Page 1 HOME AUTOMATION, INC Lumina Lighting and Automation System Advanced Application Guide Document Number 44R00-1 Rev. 2.12 March, 2006...
Page 3: Table Of Contents
Contents INTRODUCTION............................1 Planning ......................................1 INSTALLATION............................2 Mount the Lumina Enclosure................................3 Ground the Lumina Controller.................................3 Connect the Powerline Interface Module (PIM) to the Lumina.......................3 Install the Lumina Keypad................................4 About Zones Inputs..................................6 Zone Hookups.....................................6 About Outputs....................................6 General Purpose Switching Applications ...........................6 Reset Outputs....................................7...
Page 4 About UPB.....................................21 HAI Lighting Control (HLC) Format.............................22 About Rooms ....................................22 About Room Controllers................................22 Room Controller LED Indicators..............................22 About House Controllers ................................23 About Lumina Mode Controllers ..............................23 About CentraLite ...................................23 About Lutron RadioRA..................................23 About ALC.....................................24 ALC Module Types ..................................24 About X-10 ....................................24 House Codes ....................................24...
Page 5 Humidity ......................................40 STATUS ................................. 41 Control Unit Status ..................................41 Configuring HLC Devices ................................41 Configuring HLC Devices using a Lumina Keypad .........................42 Configuring HLC Devices using an OmniTouch Touchscreen ....................42 Setup Mode for HLC Devices..............................42 HLC Switches and Dimmers ..............................42 HLC Room Controllers.................................42 HLC House Controllers ................................43...
Page 6 9 - Good-Bye....................................52 Voice Dialer ....................................52 How the Lumina Voice Dialer Works ............................52 What the Lumina Voice Dialer Does ............................53 What You Hear - If Your Lumina Calls You..........................53 Entering the Code ..................................53 PC Access ......................................53 Built-In Serial Ports ..................................53 Built-In Ethernet Port..................................55...
Page 7 Edit Program Condition .................................71 Program Control Conditions ..............................71 Program Lumina Mode Conditions ............................71 Program Zone Conditions.................................72 Program Time Clock Conditions ..............................72 Program Other Conditions ................................72 Set Up Dial ....................................73 Telephone Access ..................................73 Answer Outside Call.................................73 Remote Commands...................................73 Rings Before Answer................................73 Dial Type ....................................73...
Page 8 About Room Controllers................................95 Room Controller LED Indicators..............................95 About House Controllers ................................95 About Lumina Mode Controllers ..............................96 APPENDIX B – HLC PLANNER ....................... 98 APPENDIX C - TEXT DESCRIPTION CHARACTER CODES ............101 APPENDIX D – VOICE DESCRIPTION CODES ................. 102...
Page 9: Introduction
Please take a few moments to become familiar with all of the features of your system by reviewing this guide. This guide is intended as an aid to installing, programming and operating the Lumina lighting and automation system. Keep this guide on file for future reference.
Page 10: Installation
INPUT INPUT INPUT ZONES 1-16 ARE CONFIGURABLE FOR AUXILIARY OR TEMPERATURE. ONLY ZONES 9-16 MAY BE CONFIGURED AS ENERGY SAVER ZONES. HAI REMOTE ONLY ZONE 16 MAY BE USED FOR HAI REMOTE CONTROL THERMOSTATS. CONTROL THERMOSTAT(S) POWER TRANSFORMER Status REVERE <Program...
Page 11: Mount The Lumina Enclosure
Locate the supplied PIM (P/N: 36A00-1). Plug the PIM into a 120 VAC outlet. Plug one end of the supplied 6-conductor modular cable into the connector marked “J3” (SERIAL 3) on the Lumina controller and plug the other end into the modular connector on the PIM as shown.
Page 12: Install The Lumina Keypad
Install the Lumina Keypad 1. 8 Lumina Keypads (Models 33A00-19 and 33A00-20) MAXIMUM per system, subject to power availability. 2. Use 4-conductor 22-gage wire, 1000 feet maximum length. Keypads can be homerun or daisy chained. This length shall be divided by the total number of keypads at the end of the run. For example, for 8 keypads, the maximum length reduces to 125 feet.
Page 13 Keypad Setup The keypad has different operating options that can be setup from the keypad to the user's preference. If more than one keypad is being used, it is required that you give each keypad a different address. You can change the address of a keypad through the keypad setup mode.
Page 14: About Zones Inputs
About Zones Inputs Each of the 48 zone inputs on a Lumina system may be configured as a trouble, a freeze, a water, an auxiliary, an outdoor temperature, a temperature, a temperature alarm, or a humidity input. Zones 9-16 are the only inputs that can be configured as a PESM.
