Vericom V-Sense Quick Start Manual

The Vericom V-Sense
TM
V-Sense DAQ, RG and MSI units include a simple test system that is ideal for testing nearly all vehicle types
on a variety of surfaces.
What's Included
:
•
Wall Charger/Power Supply
•
Tablet with V-Sense Director
•
Heavy Duty Vacuum Cup Mount
•
16GB of Test Data Storage (10,000+
Brake Tests)
The V-Sense User Guide can be found on the
Vericom Website and on the USB drive included
with the package.
V-Sense POD LED Panel – Power ON/OFF, Battery, Connected:
Press and hold the power button
on the far left of the LED panel will illuminate when power is on. The 4 LED lights on the right side of the
LED panel indicate the battery level of the V-Sense POD.
Connect a V-Sense POD to the Tablet with wireless Bluetooth: The tablet included with your Vericom
V-Sense Brake Meter package is preloaded with the Vericom V-Sense
preconfigured to connect to the V-Sense POD included within the case. To connect the tablet to the V-
Sense POD via Bluetooth, power on the POD and then open the Tools screen on the Vericom V-Sense
Director app (tablet). From the drop-down box, select the POD name desired for connection. Then click
the Connect button. Once the POD is connected, the connection box will show a green check mark and
the Connect button will become a Disconnect button.
(This message shows that the POD and the tablet
ARE NOT connected.)
system is the industry's leading test kit for advanced brake/frictional testing. The
for approximately 3 seconds to power the POD on or off. The light
Power Button V-Sense is ON V-Sense Connected Light V-Sense POD Battery Level
V-Sense Brake TEST
TM
Quick Start Guide
Director application. It is also
TM
(This message shows that the POD and the tablet
ARE connected.)
