Table of content Parts supplied ............................4 Transmitter ..................................4 Receiver ....................................4 Panel View ........................5 Transmitter ..................................5 Receiver ....................................5 Video Output Setting ..............................5 LED Indication ...................................6 RJ45 LED Indication .................................6 Rotary Switch Function ..............................6 Cable & Transmission Distance ............................7 Remote Control Function ..............................7 Application and Installation ..................10 Point to Point Direct Connection (Extender): ......................
Page 3
Safety instructions General safety instructions • Before switching on and operating the system, first read this safety advice and the operating instructions. • Keep the operating instructions in a safe place for later use. • Installation, commissioning and maintenance of the system may only be carried out by authorised individuals and in accordance with the installation instructions - ensuring that all applicable standards and guidelines are followed.
Graphical symbols Please pay attention to the safety instructions, and carefully read through this instruction guide before initial operation. Important points of warning are marked with a caution symbol. Important points of advice are marked with a notice symbol. Parts supplied Transmitter •...
Panel View Transmitter Receiver Video Output Setting The receiver supports both DVI and VGA dual output, default is DVI output only. You can either change the output setting before power on or while using as follows: (A) To change the output setting before power on, please press and hold below buttons and then plug in the power, release the button after 1 or more seconds (about 30 seconds to boot).
LED Indication Panel LED Status Description No power Boot completed Flash twice Booting Power Turn off video output Green LED Flash slowly (Not available for transmitter) Screen saver mode Pulse (Not available for transmitter) Not connected with transmitter/receiver Link Connected and video is streaming Flash Connecting, or no source input from transmitter No IR signal transmitting/receiving...
Transmitter channel setting must be unique to avoid conflict with any other transmitters. After rotary switch change must reboot or power off/on the transmitter ITEM TRANSMITTER Button LINK FUNCTION Video Mode / Graphic Mode Short Press Remote output (on / off) Long Press (3 seconds) Loop output (on / off) Anti-Dither (1/2/off)
Page 8
To setting the Remote ID, Press and hold power button, then press button 8 to complete the setting. (for example) Remote Control Button Function: Symbol Function Power Temporarily turn off /on the video output /Setup remote control Remote ID MENU Menu selection, input numbers after press menu button LEFT Previous channel...
Page 9
CAUTION: • Transmitter/receiver boot time requires 30 seconds. • Transmitter must be rebooted to apply channel setting by hardware rotating switch. • Not recommend to work with existing LAN connection to avoid large video, data transmission or multicast packets to slow down your other LAN devices.
Application and Installation Point to Point Direct Connection (Extender): 150 m Transmitter (TX) Receiver (RX) Multiple TX to Multiple RX Connection (Matrix Switcher): 100 m 100 m TX 1 RX 1 TX N RX N...
Multiple TX to One RX Connection (Switcher over IP): 100 m 100 m TX 1 TX N One TX to Multiple RX Connection (Splitter): 100 m 100 m TX 1 RX 1 RX N Further Information The manual is available on the eneo website at www.eneo-security.com.
Page 12
VIDEOR E. Hartig GmbH Exclusive distribution through specialised trade channels only. VIDEOR E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark/Germany Tel. +49 (0) 6074 / 888-0 Technical changes reserved Fax +49 (0) 6074 / 888-100 www.videor.com...
