- Page 1 LoRaWAN US915 PULSE Transceiver pulse interfaces Guide utilisateur / User Guide Version 1.0.0 Adeunis 283 rue Louis Néel - Parc Technologique Pré Roux 38920 CROLLES - France www.adeunis.com...
-
Page 2: Documentation
LoRaWAN US915 PULSE - User guide version V1.0.0 DOCUMENTATION • Dedicated to a product • Cautions & electrical warnings USER GUIDE • Declaration of conformity • Product functionalities and modes • Casing dimensions • Characteristics (casing and electrical) • LED explanations •... - Page 3 LoRaWAN US915 PULSE - User guide version V1.0.0 Préambule / Preamble / Präambel / Preambolo / Preámbulo • Ce guide décrit les fonctionnalités du produit adeunis®. Il explique les modes de fonctionnement du produit et la manière de le confi gurer. •...
-
Page 4: Table Of Contents
LoRaWAN US915 PULSE - User guide version V1.0.0 Table of content Documentation INFORMATIONS PRODUCT PRESENTATION 1.1. General description 1.2. Dimensions 1.3. Electronic card 1.4. Technical Specifications 1.4.1 General characteristics 1.4.2 Autonomy 1.4.3 Sensor compatibility 1.4.4 Physical interface characteristics 1.4.4.01 INPUT Circuit 1.4.4.02 TAMPER Circuit PRODUCT OPERATION... -
Page 5: Informations
LoRaWAN US915 PULSE - User guide version V1.0.0 INFORMATIONS Document Information Title LoRaWAN PULSE - User guide Sub-title Version 1.0.0 Document type User Guide This document applies to the following products : Name Reference Firmware version LoRaWAN PULSE ARF8230B Version RTU : V01.07.01 Version APP : V02.00.00 DISCLAIMER This document and the use of any information contained therein, is subject to the acceptance of the adeunis®... - Page 6 LoRaWAN US915 PULSE - User guide version V1.0.0 COMPLIANCE TO FCC US/CAN • This device complies with part 15 of the FCC rules and Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1). this device may not cause Harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation of the device.
- Page 7 LoRaWAN US915 PULSE - User guide version V1.0.0 INTRODUCTION All rights to this manual are the exclusive property of adeunis®. All rights reserved. Copying this manual (wit- hout written permission from the owner) via printing, copying, recording or by any other means, translating this manual (in full or partially) into any other language, including all programming languages, using any electrical, mechanical, magnetic or optical devices, manually or any by other methods, is prohibited.
- Page 8 LoRaWAN US915 PULSE - User guide version V1.0.0 ENVIRONMENTAL RECOMMENDATIONS All superfl uous packaging materials have been eliminated. We have done everything possible to make it easy to separate the packaging into three types of materials: cardboard (box), expanded polystyrene (fi ller material) and polyethylene (packets, foam protective sheets).
- Page 9 LoRaWAN US915 PULSE - User guide version V1.0.0 RECOMMANDATIONS REGARDING USE • Before using the system, check that the power supply voltage shown in the user manual corresponds to your supply. If it doesn’t, please consult your supplier. • Place the device against a fl at, fi rm and stable surface. •...
