Trixie Natura 55964 Manual

Item No.
natura Chicken hutch
55964
Pos. No. Description
Pos. 1
Upper front panel
Pos. 2 Upper back panel
Pos. 3 Bottom panel, front/back
Pos. 4 Left side panel
Pos. 5 Right side panel
Pos. 6
Drawer with metal inlay
Pos. 7 Middle floor, backside
Pos. 8 Bottom panel for nest box
Pos. 9 Left panel, nest box
Pos. 10 Right panel, nest box
Pos. 11
Back panel, nest box
Pos. 12 Roof plate of nesting box
Pos. 13 Middle partition wall, nest box
Pos. 14 Roof ridge
Pos. 15 Ramp
Pos. 16 Roof plate, left
Pos. 17 Roof plate, right
Pos. 18 Roosting Pole
180613
49 × 42 × 31 inch
125 × 107 × 79 cm
Measurement Quantity Item No.
673 × 472 × 25 mm 1 55964-10
673 × 517 × 25 mm 1 55964-20
673 × 523 × 25 mm 2 55964-11
986 × 716 × 25 mm 1 55964-50
986 × 716 × 25 mm 1 55964-51
Insert the partition wall (13). Then connect the left side panel
670 × 40 × 498 mm 1 55964-70
670 × 13 × 191 mm 1 55964-71
287 × 26 × 543 mm 1 55964-43
30 × 306 × 300 mm 1 55964-40
30 × 306 × 300 mm 1 55964-41
30 × 280 × 546 mm 1 55961-42
326 × 18 × 636 mm 1 55961-44
288 × 248 × 5 mm 1 55964-45
69 × 45 × 792 mm 1 55964-92
760 × 20 × 158 mm 1 55694-60
407 × 18 × 766 mm 1 55964-90
407 × 18 × 766 mm 1 55964-91
40 × 40 x 687 mm 1 55964-30
TRIXIE Heimtierbedarf GmbH & Co. KG
1. Assemble the nesting box: Connect both side panels
(Pos.9/10) with the back wall (11) and the bottom plate (8).
of the coop (4) with the nesting box
3. Put in the ramp (15) and srew it. Insert the drawer (6) and
fasten the roosting pole. (18)
2. Fasten the upper and top front and back panel (1+3/2+3), as
well as the right side
panel (5) of the sleeping house.
4. Screw the roof plate of the nesting box (12) to the left side
panel.
81860
