USER MANUAL
QFT-7
Folding Bicycle
RILU Trading Pty
Unit 2, No 2 Caulson Close
Maribyrnong 3032
Melbourne, Victoria
(03) 8395 2616
info@rilu-e-bike.com.au
Rev. QF7T-UM.A4.12092019-FINAL
(03) 8395 2616
P a g e
Australia
www.rilu-e-bike.com.au
| 1
Product Description
Riding Range & Load Weight
Product Summary
General Usage Summary
Turning your Q-F7T (ON/OFF)
PAS – Default Motor Assistance Level
Front & Rear lights (ON/OFF)
PAS - Turn OFF Motor Assistance
PAS - Motor Assistance MAX
6km/h - Walk Assist Function
Understanding Battery Capacity Meter
Battery LOW – Flashing Wanning
Step by step guide to folding your bike
Servicing your folding lock
Gear Adjustment – Uneven Shifting
Gear Alignment – Gear #7
Gear Alignment – Gear #1
(03) 8395 2616
P a g e
Introduction
Page
Page
Page
Page
Display
Page
Page
Page
Page
Page
Page
Page
Page
Folding
Page
Page
Gearing
Page
Page
Page
www.rilu-e-bike.com.au
| 2
4
5
6
7
8
9
9
10
10
10
11
12
13
17
19
20
21

Advertisement

loading
Need help?

Need help?

Do you have a question about the e-Bike QFT-7 and is the answer not in the manual?

Questions and answers

Related Manuals for Rilu e-Bike QFT-7

Summary of Contents for Rilu e-Bike QFT-7

  • Page 1 Step by step guide to folding your bike Page Servicing your folding lock Page QFT-7 Gearing Folding Bicycle RILU Trading Pty Gear Adjustment – Uneven Shifting Page Unit 2, No 2 Caulson Close Gear Alignment – Gear #7 Page Maribyrnong 3032 Melbourne, Victoria Gear Alignment –...

  • Page 2: Product Description

    LED / 3 Modes (Motor Power – L/M/H) Pedal Sensor – Repair Page Battery: 36 V / 10.4AH (Lithium Ion) Thumb Throttle Page Charger: 36V / 2A (Smart charger) Lights: Front & Rear (eBike battery power) (03) 8395 2616 (03) 8395 2616 www.rilu-e-bike.com.au www.rilu-e-bike.com.au...
  • Page 3 P a g e P a g e Riding Range & Charge Time Product Summary Range depending on: Congratulation on your purchase of a RILU Q-F7T Folding Rider, terrain, weather & level of assistance. electric bicycle. Throttle 30Km+ Your new electric bicycle has two different ways of 50Km+ activating motor power.
  • Page 4 P a g e P a g e General Usage Summary Turning Q-F7T (ON & OFF) RILU recommends you first ride the bike without using any electrical assistance to familiarize yourself with the mechanical gearing and breaking system of your Q-F7T. TURN HOLD “M”...
  • Page 5 Press “ + ” 6Km/h – Walk Assist Function HOLD “ + ” Only use ‘Walk Assist’ when you are walking the bike, do not use while sitting on the bike. Hold “ - ” (03) 8395 2616 (03) 8395 2616 www.rilu-e-bike.com.au www.rilu-e-bike.com.au...

  • Page 6: Understanding Battery Capacity Meter

    When the motor is under heavy load the POWER gauge LEDs will ‘sag’ showing an underestimated capacity reading. The gauge will correct itself after the heavy load is lifted. (03) 8395 2616 (03) 8395 2616 www.rilu-e-bike.com.au www.rilu-e-bike.com.au...
  • Page 7 Step 4 - Unlock ‘Folding Safety Latch’ TWIST SEATPOST TO LOWER SEAT GROUND Step 2 - Fold pedals Reduces risk of damaged during transport and storage Step 5 - Pull ‘Folding Lever’ forward PULL Forward (03) 8395 2616 (03) 8395 2616 www.rilu-e-bike.com.au www.rilu-e-bike.com.au...
  • Page 8 Step 9 - Carry using two hands Hand 1 - Rear of bike rack ● Hand 2 - Folded bike frame ● HAND Step 7 - Stand behind the folding lock HAND (03) 8395 2616 (03) 8395 2616 www.rilu-e-bike.com.au www.rilu-e-bike.com.au...
  • Page 9 Over time you may need to adjust the folding clamp if you are unable RILU advises using a bike service stand when performing gearing and to fully close the clamp before riding or if the folding lock is loose and breaking adjustments.
  • Page 10 If you experience uneven shifts or slippage in the lower gears, where the chain jumps from gear #2 to gear #3 unintentionally. Try to adjust the derailleur using the following method to improve shifting. (03) 8395 2616 (03) 8395 2616 www.rilu-e-bike.com.au www.rilu-e-bike.com.au...
  • Page 11 Cut - Cable Tie Unplug - Motor Cable Step 3 Step 4 5mm Allen - Release Brakes Check Brake Pad Free Step 5 Step 6 18mm Spanner Pull back derailleur Step 7 Step 8 (03) 8395 2616 (03) 8395 2616 www.rilu-e-bike.com.au www.rilu-e-bike.com.au...

  • Page 12: Battery Removal

    Pull away from frame Battery – Installation Battery – Removal Battery pushed too far inside. No Gap OK The lock is unable to fully turn. Flush with edge Not installed correctly correctly installed (03) 8395 2616 (03) 8395 2616 www.rilu-e-bike.com.au www.rilu-e-bike.com.au...
  • Page 13 DO NOT cover the charger, nor the battery during charging. Battery – Storage Guide Battery – Charging Error Battery (RED) & Charger (GREEN) Contact your dealer for support if you experience the above issue or if battery not receiving charge. (03) 8395 2616 (03) 8395 2616 www.rilu-e-bike.com.au www.rilu-e-bike.com.au...
  • Page 14 Pedalling will cause the Disk to rotate, the sensor is able to folding your eBike detect the rate (cadence) at which you are pedalling. <5mm Pedal Assist Sensor Rotation Disk (03) 8395 2616 (03) 8395 2616 www.rilu-e-bike.com.au www.rilu-e-bike.com.au...
  • Page 15 | 30 Dealer Notes Thumb Throttle – Location & Function RILU advises riders to avoid ‘hard starts’ that involve applying full throttle while on an incline. RILU recommends to have the bike in motion before engaging the throttle to prolong the life of the gears inside the motor.

  • Page 16: Customer Notes

    P a g e | 31 P a g e | 32 Customer Notes (03) 8395 2616 (03) 8395 2616 www.rilu-e-bike.com.au www.rilu-e-bike.com.au...
  • Page 17 P a g e | 33 P a g e | 34 (03) 8395 2616 (03) 8395 2616 www.rilu-e-bike.com.au www.rilu-e-bike.com.au...
  • Page 18 P a g e | 35 (03) 8395 2616 www.rilu-e-bike.com.au...