Page 15: Reset Outputs
0 to 100 percent or for sensing the outdoor temperature and/or reporting the outdoor relative humidity. The outdoor temperature can be displayed on the keypad, spoken over the telephone, or displayed on an HAI Communicating Thermostat.
Page 16: Hai Thermostats
Run a 3 (or 4) conductor wire from Lumina to the thermostat location. All thermostats are connected in parallel to Zone 16 and Output 8. Connect the red COMM cable wire with the black COMM cable wire. Make the connections (as shown below) using the supplied wire splices.
Page 17: Programmable Energy Saver Modules
Zone 16 and Output 16, respectively 1. Lumina can support up to 8 Programmable Energy Saver Modules (PESM). Each PESM requires one zone input and one controller output. The zone input corresponds to the controller output (Zone 9 and Output 1 through Zone 16 and Output 8, respectively).
Page 18 An outdoor temperature switch that prevents the auxiliary heat from coming on unless it is very cold outside. This is sometimes called a "heat balance" switch. A thermostat that uses rate of rise to determine if auxiliary heat is necessary: The Enerstat Model DSL-450. When recovering from setback, the thermostat runs the heat pump first.
Page 19: Telephone Connections
PHONE LED will come on. When the phone line rings, the PHONE LED will light. 6. If the Lumina is accessed on an in house telephone, the Lumina will disconnect the phones from the phone company lines and supply its own talk voltage to the phones.
Page 20: System Power Up Procedure
SYSTEM POWER UP PROCEDURE Connect the Power Transformer a) Connect the supplied 24V, 40VA Power Transformer using the supplied Power Cable (P/N: 44A07-1). b) Plug the Power Transformer into a 120 VAC outlet. - The “AC ON” LED (D25) should illuminate. - Within one minute, the “STATUS”...
Page 21: Keypad Check Out
Time is not currently being observed (between fall and spring) or is not observed in your geographic location, set this item to "No". This item is used to correctly calculate the times for sunrise and sunset. Once the time is set, the Lumina controller will automatically adjust the "time of day"...
Page 22 2. Unplug the power transformer. 3. Disconnect the battery 4. Disconnect the RJ31X modular cable at the jack!! If you only disconnect it at the Lumina controller only, the house phones won't work. 5. Disconnect the UPB PIM and/or X-10 cable. Disconnect the serial cable(s). Disconnect Ethernet cable.
Page 23: Overall Description
OVERALL DESCRIPTION At the heart of Lumina are six standard modes: Home, Sleep, Away, Vacation, Party and Special. These modes can be activated at the touch of a button, by time schedule, or event. The system includes HAI’s Advanced Control Programming (ACP) logic that allows you to set schedules and actions performed by the system, and add new macros to modes as desired.
Page 24: Keypad Operation
The Lumina Keypad is designed with everything that is necessary for you to program and operate your Lumina lighting and automation system. Because we feel that it is very important for you to feel comfortable with the operation of your Lumina, we recommend that you start by becoming familiar with your keypad.
Page 25: Normal Top-Level Display
(10) KEYPAD DISPLAY The Keypad Display is used to show the current mode and to give useful information that will guide you through normal operations of your Lumina lighting and automation system. (11) NUMERIC KEYPAD The Numeric Keypad is used to access to different menus in your system and to a number for a specific function. From the top-level display, each key functions as a menu choice.
Page 26: Main Menu
Trouble Beeps The Lumina constantly checks the entire system for proper operation. If trouble is found, the trouble is displayed on the bottom line and the keypad will beep at the rate of two beeps per second to alert you to the trouble. This feature can be turned off if desired - See Set Up Area, Beep On Trouble.
Page 27: Time Out
Silencing an Alarm At any time, the alarm can be silenced by pressing the ' * ' key at the Lumina keypad. When the alarm is silenced, it may continue to display the alarm condition (i.e. Water Sensor Tripped) until the condition is no longer present.
Page 28: Codes
Codes There are 16 user codes that you may assign to users of the system. All Lumina codes are 4 digits in length. A code can be any number from 0001 to 9999. Each user should be assigned a code with an authority level, and times and days in which the code will be valid - See Set Up Codes.
Page 29: Control
Control Commands The control features of the Lumina make it easy and convenient to control almost any light or appliance from the keypad, touchscreen (optional), or over the telephone (optional). You may also have your heating and air conditioning (HVAC) under control of the system, which will allow you to save energy dollars by setting the temperature appropriately when you are home, asleep, away, or on vacation..
