  • Page 1 TOP-DIS-IP2 Desktop call station RMLT.465311.009UM User Manual Document version 7 26.30.11.190 2020...
  • Page 2 © Armtel info@armtel.com...

  • Page 3: Introduction

    INTRODUCTION This User Manual applies to «TOP-DIS-IP2 Desktop call station» RMLT.465311.009 manufactured by Armtel LLC, and is intended to familiarize the User with the device and the procedure for its operation at the installation site. Designed for organization of two-way communication as a component of IPN system manufactured by Armtel LLC.

  • Page 4: Safety Provisions

    TOP-DIS-IP2 DESKTOP CALL STATION User Manual SAFETY PROVISIONS During installation and operation observe the safety measures specified by local codes and regulations on electrical safety. During installation and operation, observe safety precautions laid out in “Occupational safety rules when operating electrical installations” when working with electrical receivers with voltage of up to 1000 V.

  • Page 5: Table Of Contents

    2.5 Operation ................................. 25 2.5.1 Turning on ..............................25 2.5.2 Function keys assignment......................... 26 2.5.3 Communication types and scenarios ....................27 2.5.4 TOP-DIS-IP2 complete with TOP-HS-IP2 features ................30 2.5.5 Troubleshooting ............................31 3 MAINTENANCE ................................32 3.1 General guidelines ..............................32 3.2 Safety precautions ..............................
  • Page 6 Wall-mounting ......................47 APPENDIX D (reference) Turntable-mounting....................52 APPENDIX E (reference) Recommendations on flush-mounting of TOP-DIS-IP2 ......... 53 APPENDIX F (reference) TOP-DIS-IP2 Indication types ................... 57 APPENDIX G (reference) A template for printing of function keys assignment ........59 APPENDIX I (reference) Scope of supply ......................

  • Page 7: Description And Operation

    Address /General Alarm communication systems (based on allotted SIP server manufactured by LLC Armtel) at metal, chemical, oil-processing, oil and gas, energy and transport industries or at facilities of the same type. ТОР-DIS-IP2 is designed for installation in control, office rooms and premises.
  • Page 8 − increasing of function keys total number up to 126 pcs. by connecting of up to two Expansion units TOP-EC-IP2 RMLT.468366.009. Configuration of TOP-DIS-IP2 shall be carried out using the personal computer of the IPN network administrator on which IPN2 RU.RMLT.00041-01 IPN Config Tool software configuration application is installed.

  • Page 9: Main Specifications

    TOP-DIS-IP2 DESKTOP CALL STATION User Manual 1.1.2 Main specifications Main specifications of TOP-DIS-IP2 are given in Table Table 1 – Main specifications (beginning) Parameters Value Electrical parameters Rated voltage PoE (IEEE 802.3at), V Supply voltage range PoE (IEEE 802.3at) at turn on, V 42…60...
  • Page 10 TOP-DIS-IP2 DESKTOP CALL STATION User Manual Table 1 - Main specifications (continuation) Parameters Value Data lines 10BASE-T (IEEE802.3i) 100BASE-TХ (IEEE802.3u) Ethernet communication interface *** Channel bonding (IEEE802.3ad) Communication protocols via Ethernet SIP, «Armtel-IP» C (Armtel), Communication buses with auxiliary modules USB 2.0...

  • Page 11: Operations Conditions

    Ingress protection of TOP-DIS-IP2 complies with IP42. TOP-DIS-IP2 complies with the requirements electromagnetic interference according to IEC 61000-6-2:2005, with not lower B quality criterion. The electromagnetic interference from TOP-DIS-IP2 does not exceed the codes specified in IEC 61000-6-4:2006. armtel.com page 9/64 info@armtel.com...

  • Page 12: Design

    TOP-DIS-IP2 DESKTOP CALL STATION User Manual 1.1.4 Design 1.1.4.1 The external appearance and overall dimensions of TOP-DIS-IP2 in desktop version and with G14-2 microphone are illustrated at Figure 1 – LED indication on the microphone; 2 – microphone; 3 – stand; 4 – built-in speaker;...
  • Page 13 The antenna has a gain value of 2.8 dBi at 2.4 GHz and 4.2 dBi at 5 GHz, that allows the wireless access point to be located at a distance of up to 100 meters from TOP-DIS-IP2 or more - depending on the characteristics of the antenna on the access point. The external...
  • Page 14 (4 pcs.) and in the stand (2 pcs.) in accordance with Figure 6. When TOP-DIS-IP2 is supplied to the customer, the grooves in the base of the enclosure are closed with special plugs (not shown in Figure 6), which must be removed from the grooves before the cables are laid.
  • Page 15 Desktop call station for communication of subscriber devices with ADSL interface included in IPN system. 1.1.4.8 Power supply of TOP-DIS-IP2 is carried out via PoE line in accordance with IEEE802.3at standard, and in the form of passive power over twisted pair (passive PoE), without data transmission as well, when one port is transmitted data, the second –...

