- Page 1 P a g e USER MANUAL QFT-7 Folding Bicycle RILU Trading Pty Unit 2, No 2 Caulson Close Maribyrnong 3032 Melbourne, Victoria Australia (03) 8395 2616 info@rilu-e-bike.com.au Rev.18.5409.QF7-UM (03) 8395 2616 www.rilu-e-bike.com.au...
-
Page 2: Table Of Contents
Battery LOW – Flashing Wanning Page Folding Step by step guide to folding your bike Page Servicing your folding lock Page Gearing Gear Adjustment – Uneven Shifting Page Gear Alignment – Gear #7 Page Gear Alignment – Gear #1 Page (03) 8395 2616 www.rilu-e-bike.com.au... - Page 3 Motor – Changing Tire Page Motor – Service Notes Page Battery Removing battery from inside frame Page Charger Page Battery Storage Page Sensors Pedal Sensor – Location Page Pedal Sensor – Repair Page Thumb Throttle Page (03) 8395 2616 www.rilu-e-bike.com.au...
-
Page 4: Product Description
36V / 200 W (Thumb + PAS) Display: LED / 3 Modes (Motor Power – L/M/H) Battery: 36 V / 10.4AH (Lithium Ion) Charger: 36V / 2A (Smart charger) Lights: Front & Rear (eBike battery power) (03) 8395 2616 www.rilu-e-bike.com.au... - Page 5 Riding Range & Charge Time Range depending on: Rider, terrain, weather & level of assistance. Throttle 30Km+ 50Km+ Battery charge time is 4-5 Hours Weight 17.8 Kg (Bike) net weight 19.5Kg (Battery Installed) QF7-T Rated Load weight is 120Kg (03) 8395 2616 www.rilu-e-bike.com.au...
-
Page 6: Product Summary
P a g e Product Summary Congratulation on your purchase of a RILU Q-F7T Folding electric bicycle. Your new electric bicycle has two different ways of activating motor power. Throttle Located on the right hand side of the handlebar is a thumb triggered throttle which enables you to control the speed of the motor, without the need for pedalling. -
Page 7: General Usage Summary
P a g e General Usage Summary RILU recommends you first ride the bike without using any electrical assistance to familiarize yourself with the mechanical gearing and breaking system of your Q-F7T. (03) 8395 2616 www.rilu-e-bike.com.au... - Page 8 Can’t power on your display? Check the battery power switch. Ensure its set to the ON position. You only need to turn off the battery when not using the Q-F7Tfor long period of time (longer than one month) (03) 8395 2616 www.rilu-e-bike.com.au...
- Page 9 P a g e Default Motor Assistance Level Turn “ON” Riding LED lights HOLD “ + ” (03) 8395 2616 www.rilu-e-bike.com.au...
- Page 10 Q-F7T. Press “ + ” 6Km/h – Walk Assist Function Only use ‘Walk Assist’ when you are walking the bike, do not use while sitting on the bike. Hold “ - ” (03) 8395 2616 www.rilu-e-bike.com.au...
-
Page 11: Understanding Battery Capacity Meter
When the motor is under heavy load the POWER gauge LEDs will ‘sag’ showing an underestimated capacity reading. The gauge will correct itself after the heavy load is lifted. (03) 8395 2616 www.rilu-e-bike.com.au... - Page 12 P a g e | 12 Battery Low – Flashing Warning When battery LED is Flashing Battery charge level is <10%. It is critical that you recharge within 24 hours to avoid any damage to the battery. (03) 8395 2616 www.rilu-e-bike.com.au...
- Page 13 This will enable the seat post to act as a balance leg assisting the bike to keep upright when folded SEATPOST TO LOWER SEAT GROUND Step 2 - Fold pedals Reduces risk of damaged during transport and storage (03) 8395 2616 www.rilu-e-bike.com.au...
