SAFARI CHEF 2 – BURNER COLLAR REPLACEMENT

Advertisement

loading
Need help?

Need help?

Do you have a question about the SAFARI CHEF 2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cadac SAFARI CHEF 2

Summary of Contents for Cadac SAFARI CHEF 2

  • Page 1 SAFARI CHEF 2 – BURNER COLLAR REPLACEMENT...

  • Page 2: Tools Required

    Tools required : Crosshead screwdriver 7mm spanner 17mm Socket (optional)
  • Page 3 Step 1, Unscrew burner by twisting in an anti-clockwise rotation.
  • Page 4 Step 2, Remove the three screws indicated by yellow circles. Remove top plate...
  • Page 5 Step 3, Remove washer. NOTE: Colour of washer may vary.
  • Page 6 Step 4, • Place the spanner over the nut and turn unit over. • Remove the crosshead screw...
  • Page 7 Step 5, Earth collar can then be removed.
  • Page 8 Step 6, Plastic collar can then be removed using the 17mm socket. (Hand tight only)
  • Page 9 •All screws are tight •DO NOT over tighten the new plastic collar •DO NOT over tighten the burner Disclaimer: Cadac will not be held responsible for any damage or injury caused by following this tutorial.
