Summary of Contents for Magic Flight Muad-Dib

  • Page 3 INTRODUCTION Welcome to the Muad-Dib Flight Guide. This book has been designed to lead you through a successful first session. The Guide is intended to encourage creative exploration and will empower you to become an expert with your Muad-Dib.
  • Page 4 ANATOMY...
  • Page 5 Whip: FDA Grade Peroxide-Cured Silicon Tubing and Brass Tip Screen: Surgical Grade Steel** Our black “Noir” Muad-Dib’s are made from Maple wood that has been coated in naturally sourced India Ink. ** Titanium Screen is currently in development and coming soon...
  • Page 6 DO NOT overfill the screen DO handle the screens gently Always perform a burn-off after each use Always remove and cap the battery between uses Beware-- dogs enjoy Muad-Dib’s as chew toys Always practice choosing on the basis of love.
  • Page 7 actual size Slide the MONOCLE to the side. Gently load the amount of material Note: Screen is very fragile. Do not press or pack herbs into trench. shown above onto the center of the screen. Do not load material higher than the side rails.
  • Page 8 UICK START GUIDE Slide the MONOCLE to the closed position and insert a DRAW WHIP into the DRAW HOLE.
  • Page 9 Insert a fully charged AA Glyph Battery (or Power Adapter 2.0) into the BATTERY HOLE. Begin to inhale, and then press the battery. Continue drawing at a normal to fast rate-- engaging the battery until your draw is complete. All vapor should be captured in one breath.

  • Page 10: Battery Safety

    BATTERY SAFETY • Always remove (AND CAP) the battery from the Muad-Dib when not actively vaporizing • Insert positive (male) end of battery first • Keep positive (male) end batteries covered with provided black caps when not in use •...
  • Page 11 Charge batteries when you go to sleep at night and then remove/ cap them in the morning • The Muad-Dib will only work with NiMH batteries, 2000 mAh or higher • If using 3rd party batteries, remove the wrapper and any adhesive...
  • Page 12 LOAD & DRAW The Muad-Dib will work best for herbal concentrates that melt down to a liquid. These types of concentrates fully vaporize and leave no plant matter residue behind on the screen. Only load the recommended amount. Overloading the screen leads to a waste of your concentrate.
  • Page 13 Begin to draw before engaging the battery and continue to draw until there is no more visible vapor. The inability to capture all of the vapor that is formed in one breath is a sure sign that you have overloaded your screen.
  • Page 14 BURN-OFF After each use, it’s important to BURN-OFF any excess concentrate in order to achieve and maintain optimum taste. Only vaporize the recommended dose -- one hit at a time -- in order to avoid wasting your concentrate. After each hit, perform a burn-off. If done routinely, the burn-off should only take a few seconds.
  • Page 15 REPLACING SCREENS SCREENS ARE FRAGILE-- BE CAREFUL Remove old screen and clean all residue from the rails Prepare your new screen by making sure the U-CLIPS are facing straight down (see fig. a) Align each clip with the rails and press each clip onto the rail with your finger (see fig.
  • Page 16 CLEANING MUAD-DIB Perform burn-off. Once the screen has cooled down, remove the screen. Dip a Q-Tip in Isopropyl Alcohol (ISO) and gently wipe the rails clean. Then wipe down the inside of the brass bowl. If there’s residue on the MONOCLE, you can use a bit of ISO on it as well.
  • Page 17 WHIP Soak in hot water for about 5 minutes to loosen buildup inside of the whip. Hold securely from brass end and squeeze residue out of the open end like toothpaste. Apply continuous pressure as you work your fingers along the length of the whip. Dry whip thoroughly and reinsert stem.
  • Page 18 DIAGNOSTICS When discharged, the batteries generally take between 2-4 hours to fully charge. In addition, batteries have a limited lifetime and need to be occasionally replaced. Additional batteries may be purchased through mflb.it/store. If purchasing non-Glyph Batteries, then make sure to order 2000 mAh NiMH AA-Batteries.

  • Page 19: Troubleshooting

    TROUBLESHOOTING The MONOCLE can be closed during use, or you can leave it open and engage the battery as you’re loading your hit to use it like a traditional rig. Material that doesn’t melt all the way down can be used, though you run the risk of combustion rather than vaporization.
  • Page 20 ABOUT MAGIC-FLIGHT Magic-Flight began in 2009 with the introduction of the Launch Box– the world’s first handmade, portable wooden vaporizer– and with the hope that through our product people would literally be able to breathe easier in their lives because of what we do in ours. Our products are the result of our conviction that it is possible to make things that are at once beautiful, useful, and sustainable.

  • Page 21: Connect With Us

    CONNECT WITH US We’re eager to hear your story. Stay connected by visiting us on: youtube.com/ blog.magic-flight.com magicflightvaporizer @magic-flight facebook.com/ magicflight @magic-flight mflb.tumblr.com...
  • Page 22 COOL YOUR VAPOR TO PERFECTION Includes 2 Whips that connect to both the Launch Box and Muad-Dib Featuring a shower head style diffusion through water At only 4.25” tall, the Orbiter is minimal in footprint but mighty in performance...
  • Page 23 YOUR SOURCE FOR INFINITE POWER Variable voltage enables you to have complete control over the temperature Use a COOLER temperature for dry herbal materials Use a WARMER temperature for concentrates...
  • Page 24 HANDMADE WITH LOVE IN CALIFORNIA...