  • Page 16: Labeling

    TOP-DIS-IP2 DESKTOP CALL STATION User Manual 1.1.5 Labeling On the bottom side of TOP-DIS-IP2 casing is placed bilingual nameplate. The nameplate contains the following information: − name, trademark and reference information of the manufacturer; − product name and description; − permissible operating temperature range;...

  • Page 17: Package

    TOP-DIS-IP2 DESKTOP CALL STATION User Manual 1.1.6 Package The TOP-DIS-IP2 with the assembly kit and documents, which come with the supply package, is packed in consumer package (cardboard box). Before packing in consumer package (cardboard box), TOP-DIS-IP2 with the assembly kit and operational documentations are placed in plastic film covers that have the corresponding marking.

  • Page 18: Description And Operation Of The Product Components

    − microphone; − speaker; − Wi-Fi module. 1.2.2 Main board TOP-DIS-IP2 main board is a printed board with installed electronic elements required for functioning of the TOP-DIS-IP2. External appearance of main board is given on Figure a) key side view Figure 7 –...
  • Page 19 TOP-DIS-IP2 DESKTOP CALL STATION User Manual b) CPU module side view Figure 7 – TOP-DIS-IP2 main board (end) Figure 7b includes: − U1: central processing unit CPU; − Х2: socket for external 12 V power supply connection; − Х1, Х3: sockets for Ethernet connection with РоЕ function, indicators on the...

  • Page 20: Functional Keys

    TOP-DIS-IP2 according to the algorithm assigned in the IPN Config Tool. The TOP-DIS-IP2 main board has the sockets that are connected to the enclosure base for connecting cables to the Ethernet network, Handset unit and Expansion units, the USB socket, and the external power supply socket.

  • Page 21: Microphone

    Figure 8 – The way of opening of the key cap 1.2.4 Microphone TOP-DIS-IP2 uses a removable high-sensitivity G14-2 condenser microphone on a flexible gooseneck (see Figure 9). The microphone has a red LED that indicates the type of incoming or outgoing communication by a constant glow or blinking.

  • Page 22: Speaker

    Figure 11 – External appearance and overall dimensions of built-in speaker 1.2.6 Wi-Fi module In the basic version of TOP-DIS-IP2, the Wi-Fi module WM1123WU is used, which is installed on the main board and supports IEEE 802.11a/b/g/n/ac protocol for operation at 2.4 GHz and 5.0 GHz with a bandwidth of up to 80 MHz.

  • Page 23: Intended Use

    12 V power supply with a power of at least 25 W. 2.1.3 In case of PoE (PoE plus) power failure, it is necessary to supply TOP-DIS-IP2 with 12 V power from the external adapter via the socket at the base of the Desktop call station (see Figure 2).

  • Page 24: Preparation For Use

    User Manual 2.2 Preparation for use Preparation of TOP-DIS-IP2 for use shall be carried out by the manufacturer’s representatives, or personnel trained to operate Armtel LLC products. The main preparation of the product for use is carried out during installation and connection. Preparation of TOP-DIS-IP2 for operation involves a series of steps: −...

  • Page 25: Installation, Connection And Dismantling

    2.4.1 The main installation position of TOP-DIS-IP2 is desktop mounting. With the desktop installation of TOP-DIS-IP2 on the base of the enclosure there is a stand for better visibility of the keys (see 1.1.4.2). If TOP-HS-IP2 Handset unit or TOP-EC-IP2 Expansion unit are used, in order to provide extra stiffness the modules can be attached to TOP-DIS-IP2 by aluminum junction plates supplied with additional modules.
  • Page 26 TOP-DIS-IP2 DESKTOP CALL STATION User Manual 2.4.6 TOP-DIS-IP2 is dismantled in the following order: − disconnect microphone; − disconnect stand (if used); − disconnect all connection cables; − disconnect junction plates; − in case turntable-mounting − remove the structure from the turntable and detach junction plates;...

