UINICS SP-564A Series Instruction Manual

Rate and total digital indicator

Hide thumbs

Table of Contents

Quick Links

Download this manual

Rate and Total digital indicator

Series

Input

Output

signal

name

SP-564

AV3

AV4

AV5

No entry

Note 1

Note 1: V3, N option can not be selected simultaneously with the S24 option.

Note 2: RS2,RS4 and RS4W Option is DC24V 60mA max

Thank you for purchasing this UINICS product.

Please read this Instruction Manual carefully in order to ensure that you use the meter safely and

correctly.

【INSTRUCTION MANUAL】

MODEL：SP-564A Series

Communi-

Sensor

cation

power

No entry

RS2

RS4

RS4W

No entry

Note 2

S24

Power

Body

supply

color

Indicator 7-segment red LED

7-segment green LED

Two-row relay output

Analog voltage output DC 1-5V

Analog voltage output DC 0-5V

Analog voltage output DC 0-10V

Analog current output DC4– 20mA

NPN open collector pulse input

Voltage pulse input(Low: less than 2V, Hi:3.8-30V)

Current pulse input

Taco-generator signal input AC 0.8V-80V(P-P)3KHz MAX

Sine wave signal input AC 0.05V-20V(P-P)

Synchronous pulse output

RS-232C communication

RS-485 2-wire communication

RS-485 4-wire communication

Sensor power：DC12V 100mA max.

Sensor power：DC24V 50mA max.

No entry

Power source：AC 85V to 264V

Power source：DC 12V to 24V

No entry

Gray

Black

Function

(Low: less than 8mA,Hi:16-20mA)

【 2nd edition : Apr 9, 2012 】

@SP-564AE(2)

Table of Contents

Need help?

Do you have a question about the SP-564A Series and is the answer not in the manual?