Page 30: Hai Lighting Control (Hlc) Format
HLC format is a defined structure for configuring, programming, and operating all the HLC lighting devices in your home. Each “House Code” that is configured to use the HLC format consists of 2 rooms with up to 8 HLC devices in each room. Lumina supports up to 8 rooms of HLC lighting.
Page 31: About House Controllers
For example, Unit 8, 16, 24, 32, 40, 48, 56, and 64 may be used for Lumina Mode Controller. This allows you to have up to 8 Lumina Mode Controllers throughout the house.
Page 32: About Alc
ALC signal wiring to ALC Switch Modules. ALC Switches communicate with the Lumina over low voltage signal wire. They are two-way devices, so the controller always knows the actual status of the switch.
Page 33: Unit Numbers
4=ALL Lumina will automatically display the first named item in that list. The down arrow key can then be used to scroll through the list, and the ' # ' key is used to select the item. If the specific item number is known, enter the item number followed be the ' # ' key, or scroll up and down among the named items.
Page 34: Configuring Lighting Scenes In An Hlc Room
(Scenes A-D) and one “On” Scene (preset lighting levels for each device when the room is turned on). To set a lighting scene using the Lumina keypad, adjust all of the HLC devices in the room to the desired lighting levels.
Page 35: Controlling Centralite Units
• Timed commands may be from 1-99 seconds, 1-99 minutes or 1-18 hours. Press # (STA) to see the exact status of a UPB device. When the ' # ' key is pressed, Lumina sends a “Status Request” message to the selected device for its current state. The exact state is then displayed.
Page 36: Controlling Alc Or X-10 Units
Controlling ALC or X-10 Units Entry Lights ↓ 0=OFF 1=ON 2=DIM 3=BRT Entry Lights ↑ 4=LVL 5=RMP 9=TIM #=STA Press 0 (OFF) to turn the selected unit off. Press 1 (ON) to turn the selected unit on. Press 2 (DIM) to dim the selected unit (1-9 steps, each step is 10% from its current level). Press 3 (BRT) to brighten the selected unit (1-9 steps, each step is 10% from its current level).
Page 37: Controlling Compose Units
Controlling Compose Units Entry Lights ↓ 0=OFF 1=ON 2=DIM 3=BRT Entry Lights ↑ 4=SCN 9=TIM #=STA Press 0 (OFF) to turn the selected unit off. Press 1 (ON) to turn the selected unit on. Press 2 (DIM) to dim the selected unit (1-9 steps, each step is 10% from its current level). Press 3 (BRT) to brighten the selected unit (1-9 steps, each step is 10% from its current level).
Page 38: Status Of A Unit
The Lumina has eight outputs that can be used to switch relays. Outputs 1-8 are controlled as Unit Numbers 65-72, respectively. The Lumina has 2 additional outputs labeled INT HORN and EXT HORN. Unit Number 73 is used to control INT HORN output and Unit Number 74 is used to control the EXT HORN output.
Page 39: Mode
Selecting a Lumina Mode You can select the mode from the mode menu on a Lumina keypad. To enter the mode menu, from the top-level display or from the main menu, press the 2 (MODE) key on the numeric keypad.
Page 40: All
UPB: Program a Link into each device that will respond to the Lumina “All On” and “All Off” command program. For example: In each UPB switch that will respond to “All Off” and “All On”, program a Link (in this example, Link 50 is used) that will go to 100% when activated (turned on).
Page 41: Leviton Scene Control
Leviton Scene Control Lumina supports Leviton Scene Control (a feature found in certain Leviton Switches). There are 64 Scenes that can be set and executed. The Leviton Switches are divided into "lighting groups" of four units each. Each of these lighting groups can be set to four different Scenes.
Page 42: Scene Off Command
A special UPB command called “Link Off” (deactivate) is used to command all of the devices that have the same Link to go to 0% at their preset fade rate. For instance, in our “All On” and “All Off” example, when “Link 50 Off” is transmitted by Lumina, each Wall Switch with Link 50 will go to 0% to achieve the “All Off”...
Page 43: Executing Phantom Buttons
Executing CentraLite Scenes Lumina can turn on and turn off each of the 255 possible CentraLite Scenes. To issue CentraLite Scenes commands, from the top level display or from the main menu, press the 4 (ALL) key on the numeric keypad, and then press the 5 (CENLIT) key. You are prompted to enter a Scene (1-255).
Page 44: Hai Communicating Thermostats
Press the ' # ' key when the desired temperature zone is shown. Press the ' 0 ' key to select all HAI Thermostats. This is a simple way to broadcast the new Heat or Cool setting or change the system mode, fan mode, or hold mode of all HAI thermostats in your system.