  • Page 27: Operation

    SIP, when establishing communication session using Wi-Fi. The Direct call FK of TOP-DIS-IP2 can be configured by means of network administrator's PC depending on the type of protocol used (“Armtel-IP” or SIP), for implementing various communication scenarios, for example, “Direct call to the Subscriber”, “Conference”,...

  • Page 28: Function Keys Assignment

    Function keys (FK) – the keys of the Desktop call station programmed to perform a specific function. The keys can be programmed for communication functions and local functions. The functions of the TOP-DIS-IP2 keys are configured from the administrator's PC by means of IPN Config Tool. The main options accompanying connection setting up, keeping up and link disconnection between subscribers are the settings of the duplex mode (possible assignments: “Disabled/Off”, “Manual”, “Full”, and “Priority level”.

  • Page 29: Communication Types And Scenarios

    2.5.3.1 TOP-DIS-IP2 supports two telecommunication protocols SIP (RFC 3261) and protocol “Armtel-IP”. The Desktop call station operation via SIP protocol can be carried out over SIP server. Calls via SIP protocols are made in both simplex and duplex modes, receiving of the calls - in half-duplex mode, and when using TOP-HS-IP2 Handset unit - in full duplex mode.
  • Page 30 TOP-DIS-IP2 DESKTOP CALL STATION User Manual The participants of the circular are collected by the organizer of the circular with the help of FK “Circular”. After a short press on the FK with the function “Circular”, the organizer one by one presses the keys with the function “Call via SIP” of the subscribers to add new members to the circular or to remove participants from the circular.
  • Page 31 ACM-IP2” RMLT.465275.006 produced by LLC Armtel. In this mode, activation of control lines on the ACM-IP2 does not occur, the module is free for voice calls. The control is carried out by FK with the assigned function “Relay”. The function works via protocol “Armtel-IP” and SIP.

  • Page 32: Top-Dis-Ip2 Complete With Top-Hs-Ip2 Features

    Desktop call station and the microphone are turned off in this mode. The TOP-DIS-IP2 feature in combination with TOP-HS-IP2 is the combination of its programming flexibility and the ability to change many functions on site in accordance with the customer's requirements.

  • Page 33: Troubleshooting

    Ethernet interface communication is cable or the 12 V power adapter impossible The communication TOP-DIS-IP2 has not been Configure the TOP-DIS-IP2 by means with subscribers is configured of IPN system Config Tool impossible The communication via telephone handset is impossible;...

  • Page 34: Maintenance

    − check for safety connection to the cable sockets - the cables should not have any tension; − cleaning of TOP-DIS-IP2 surface from dirt, using for this purpose the wet sponge with mild soap solution or wet wipes for cleaning office appliances; the use of chemically active solvents is not admitted;...

  • Page 35: Checking Operability

    − pause for about 10 seconds to completely discharge the filtering power supply tanks in TOP-DIS-IP2; − apply power to TOP-DIS-IP2 again, make sure that the remote control is successfully initialized as described in 2.5.1. 3.4.2 Checking acoustic path...

  • Page 36: Pepair

    TOP-DIS-IP2 DESKTOP CALL STATION User Manual 4 PEPAIR No scheduled repair work is provided for the product. Unscheduled repair shall be performed by the manufacturer at the request of the User. The place, time, procedure and cost of the work shall be agreed with the manufacturer in advance.

  • Page 37: Storage

    TOP-DIS-IP2 DESKTOP CALL STATION User Manual 5 STORAGE Product storage conditions – in the manufacturer’s consumer package in indoors and humidity-controlled storage facilities within temperature range from minus 20 °С to plus 40 °С, and in relative humidity conditions under plus 25 °С.

  • Page 38: Transportation

    TOP-DIS-IP2 DESKTOP CALL STATION User Manual 6 TRANSPORTATION The product shall be transported in consumer package as a packaging unit by road, river, railway and air transport (except unsealed compartments), with compliance with the following conditions: − temperature from minus 20 to plus 40 °С and humidity up to 80 % at 25 °С;...

  • Page 39: Disposal

    TOP-DIS-IP2 DESKTOP CALL STATION User Manual 7 DISPOSAL The product shall not be disposed of together with household waste and must be delivered to a special center for the disposal of electronic products. The operating organization shall be responsible for the disposal of the product.

