The Communiqué Digital Telephone Station
Press the Security* and
Automation* keys to
access your security
system and any home
automation features,
respectively (optional: see
below).
Press and hold the Fire*,
Auxiliary* and Panic* to
send a Fire, Auxiliary or
Panic transmission to your
security monitoring station
(optional: see below).
Press the Clock key to view
the time and date, and your
alarm clock status.
The handsfree speaker,
located underneath the
handset, will project sounds
when the telephone is in the
handsfree mode.
Line Keys
Press a Line key to gain
access to an outside line.
the Line keys are also used
to represent various
programming functions. In
addition, use the Line keys
in the background music
mode to record pre-
selected radio stations.
Feature Keys
Hold / Music - Press to place
an incoming call on hold or to
turn station background music
ON or OFF.
Speed Dial - Press to gain
access to directory of pre-
recorded telephone numbers.
All Page - Press to broadcast
an announcement to all internal
stations.
Room Monitor - Press to listen
in on another station which has
the room monitoring function
activated.
Conference Call - Press to
converse with more than one
stations or lines at once.
* These keys are used in conjunction with your home security equipment and must be programmed by your installer. You must
have a Communiqué Security Interface Card in order for these keys to function. Please ask your installer for more information.
1
2
5
Do Not Disturb / Mute - Press
to prevent station interruptions
or to mute the Handsfree
microphone
Call Forward - Press to forward
incoming calls to another station
or outside number.
Message Center – Press to
receive station and system
mailbox messages.
Handsfree – Press to gain
access to an outside line or to
use the telephone without the
handset. Also, press to exit any
programming function or feature
and return to the idle state.
1
2
4
5
The Liquid Crystal Display
(LCD) provides system
status and will guide you
through system and station
programming via visual
prompts.
3
3
Station Keys
Press a Station key to
connect to another
telephone, intercom or door
station. The Station keys will
also represent the various
programming options
available in station and
system programming.
The handsfree microphone is
located here. This microphone
will pick up sounds when the
telephone is in the handsfree
mode.
The infrared receiver is
located under the dark plastic
window.
4
Press the Redial key to dial the last
number from that station.
Use the Volume Up (
^
keys to scroll through infromation
presented on the LCD. To control
station volume levels, press the Volume
Up and Down keys while the sound you
wish to alter is activated. Pressing
these keys will also adjust the LCD
contrast when the telephone is in the
idle state.
Press the PGM key once to access
station programming and twice to
access system programming. Press
the PGM key to record any
programming changes you make to
your station or system-wide.
Communiqué Operation Manual • 1
) and Down (v)