Page 45: Programmable Energy Saver Modules (Pesms)
(HVAC) system thermostat. The PESM allows the Lumina to read the temperature of the area that the HVAC system controls. When you are away or asleep, the PESM can be set to allow the temperature to drift higher or lower to reduce the operating time, hence saving energy dollars.
Page 46 You can turn the energy saver on, off, use a timed on/off, and change the Heat and Cool temperatures from the keypad or by telephone. Commands can also be programmed so that they occur by time schedule or by event, such as Lumina mode change.
Page 47: Freeze Alarms
Downstairs ↓ 0=OFF 1=ON 2=HEAT Downstairs ↑ 3=COOL 9=TIME #=STAT ENTER TIME MINUTES (1-99) #=H/M/S Downstairs FOR 15M ↓ 0=OFF 1=ON The current status of a temperature zone may be displayed by selecting ' # ' (STAT) key from the main temperature menu. The status display differs depending on the temperature zone type.
Page 48: Temperature Control Of Appliances
You can control appliances connected to X-10 and ALC modules (such as a ceiling fan) using Advanced Control Programming (ACP) of the Lumina. For example, the ceiling fan can be programmed to come on if the temperature goes above the High temperature.
Page 49: Status
When configuring HLC devices using a Lumina keypad or OmniTouch touchscreen, each device (unit number) must first be assigned a name in the Lumina controller. HAI recommends that you first configure your Lumina controller (naming all of the HLC units) using the HAI PC Access Software, and then download the information to the Lumina controller.
Page 50: Configuring Hlc Devices Using A Lumina Keypad
Operation Tap the rocker switch quickly 5 times. The HAI UPB™ Wall Switch or Dimmer will flash the lighting load one time and blink its LED blue to indicate that it is in Setup Mode. Note: The switch will automatically exit Setup mode after 5 minutes. To manually exit Setup mode, tap the switch quickly 2 times.
Page 51: Hlc House Controllers
Test Status The diagnostic test performed by the Lumina allows you to check the status of the battery, telephone, bell circuit, auxiliary fuse, and zone loop readings. The display is updated 3 times per second, although the actual readings are taken 10 times per second.
Page 52: Temperature Status
The second part shows how the Lumina is currently using the phone line: IDLE - NOT USING THE PHONE LINE LOCAL - LOCAL ACCESS REMOTE - REMOTE ACCESS VOICE - IN VOICE DIAL OUT MODE EMGACC - ACCESS AFTER VOICE DIAL OUT...
Page 53: Events
USER NAME REM ACCESS An event is logged after three unsuccessful attempts are made to log into the system from a remote phone, the Lumina will lock out remote telephone access for 1 hour to discourage any further attempts to access the system - See Telephone Control.
Page 54: Messages
Say Message Note: To Say a message, the HAI Two-Way Audio Module (with a speaker) must be installed. The 4 (SAY) key allows the controller to say the selected voice message over a speaker. This voice message can be an audible reminder of special events and occasions.
Page 55: Phone Message
128 messages for a matching message. If one is found, the Program Command (macro) corresponding to the matching message is activated. When receiving an ASCII message that is over 15 characters, Lumina only processes the last 15 characters of the message. Pro-Link determines that a message has been received when: •...
Page 56: Telephone Control
In-House Phones Each time you pick up your telephone at home, the Lumina will also pick up the line and listen for a # (pound) key. If Lumina does not hear the # key within 5 seconds, it hangs up and does not listen in again until the next time you pick up your phone. If the Lumina hears any key other than the # key while it is listening in, it disconnects itself immediately.
Page 57: Phone Access Denied - Remote Lockout
If you press a key that is not on the current menu, you will hear 3 beeps and the menu will be repeated. So that the Lumina does not tie up your phone, there is a 10 to 15 second time-out that starts after the Lumina stops talking. If it does not hear any numbers from your phone in 10 to 15 seconds after it stops talking, the Lumina will hang up.
Page 58: Control
Press the temperature zone you wish to control, then press #. Press the ' 0 ' key to select all HAI Thermostats. This is a simple way to broadcast the new Heat or Cool setting or change the system mode, fan mode, or hold mode of all HAI thermostats in your system.
Page 59: Status
Press 7 from the MAIN MENU to get to the EVENT menu. The Lumina will read the 3 latest events. Press the ' 7 ' key for Lumina to read 3 more events, or ' * ' to cancel. Page 51...
Page 60: Phone
The Lumina will say, "GOOD-BYE" and hang up. From an in-house phone, the dial tone will return. From a remote phone, you will hear a click as the Lumina hangs up. It is recommended that you press 9 to terminate a remote call. If you don't, the Lumina will hang up in about 15 seconds.