  • Page 40: Appendix A (Reference) Connection

    TOP-DIS-IP2 DESKTOP CALL STATION User Manual APPENDIX A (REFERENCE) CONNECTION The pin assignment of RJ-45 sockets of TOP-DIS-IP2 Ethernet interface is given in Table А.1. А.1 – The pin assignment of RJ-45 sockets Table External appearance of RJ-45 socket Contact number...
  • Page 41 TOP-DIS-IP2 DESKTOP CALL STATION User Manual The pin assignment of RJ-25 sockets for digital path connection of TOP-HS-IP2 and ТОР-EC-IP2 Expansion unit is shown in Table А.3. А.3 - The pin assignment of RJ-25 sockets for digital path connection of TOP-HS-IP2 and Table ТОР-EC-IP2...
  • Page 42 TOP-DIS-IP2 DESKTOP CALL STATION User Manual An example of TOP-DIS-IP2 connection complete with TOP-HS-IP2 Handset unit and TOP-EC-IP2 Expansion unit is illustrated at Figure A.5. Figure A.5 – The example of TOP-DIS-IP2 connection page 40/64 armtel.com © Armtel info@armtel.com...
  • Page 43 TOP-DIS-IP2 DESKTOP CALL STATION User Manual The example of connection of TOP-DIS-IP2 complete with two TOP-EC-IP2 Expansion units, with TOP-HS-IP2 Handset unit and “Ethernet bonding” function is illustrated at Figure A.6. Figure A.6 – The example of TOP-DIS-IP2 connection armtel.com page 41/64 info@armtel.com...

  • Page 44: Appendix B (Reference)

    TOP-DIS-IP2 DESKTOP CALL STATION User Manual APPENDIX B (REFERENCE) DESKTOP MOUNTING OF THE UNIT COMPLETE WITH TOP-EC-IP2 EXPANSION UNIT AND TOP-HS-IP2 HANDSET UNIT If TOP-EC-IP2 Expansion unit is used, its installation set includes junction plates to impart stability and stiffen the assembly will be included into the scope of supply. The...
  • Page 45 TOP-DIS-IP2 DESKTOP CALL STATION User Manual After adjustment of the joint plates, connect interface cables to TOP-DIS-IP2 and, if necessary, power supply cables, and then fix the stand. TOP-EC-IP2 Expansion unit can be attached to TOP-DIS-IP2 Desktop call station from...
  • Page 46 TOP-DIS-IP2 DESKTOP CALL STATION User Manual Auxiliary Expansion units can be attached either directly to TOP-DIS-IP2, or to each other (see Figure B.4): Figure B.4 – The variants of adjustment of two TOP-EC-IP2 Expansion units Connecting cables are connected either to the Desktop call station or to the additional Expansion unit.
  • Page 47 TOP-DIS-IP2 DESKTOP CALL STATION User Manual If TOP-HS-IP2 Handset unit is used, it is attached to TOP-DIS-IP2 similarly using the junction plates (see Appendix B of the instruction manual for the TOP-HS-IP2 RMLT.465484.003). The TOP-HS-IP2 is connected to RJ-22 and RJ-25 sockets of the Desktop...
  • Page 48 User Manual Figure B.6 – The variants of TOP-HS-IP2 and TOP-EC-IP2 adjustment In all cases of desktop mounting of TOP-DIS-IP2 Desktop call station and options arrangements, upon completion of installation G14-2 removable gooseneck microphone should be attached to the unit.

  • Page 49: Wall-Mounting

    TOP-DIS-IP2 DESKTOP CALL STATION User Manual APPENDIX C (REFERENCE) WALL-MOUNTING To attach TOP-DIS-IP2 to the wall, the holes on the bottom side of the unit base stand should be used (see Figure C.1): Figure C.1 – Holes for TOP-DIS-IP2 mounting armtel.com...
  • Page 50 TOP-DIS-IP2 DESKTOP CALL STATION User Manual At the place of installation, the layout is done in accordance with the template given (see Figure C.2): page 48/64 armtel.com © Armtel info@armtel.com...
  • Page 51 TOP-DIS-IP2 DESKTOP CALL STATION User Manual b) Layout on the wall for mounting TOP-DIS-IP2 with TOP-HS-IP2 Figure C.2 - Layout on the wall for the brackets installation (continuation) armtel.com page 49/64 info@armtel.com © Armtel...
  • Page 52 TOP-DIS-IP2 DESKTOP CALL STATION User Manual page 50/64 armtel.com © Armtel info@armtel.com...
  • Page 53 C.3) by the screws provided and fixed to the wall through the holes (4). After fixing the brackets, the mounting plate is removed. Figure C.3 – Brackets for wall-mounting of TOP-DIS-IP2 In the holes 1, 4, 5, 8 on the bottom side of TOP-DIS-IP2 base (see Figure C.1), 3 ×...

