- Page 1 HAV-PMS10 Portable Micro System ANLEITUNG MANUAL MODE D’EMPLOI GEBRUIKSAANWIJZING MANUALE MANUAL DE USO HASZNÁLATI ÚTMUTATÓ KÄYTTÖOHJE NÁVOD K POUŽITÍ BRUKSANVISNING...
- Page 2 Packaging contents 1x HAV-PMS10 Portable Micro System 1x SC/DC adapter 1x USB cable 1x 3.5mm audio cable 1x Stereo earphone 1x USB Driver CD for Windows® 98SE 1x Manual Location of controls...
-
Page 3: Battery Operation
LCD display Battery operation Open the battery compartment according below figures. Insert 4x C batteries as shown in the diagram inside the battery compartment. AC/DC adapter operation Open the connections panel on the rear of the system in the direction of the arrow. Connect the mini plug to the 6V connection and the power plug to a 220~230V wall outlet. -
Page 4: Usb Driver Installation
Note: When the AC/DC adapter is connected the LCD backlight will turn on and remain lit until the AC adapter is unplugged. When the system is running on batteries, the LCD backlight will light up briefly each time a button is pressed and then turn off. You can adjust the time the LCD backlight will remain on for through the SYS menu (see the SYSTEM MODE (SYS) section for details). - Page 5 The system automatically when connected. Microsoft Windows 98 SE For Windows 98 SE it’s necessary to install the USB driver. 1. Navigate to MY COMPUTER and double-click on the CD/DVD drive icon. 2. Double-click on the folder “Win98 USB Drivers” and then on the folder “english”.
- Page 6 3. Select “USB Mass Storage Device” from the list that appears and then click on “OK”. 4. Disconnect the USB cable from the system and the computer. Macintosh OS X 1. Identify the appropriate Removable Disk icon, on the left side of the Finder window.
-
Page 7: Menu Navigation
Note: It’s also possible to use the mouse to drag-and-drop files between the system and the computer. Basic operations Standby mode The system will enter Standby mode automatically when it is connected to a power source. The LCD will display the time. Power On/Off To turn the system on, press play/pause while in Standby mode. -
Page 8: Operation
SET-Clock Set, Alarm Set SYS - SYSTEM: EQ, Repeat Mode, Display, Auto Off, Sleep Time, Recording, Resume, Delete File, Format, Reset, Information, Alarm Mode Music Select and confirm MUSIC to find audio files (e.g. MP3, WMA) in the “Root” folder of the system. Voice Select to find recorded audio files in the “Record”... - Page 9 Repeat play Repeat Play options can be changed in the SYSTEM menu. Options are Normal, One, All, Intro and Random. (See the SYSTEM MODE (SYS) section for details) Repeat A-B function The A-B function allows to set a segment of a track to be played repeatedly.
- Page 10 1. Place the system in PRESET or MANUAL tuning mode. 2. Press and hold MENU. 3. The system will automatically seek and store the first 20 frequencies. Note: this will overwrite previously stored preset stations. Delete a Preset Station 1. Place the player in PRESET tuning mode. 2.
- Page 11 Note: see the SYS section for details about changing the recording options Voice Recording 1. Set the REC Input to “MIC” 2. Place the system in MSC mode. 3. Press REC to start recording through the built-in microphone. 4. Press play/pause to interrupt recording and press again to resume. 5.
- Page 12 The options are: Clock Set and Alarm Set. Clock set 1. Enter SET mode and confirm. 2. Press < or > to select AM/PM, hour and minute. 3. Press + or - to adjust. 4. Press play/pause to confirm (or press MENU to cancel the setting). Alarm set 1.
- Page 13 EQ (equalizer) Adjust the EQ settings to optimize the sound. The EQ options are: Normal, Classic, Live, Pop, and Rock. 1. Select and confirm EQ. 2. Press < or > to select an EQ option. 3. Press play/pause to confirm the change. (Or press MENU to cancel the setting) Repeat Mode The repeat functions are:...
- Page 14 (Only displayed if MP3 track contains Lyric information) Contrast Adjust the contrast of the display. The contrast setting ranges from 00 to 15 (00 = lowest contrast; 15 = highest contrast). B-Light Time (Backlight) Adjust the amount of time the backlight remains on after a button is pressed.
- Page 15 1. Select and confirm Recording. 2. Press < or > to select a recording option. 3. Press play/pause to confirm the option. (Or press MENU to cancel the setting) REC Mode (Recording Mode) Adjust the quality that the player records in. VAD (Voice Activated Detection) The system will record automatically when an audio signal is detected;...
- Page 16 1. Select and confirm DELETE FILE 2. Select and confirm MUSIC or VOICE files to delete from the “Record” folder. The system will display files one by one (If VOICE was selected, the system will only display files in the “Record” folder. 3.
-
Page 17: Specifications
1. Select and confirm INFORMATION. 2. Select and confirm F/W VERSION to display the firmware version. 3. Select and confirm INTERNAL M. to display the memory usage of the internal memory disk; 4. Select and confirm SD/MMC CARD to display the memory usage of the SD/MMC card. -
Page 18: Warranty
Warranty: No guarantee or liability can be accepted for any changes and modifications of the product or damage caused due to incorrect use of this product. General: Designs and specifications are subject to change without notice. All logos brands and product names are trademarks or registered trademarks of their respective holders and are hereby recognized as such.