-
Page 10: Product Presentation
LoRaWAN US915 PULSE - User guide version V1.0.0 PRODUCT PRESENTATION IMPORTANT NOTE: the LoRaWAN US915 PULSE can only be started or restarted using a magnet. Description • LoRaWAN US915 PULSE is a ready to use radio transmitter that can be used to transform any type of meter into a wireless meter (smart meter). -
Page 11: Dimensions
LoRaWAN US915 PULSE - User guide version V1.0.0 1.2. Dimensions Values in millimeters 1.3. Electronic card RF module Internal battery LoRaWAN protocol USB port for prod- uct configuration Screw terminals for connecting meters Page of 26... -
Page 12: General Characteristics
LoRaWAN US915 PULSE - User guide version V1.0.0 1.4. Technical Specifications 1.4.1 General characteristics Parameters Value Supply voltage Nominal 3.6V Power supply Battery Li-SOCl2 Maximum Power 90mA Working temperature -25°C / +70°C Dimensions 105 x 50 x 27mm Casing IP 67 LoRaWAN region EU 863-870 LoRaWAN specification... -
Page 13: Physical Interface Characteristics
LoRaWAN US915 PULSE - User guide version V1.0.0 1.4.4 Physical interface characteristics 1.4.4.01 INPUT Circuit The schematic diagram is the following: Absolute maximum ratings Unit Minimum input voltage - 0.7 Maximum input voltage Electrical characteristics (Typ.) Unit Minimum input voltage Maximum input voltage Equivalent Input pull-up kΩ... -
Page 14: Product Operation
LoRaWAN US915 PULSE - User guide version V1.0.0 PRODUCT OPERATION 2.1. Global Operation Important: adeunis® use the most significant byte first format. The product has several operating modes: PARK MODE Presence of a ma- gnet on the product Command sending >6s by serial link COMMAND... -
Page 15: Application Operation
LoRaWAN US915 PULSE - User guide version V1.0.0 2.2. Application operation 2.2.1 Periodic transmission The product allows the measurement and the periodic transmission of the values of the sensors accord- ing to the following diagram: The settings associated with this Product in mode of operation are: standby... -
Page 16: Periodic Transmission With History
LoRaWAN US915 PULSE - User guide version V1.0.0 2.2.2 Periodic transmission with history The product allows the accumulation of several successive meter values before the periodic transmis- sion of the set of values according to the following scheme: Product in standby Historical Detected and... -
Page 17: Periodic Transmission With Redundancy
LoRaWAN US915 PULSE - User guide version V1.0.0 2.2.3 Periodic transmission with redundancy The product enables to ad redundancy in the frame with historisation (cf scheme here under). Thanks to redundancy the product will memorize a certain number of data and send them again in the next frame. -
Page 18: Flow Threshold Alarm Transmission
LoRaWAN US915 PULSE - User guide version V1.0.0 2.2.4 Flow threshold alarm transmission The product allows the detection of the exceeding of a flow threshold for each counting entry according to the following scheme: Product in standby Flow calcu- Detected and lation peri- validated od reached... -
Page 19: Tamper Detection
LoRaWAN US915 PULSE - User guide version V1.0.0 The settings associated with this mode of operation are: • Enabling and Configuring inputs (register 320) • Anti-bounce timer period (register S322) • Flow calculation period (register S325) • Alarm thresholds (registers S326 and S327) Example : Register Value encoding... -
Page 20: Transmitting A Daily Frame
LoRaWAN US915 PULSE - User guide version V1.0.0 Register Value encoding Value Result S320 Hexadecimal 0x39 Channel A : • Activated • Meter other than gas • Tamper input activated Channel B : • Activated • Gas meter • Tamper input disabled S332 Decimal Scan period for A-channel tamper input is 2x10s =... -
Page 21: Leaks Detection
LoRaWAN US915 PULSE - User guide version V1.0.0 2.2.7 Leaks detection The product allows leak detection on each count input as shown in the following diagram: Product in standby Period Flow calcu- Pulse de- of 24h lation period tected and reached reached ? validated... -
Page 22: Operation Of The Leds
LoRaWAN US915 PULSE - User guide version V1.0.0 Example : Register Value encoding Value Result S320 Hexadecimal 0x39 Channel A : • Activated • Meter other than gas • Tamper input activated Channel B : • Activated • Gas meter •... -
Page 23: Registers And Frame Description
LoRaWAN US915 PULSE - User guide version V1.0.0 REGISTERS AND FRAME DESCRIPTION To know the content of the registers and of each frames (uplink and downlink) of the product, refers to the TECHNICAL REFERENCE MANUAL of the PULSE product, available on the adeunis website: https:// www.adeunis.com/en/produit/pulse-impulse-interface/ CONFIGURATION AND INSTALLATION... -
Page 24: Mounting The Counters On The Screw Terminals
LoRaWAN US915 PULSE - User guide version V1.0.0 5.3. Mounting the counters on the screw terminals Once the nut and packing seal are installed, the strands of the meter cable can be connected to the screw terminals of the product. Below is the identification of each terminal block: Note: Up to 2 meters of the same type can be used in parallel. - Page 25 LoRaWAN US915 PULSE - User guide version V1.0.0 Meter with 3-wire output GROUND / GND GND / Brown IMPULSE_1 / BF IMPULSE_1 / White TAMPER TAMPER_1 / Green In this configuration, it is preferred to activate input TAMPER of channel A (register 320 bit 3 = 1) and deactivate channel B (register 320 bit 4=0) which is not no used.
-
Page 26: Document History
LoRaWAN US915 PULSE - User guide version V1.0.0 DOCUMENT HISTORY User guide version Contents V1.0.0 Document created of 26 Page...