Questions and answers

Summary of Contents for UINICS SP-564A Series

Page 1 Note 1: V3, N option can not be selected simultaneously with the S24 option. Note 2: RS2,RS4 and RS4W Option is DC24V 60mA max Thank you for purchasing this UINICS product. Please read this Instruction Manual carefully in order to ensure that you use the meter safely and correctly.
Page 2 1. SP-564（according to user’s specifications）・・・１ 2. Instruction manual for SP-564・・・１ 3. Unit label・・・１ 4. User-specified accessories. （In the case of the absence of such specifications, these accessories are not attached.） If accessories are insufficient, please contact with an agency or UINICS. - 1 -...
Page 3: Specifications
2. Specifications Item Specifications Operation system Periodic sampling operation (CPU) Display 7-segment red LED（14 mm character height）：6 digits GL-type 7-segment green LED（14 mm character height）：6 digits Rate mete ±0.05％ rdg.±１digit Measuring accuracy (at Sampling time for 0.5 second or more ）－９...
Page 4 EXT. Input NPN open collector pulse input or ground contact input Indicator When specified, input from the rear terminal board changes change indicator（Rate meter or Totalizer） Sensor input When specified, input from the rear terminal board deactivates deactivation sensor input. Reading hold When specified, input from the rear terminal board causes the input...
Page 5 《 RS-232C communication：RS2-type 》 Signal standards In accordance with EIA RS-232C standards（Serial signal） Synchronous method Asynchronous Baud rate 1200bps / 2400bps / 4800bps / 9600bps（Selectable） Start bit 1 bit Stop bit 1 bit Data bit 7 bits / 8 bits（Selectable） Parity bit Odd / Even / None（Selectable）...
Page 6 3. Mounting meter How to mount indicator (meter) １． Cut the panel to insert the indicator (meter) from the front. Panel cutout dimensions +0.8 Meter Installation board Fig.1 Packing Unit：mm ２ Please push the Fitting for fixing the body. Into a right and left both sides of the meter. Fitting for fixing the body Fig.2 ３.
Page 7 4．Names and functions of components on front Fig.4 Display Indicate Mode Output ① Display 1) Display indicates the rate reading or the cumulative total reading. 2) The following displays appear in the setup mode. A,B・・・・・Mode No. C-F・・・・・Mode setting 3) Setting value is indicated while each setting up（preset value, offset value）. ②...
Page 8 ⑧ Mode key ( Mode ） The Mode key is used to call up or switch between various settings. 1) Mode Activated for 2 sec. or more ・・・ calls up mode setting. （Press MODE → Mode No. switchover） 2) Mode ＋ ∧ Activated for 2 sec.
Page 9 5.Connecting terminal board Fig.６ Fig.５ ※ RS-232C/RS-485/RS-485W communication type：Refer to fig.5. (Terminal No.1-4) There is not the EXT. input the synchronization pulse output when select a communication type. Wiring precautions ！ Caution ・Always turn the power off before commencing any wiring work. ・Please confirm the specification.
Page 10: Sensor Connection
Sensor connection A）Pulse output 2-wire type sensor Fig.７ B）Pulse output 3-wire type sensor Fig.８ Sensor Proximity sensor Encoder ７８９１０ +12V IN ７８９１０ (+24V) +12V IN (+24V) C）Ground contact output sensor D）Tacho-generator signal/ Fig.９ Sine wave signal output sensor Fig.1０...
Page 11 6. Construction of input circuit [1] Pulse sensor input NPN open collector pulse input Fig.13 Voltage pulse input Fig.14 [2] Tacho-generator signal input/ Sine wave signal input Fig.15 [3] Reset input Fig.16 ・Sensor power DC12V（standard）：R1 = 2.2kΩ ・Sensor power DC24V（S24 type）：R1 = 3.9kΩ - 10 -...
Page 12: Setting The Dip Switch
[4] EXT. input Fig.17 ・Sensor power DC12V（standard）：R2 = 2.2kΩ ・Sensor power DC24V（S24 type）：R2 = 3.9kΩ 7. Setting the dip switch Fig.18 The input response frequency is selected by setting the dip switch. Table 1 SW1-1 SW1-2 SW1-3 SW1-4 OFF ⇔...
Page 13: Test Mode
8. Test mode - 12 -...
Page 14 9. Initial setting values and initialization If the specifications desired by the user are requested prior to shipment, the meter will be set these settings. Otherwise, the regular factory settings are shown below. １.Value setting of each Mode Table 1 Mode Initial setting Note...
Page 15: Setting The Mode
10. Setting the mode ・Calling up and modifying the mode setting When a mode is set, operate each key according to the following table. Operating key Display unit Operation procedure ＡＢＣＤＥＦ While holding down the MODE key, press the ０...
Page 16 Contents of modes and setting values Mode No. Setting of converting value (scaling) ＡＢＣＤＥＦ０１０１．１０００ Converted value 0001～9999 (Do not set 0000) ①This mode “01" acts as input converter. Mode “02"-C acts as magnification(EXP-value).
Page 17 Mode No. EXP-value, and measurement time unit setting ０２ＡＢＣＤＥＦ０２．３０１１ Display decimal point setting 0･･･ 1･･･ 2･･･ 0.00 3･･･ 0.000 4･･･ 0.0000 measurement time unit 0 ･･･ per Hour 1 ･･･...
Page 18 Mode No Moving average setting ０４ＡＢＣＤＥＦ０４．０ Moving average 2～9 times (0,1 setting meaning no function) It inputs the number of times (0-9) of input pulse. For instance, upon setting “4" ,the average of 4 pulses can be calculated and displayed.
