Go to settings Figure 4 Settings Go to developer options Figure 5 Developer options Set USB Mode to OTG Mode and turn on USB debugging version 1.0 www.gc5.pl Page 9 /14...
-
Page 10: Operation Guide
Figure 6 USB Mode and USB debugging Set USB Configuration to MTP Figure 7 Select USB Configuration 2 Operation Guide Rear navigation buttons The buttons are used to turn the device on and off. Brightness +/- buttons are prepared for version 1.0... -
Page 11: Setting Static Ip Address
Figure 8. Rear navigation buttons Symbol Name Using instruction Brightness +/- Choose + Buttons prepared for future development Brightness +/- Choose - On/Off On/Off button Start-up/Shut down the monitor. You need to press the button for a few seconds for both turning on and off. - Page 12 2. Go to More Figure 9 Settings - More 3. Go to Ethernet Figure 10 Ethernet 4. Go to Ethernet Ip mode Figure 11 Ethernet Ip mode 5. Choose static version 1.0 www.gc5.pl Page 12 /14...
-
Page 13: Installation
Figure 12 Setting Ethernet Ip mode 6. Insert IP address and other information and click CONNECT Figure 13 Inserting Ethernet information 3 Installation Do not place the monitor next to the radiator or heat source. Do not let any objects press or twine around the power cable or VGA cable. -
Page 14: Wall-Mount Installation
Figure 8. Embed with snap joint Installation Wall-mount Installation Figure 3. Wall-mount Installation version 1.0 www.gc5.pl Page 14 /14...
