Film advance and shutter cocking are carried out simultaneously by means of a hand wheel with
360° rotation angle. Frame counter counts number of frames taken, and it is set to Initial position
automatically as soon a s the camera back is opened.
Re wind crank is of a tape-measure type. For rewinding film advance gear disengagement knob is
to be fixed in the depressed position.
Provision is made in the camera for a special motor attachment for automatic film transport.
Film accepted, mm........................................................................... 35
Frame size, mm ................................................................................ 24x36
Number of frames ............................................................................ 36
Photographic objective «Minitar 1
focal length, mm ..................................................................................32
»
:

2. SPECIFICATIONS

5