Page 19 Mode No. Display selection, External input selection ＡＢＣＤＥＦ０６０６．００ Display selection 0 ･･･ Change over rate and total count 1 ･･･ Only rate display 2 ･･･ Only total count display External input selection 0 ･･･...
Page 20 Mode No. Totalizer : Decimal point, Counting method, Reset, Converter ＡＢＣＤＥＦ０８０８．３０００ Display decimal point setting 0･･･ 1･･･ 2･･･ 0.00 3･･･ 0.000 4･･･ 0.0000 Counting method 0･･･ additional count 1･･･...
Page 21 Mode No. Analogue output ＡＢＣＤＥＦ０９０９．００ Analogue shift 0･･･ Comparative output with right 4digits 1･･･ Comparative output with central 4 digits 2･･･ Comparative output with left 4digits Output selection for rate or total count 0･･･...
Page 22 Mode No. Display value at output time of analogue max. ＡＢＣＤＥＦ１０１０．１０００ setting maximum display value at maximum analogue output Input 0001 - 9999 (Do not set 0000) Set an indication value of the time when the analog output is maximum. Set a value in four digits, neglecting the decimal point.
Page 23 Mode No. Alarm output selection ＡＢＣＤＥＦ１２１２．００ OUT2 alarm output selection ０：Function stop １：Rate meter ２：Totalizer OUT1 alarm output selection ０：Function stop １：Rate meter ２：Totalizer OUT1 alarm output selection Function stop･･･OUT1 alarm output function stop Rate meter･････Compare rate meter indication value to Preset value.
Page 24 Mode No. OUT1：Setting the alarm output P2-type ＡＢＣＤＥＦ１３１３．００００ Output mode（2-9：One shot output）０：Comparison ５：100 ms. １：Hold ６：250 ms. ２：30 ms. ７：500 ms. ３：50 ms. ８：1 sec. ４：80 ms. ９：2 sec. Upper or lower limit selection ０：Upper limit １：Lower limit ( Immediate )
Page 25 Mode No. OUT2：Setting the alarm output P2-type ＡＢＣＤＥＦ１４１４．００００ Output mode（2-9：One shot output）０：Comparison ５：100 ms. １：Hold ６：250 ms. ２：30 ms. ７：500 ms. ３：50 ms. ８：250 ms.（Zero return）４：80 ms. ９：500 ms.（Zero return）...
Page 26 Mode No. Setting the communication RS2-type / RS4-type / RS4W-type ＡＢＣＤＥＦ１５１５．０１０３ Baud rate ０：1200 bps １：2400 bps ２：4800 bps ３：9600 bps Parity bit ０：None １：Even ２：Odd Data bit ０：7 bit １：8 bit Communication selection ０：Not used（※）...
Page 27 11．Operation explanation for totalizer 1) Totalizer starts measurement from zero or offset value.（addition or subtraction） 2) Display range：-99999 to 999999 The Overflow (OV) lamp is blinking activated when the total exceeds 999999 (or -99999). While blinking indication, it continues measurement from 000000 or -00000. 3) The over times（the overflowed upper 3 digits）are displayed while Up key is pressed.
Page 28 １2．Mode protect function If this function is turned ON, change of mode setting will be made impossible. （The Up key and Down key is canceled.） The mode protect at the time of the shipment becomes OFF. Operation of the mode protect 1.
Page 29: Setting The Offset Value
１３．Setting the offset value The preset total reading value to be displayed directly following a reset is specified. For example, if the offset value is set at “001000”, the reading becomes “1000” when reset, and the count resumes from “1000”. In order to start the count from “0”, the offset value should be set as “000000”.
Page 30 １４．Setting the alarm preset value Set the preset values on the upper and lower limits in alarm output. The setting range is -99999-999999. Operating Display unit Operation procedure ＡＢＣＤＥＦ Press the key for 2 seconds or more. ９...
Page 31 15. Adjusting the tacho-generator signal, sine wave signal input The input (V3, N) range is adjusted correctly at the factory. Please do not touch except necessity/ V3-type：Taco-generator signal input AC 0.8V-80V(P-P) N-type ：Sine wave signal input AC 0.05-20V(P-P) While looking at display , adjust an adjustment volume. The adjustment volume is located as shown in fig20 (Fig.
Page 32: Adjusting The Analog Output
16. Adjusting the analog output The analog output（AV3 - 5,AI）range is adjusted correctly at a factory. Please do not touch except necessity. ・Tune in exactly 1. Power on Mode key being pressed to put the instrument into the test mode. 2.
Page 33 17.Communication format （RS2-type / RS4-type / RS4W-type）・Communication command Command (Host) Response (Indicator) 1. Rate meter data read Ｃ＠□□ＲＤＴ△△ ＲＣ＠□□◇◇＋０１２３４５△△ Ｒ 2. Totalizer data read fixed Ｃ＠□□ＲＣＴ△△ ＲＣ＠□□◇◇＋０１２３４５△△ Ｒ 3. Preset value OUT1 read fixed Ｃ...
Page 34 ≪ ID ≫ The ID number（00-99）of the unit of the place of the communication is specified. ≪ Checksum processing method ≫ Transmission command data become the next. ID number：00, In the case of “Reset” Ｃ “＠００ＲＳＴ△△ ” Ｒ ↑ This is subjected to a checksum. “＠”＋“０”＋“０”＋“Ｒ”＋“Ｓ”＋“Ｔ”...
Page 35 ■ Internal circuit 1. RS-232C（RS2-type） Fig.22 １ＴＸ２ＲＸ４Ｓ.Ｇ. 2. RS-485 2-wire（RS4-type） Fig.23 １ＲＸ２ＴＸ３（N.C.） 3. RS-485 4-wire（RS4W-type） Fig.24 １ＴＸ２３ＲＸ４ - 34 -...
Page 36: External Dimensions
18. External dimensions Fig.2５ Fig.26 - 35 -...
Page 37 These specifications and the like may be revised for improvement without prior notice, which please understand and accept. Head Office : 123-1,Kami,Nishiku,Sakai-city,Osaka,Japan. TEL.81-72-274-6001 FAX.81-72-274-6005 Tokyo Branch : TEL.81-3-5256-8311 FAX.81-3-5256-8312 - 36 -...
