Trixie Natura Chicken Hutch Assembling Instruction & Part List

Item No.
"natura" Chicken Hutch
01-55962
Pos. No. Description
Pos. 1 Side panel, nesting box, left
Pos. 2 Side panel, nesting box, right
Pos. 3 Back wall, nesting box
Pos. 4 Bottom plate, nesting box
Pos. 5 Partition wall, nesting box
Pos. 6 Wall, sleeping house, left
Pos. 7 Roof plate, nesting box
Pos. 8 Front part, sleeping house
Pos. 9 Back wall, sleeping house
Pos. 10 Wall, sleeping house, right
Pos. 11 Front part, enclosure
Pos. 12 Back part, enclosure
Pos. 13 Ramp
Pos. 14 Support for the ramp
Pos. 15 Side wall, enclosure, right
Pos. 16 Pos. 16 Chicken perch Chicken perch
Pos. 17 Drawer with plastic inlay
Pos. 18/19 Roof plate, left/right
Final batten, roof
Pos. 20/21
left/right, front/back
Pos. 22 Roof ridge
120301 120301
Aufbauanleitung / Assembling Instruction & Stückliste / Part List
175 × 107 × 80 cm
Measurement Quantity Item No.
362 × 303 × 40 mm 1 55962-10
362 × 303 × 40 mm 1 55962-11
30 × 271 × 510 mm 1 55962-12
338 × 15 × 487 mm 1 55962-13
238 × 340 × 5 mm 1 55962-14
25 × 860 × 666 mm 1 55962-20
382 × 30 × 576 mm 1 55962-15
764 × 1038 × 25 mm 1 55962-21
764 × 1038 × 25 mm 1 55962-22
25 × 520 × 666 mm 1 55962-23
860 × 630 × 25 mm 1 55962-30
860 × 630 × 25 mm 1 55962-31
654 × 18 × 170 mm 1 55962-41
32 × 30 × 215 mm 1 55962-40
25 × 566 × 666 mm 1 55962-32
ø 40 × 721 mm ø 40 × 721 mm 1 1 55962-42 55962-42
710 × 50 × 690 mm 1 55962-43
480 × 18 × 780 mm 55962-50
1/1
1164 × 18 × 780 mm 55962-51
485 × 60 × 25 mm 55962-44
2/2
1169 × 60 × 25 mm 55962-45
90 × 30 × 764 mm 1 55962-52
TRIXIE Heimtierbedarf GmbH & Co. KG TRIXIE Heimtierbedarf GmbH & Co. KG
1. First assemble the nesting box: Connect the both side
panels (1/2) with the back wall (3) and the bottom plate (4).
Insert the partition wall (5).
Screw the final battens (20/21)) at the fronts of the
roof plates (18/19).
3. Fasten the front and back wall (8/9), as well as the right side
wall (10) of the sleeping house.
2. Then fix the left side wall of the sleeping house (6) and the
roof plate (7) to the nesting box. Screw the left check strap (I)
with the roof of the nesting box.
4. Insert the drawer (17) and fasten the perch. (16)