  • Page 54: Turntable-Mounting

    APPENDIX D (REFERENCE) TURNTABLE-MOUNTING For fixing TOP-DIS-IP2 to the turntable used holes on the underside of the bottom side. Mounting holes on the turntable and the bottom side of the remote control are combined and secured with 3x8 plastic screws provided.

  • Page 55: Appendix E (Reference)

    User Manual APPENDIX E (REFERENCE) RECOMMENDATIONS ON FLUSH-MOUNTING OF TOP-DIS-IP2 In case of flush-mounting of TOP-DIS-IP2 the marking on the desktop should be carried out according to Figure E.1: Figure E.1 – Layout of the desktop for flush-mounting of TOP-DIS-IP2 armtel.com...
  • Page 56 TOP-DIS-IP2 DESKTOP CALL STATION User Manual TOP-DIS-IP2 is flushed into the cut-out hole and fixed in holes 1-8 (see Figure E.2) by means of screws for ART 9091 plastic. Figure E.2 – Holes for self-tapping screws The permissible length of self-tapping screws should not exceed the value determined...
  • Page 57 TOP-DIS-IP2 DESKTOP CALL STATION User Manual If TOP-EC-IP2 Expansion unit should be attached to, the layout for its installation is fulfilled according to the dimensions illustrated at Figure E.1 and in accordance with Figure E.4: If the Desktop call station is equipped with TOP-HS-IP2, it should be mounted using self-tapping screws intended for plastic, similar to mounting of the Desktop call station, through two holes in the desktop with a diameter of 3.2 mm.
  • Page 58 TOP-DIS-IP2 DESKTOP CALL STATION User Manual a distance (52 ± 0.2) mm from the outer holes for adjustment of the Desktop call station (see Appendix C of the User manual for TOP-HS-IP2 RMLT.465484.003) with horizontal and vertical marking. both left-hand and right-hand options are available for the Handset unit mounting.

  • Page 59: Appendix F (Reference)

    TOP-DIS-IP2 DESKTOP CALL STATION User Manual APPENDIX F (REFERENCE) TOP-DIS-IP2 INDICATION TYPES The indication types are used in TOP-DIS-IP2 are given in Table F.1. All periods of indication are synchronized in the frames of one end-User device Table F.1 – TOP-DIS-IP2 indication types Full indication cycle –...
  • Page 60 TOP-DIS-IP2 DESKTOP CALL STATION User Manual page 58/64 armtel.com © Armtel info@armtel.com...

  • Page 61: Appendix G (Reference) A Template For Printing Of Function Keys Assignment

    TOP-DIS-IP2 DESKTOP CALL STATION User Manual APPENDIX G (REFERENCE) A TEMPLATE FOR PRINTING OF FUNCTION KEYS ASSIGNMENT Print size (2,8 х 0,95) mm armtel.com page 59/64 info@armtel.com © Armtel...
  • Page 62 TOP-DIS-IP2 DESKTOP CALL STATION User Manual page 60/64 armtel.com © Armtel info@armtel.com...

  • Page 63: Scope Of Supply

    TOP-DIS-IP2 DESKTOP CALL STATION User Manual APPENDIX I (REFERENCE) SCOPE OF SUPPLY Scope of supply of TOP-DIS-IP2 is given in Table I.1. Table I.1 – Scope of supply Quanty- Identification Name Note ty, pcs. RMLT.465311.009* TOP-DIS-IP2 Desktop call station RMLT.305636.001 Package Product сomponents...
  • Page 64 TOP-DIS-IP2 DESKTOP CALL STATION User Manual Table F.1 – Scope of supply (end) Quanty- Identification Name Note ty, pcs. Operational documentation RMLT.465311.009PP Product Passport RMLT.465311.009UM User Manual * Version identification according to the contract. Wall-mounting kit : bracket left RMLT.733121.001 – 1 pcs., bracket right RMLT.733121.002 –...
  • Page 65 TOP-DIS-IP2 DESKTOP CALL STATION User Manual NOTES armtel.com page 63/64 info@armtel.com © Armtel...
  • Page 66 TOP-DIS-IP2 DESKTOP CALL STATION User Manual NOTES page 64/64 armtel.com © Armtel info@armtel.com...