- Page 14 P a g e | 14 Step 3 - Align the pedals Chain side – Pointing to the back of the bike. Step 4 - Unlock ‘Folding Safety Latch’ TWIST Step 5 - Pull ‘Folding Lever’ forward PULL Forward (03) 8395 2616 www.rilu-e-bike.com.au...
- Page 15 P a g e | 15 Step 6 - Fold handlebar stem ● Release (UP) (Stem lock) ● Fold (DOWN) (Stem latch) Step 7 - Stand behind the folding lock (03) 8395 2616 www.rilu-e-bike.com.au...
- Page 16 P a g e | 16 Step 8 - Fold the bike in half Step 9 - Carry using two hands ● Hand 1 - Rear of bike rack ● Hand 2 - Folded bike frame HAND HAND (03) 8395 2616 www.rilu-e-bike.com.au...
- Page 17 Adjusting - Folding Clamp Over time you may need to adjust the folding clamp if you are unable to fully close the clamp before riding or if the folding lock is loose and doesn’t grip the frame. LOOSEN TIGHTEN (03) 8395 2616 www.rilu-e-bike.com.au...
-
Page 18: Gearing
P a g e | 18 Adjusting - Gear Quick Adjustment RILU advises using a bike service stand when performing gearing and breaking adjustments. It will be easier when the bike is raised off the ground. Electric bicycles are heavier than regular bicycles please ensure your... - Page 19 Gearing Adjustment - Uneven Shifting / Slipping If you experience uneven shifts or slippage in the lower gears, where the chain jumps from gear #2 to gear #3 unintentionally. Try to adjust the derailleur using the following method to improve shifting. (03) 8395 2616 www.rilu-e-bike.com.au...
- Page 20 P a g e | 20 Gearing Adjustment – Gear #7 Pulley Alignment (03) 8395 2616 www.rilu-e-bike.com.au...
- Page 21 P a g e | 21 Gearing Adjustment – Gear #1 Pulley Alignment (03) 8395 2616 www.rilu-e-bike.com.au...
- Page 22 Step 2 Cut - Cable Tie Unplug - Motor Cable Step 3 Step 4 5mm Allen - Release Brakes Check Brake Pad Free Step 5 Step 6 18mm Spanner Pull back derailleur Step 7 Step 8 (03) 8395 2616 www.rilu-e-bike.com.au...
- Page 23 P a g e | 23 Motor – Service Notes (03) 8395 2616 www.rilu-e-bike.com.au...
- Page 24 Pinch the battery Pull away from frame Battery – Installation Battery – Removal Battery pushed too far inside. No Gap OK The lock is unable to fully turn. Flush with edge Not installed correctly correctly installed (03) 8395 2616 www.rilu-e-bike.com.au...
- Page 25 DO NOT cover the charger, nor the battery during charging. Battery – Charging Error Battery (RED) & Charger (GREEN) Contact your dealer for support if you experience the above issue or if battery not receiving charge. (03) 8395 2616 www.rilu-e-bike.com.au...
- Page 26 P a g e | 26 Battery – Charging Steps Battery – Storage Guide (03) 8395 2616 www.rilu-e-bike.com.au...
- Page 27 Wedged between the chain wheel and the bottom bracket is the “Pedal Assist Sensor” and the “Rotation Disk”. Pedalling will cause the Disk to rotate, the sensor is able to detect the rate (cadence) at which you are pedalling. Pedal Assist Sensor Rotation Disk (03) 8395 2616 www.rilu-e-bike.com.au...
- Page 28 If you are pedalling while in mode (low/med/high) and are not receiving automatic motor assistance or experiencing intermittent motor power please inspect the “pedal assist sensor” and the “rotation disk” alignment as it is possible to knock and bend the sensor when folding your eBike <5mm (03) 8395 2616 www.rilu-e-bike.com.au...
- Page 29 P a g e | 29 Thumb Throttle – Location & Function RILU advises riders to avoid ‘hard starts’ that involve applying full throttle while on an incline. RILU recommends to have the bike in motion before engaging the throttle to prolong the life of the gears inside the motor.