Page 61: What The Lumina Voice Dialer Does
WATER ALARM ACTIVATED: BASEMENT - TRIPPED Then the Lumina will read the Main Menu as described in Telephone Control. You can press 0 to hear the menu. At this point, you are in control, just as if you had called your system.
Page 62 To access a serial port, use the HAI Model 21A05-2 Serial Cable Kit. Plug one end of the cable into one of the modular serial port connectors on the controller. Plug the other end into the Model 21A05-1 Communication Cable Adaptor (modular to DB-9 RS-232), which connects the Lumina serial port to the computer's DB-9 RS-232 port.
Page 63: Built-In Ethernet Port
Built-In Ethernet Port The built-in Ethernet port (J6) allows a device to connect to the Lumina controller via a network (i.e. Ethernet, Internet) using a secure, encrypted communication link. The Ethernet port transports HAI application-level packets containing Omni-Link serial protocol messages over IP. The controller supports 3 unique client “sessions” which means 3 devices may actively be connected and communicating with the controller simultaneously over the Ethernet port.
Page 64: Dynamic Dns
(the router/switch) in the local network. This allows you to locate and connect to the Lumina controller without having a computer on the local network powered up and running.
Page 65 To connect to a Lumina controller from the Internet using HAI PC Access, under Configure >> Network enter the public IP address: To connect to a Lumina controller on a local network using HAI PC Access, (i.e. 134.42.112.8) under Configure >> Network enter the controller’s IP address:...
Page 66: Setup
Set Up Codes Lumina has 16 user codes that you may assign to users of the system. All Lumina codes are 4 digits in length (0001 to 9999). Each user can be assigned a code with an authority level and times in which the code will be valid. To set up a code, from the Setup menu, press the 1 (CODES) key.
Page 67: Set Up Time
This item is used to correctly calculate the times for sunrise and sunset. You are only asked this question when you set the time. Once the time is set, Lumina will automatically adjust the "time of day" each time daylight savings time begins and ends.
Page 68: Advanced Control Programming (Acp)
Advanced Control Programming (ACP) Your Lumina can be programmed to do automated control functions on a time schedule or in response to an event occurring in the system. You may program the following items: • Unit Numbers: On, Off, On for time, Off for time, Dim, Brighten, Dim for time, Brighten for time, Level, and Scene •...
Page 69 Menu 1 - Programs for a particular control unit number Menu 2 - Programs to change the Lumina mode Menu 3 - Programs for a particular macro button Menu 4 - Programs for All On/Off and Scene functions Menu 5 -...
Page 70: Delete All Programs
The arrow keys are used to scroll through the programs. Pressing the ' # ' key while a particular program is displayed will allow that program to be edited or deleted. The display shows: SHOW PROGRAM 1=EDIT 2=DELETE Press the 1 (EDIT) key to edit the selected program. The Edit Program menu is displayed which allows the various parts of the program to be changed - See Edit Program.
Page 71: Edit Programs When
Edit Programs When Selecting the 1 (WHEN) key, from the Edit Program menu, allows the time or button/event that activates the program to be changed. The display shows: EDIT WHEN 1=TIMED 2=BUTTON Times Programs Selecting 1 (TIMED) sets the program to be activated at a specific time of day. You are prompted to enter the time and date or days of week.
Page 72: Button And Event Programs
A specific macro button may be activated by entering the button number followed by the ' # ' key, or by using the arrow keys to scroll through a list of buttons. To program specific event buttons (i.e. Front Door Opens, Lumina Mode Changes, Porch Light Turns On, etc.), press the ' # ' key to bring up a menu of event button types: BUTTON TYPE ↓...
Page 73: Lumina Mode Event Buttons
5 or I 6 or J 7 or K 8 or L Lumina Mode Event Buttons Pressing the 2 (MODE) key allows you to select the event button that will be activated when the Lumina mode changes: 1=HOME 2=SLEEP ↓ 3=AWAY...
Page 74: Zone Event Buttons
“Link Goto” (where the result of the Goto command is “0”) message is received. Using HAI PC Access Software, you can create a program that uses “When Link Fade Stop” as the trigger. When this trigger is used, the program will execute when the “Link Fade Stop” message is received.
Page 75: X-10 Event Buttons
Pressing the 6 (X-10) key allows you to specify an event button activated upon receipt of an X-10 command from a source external to Lumina. The Lumina can also respond to scene changes initiated at Compose keypads and dimmers. When a scene change is initiated, Lumina can activate an event button program.
Page 76: Message Event Buttons (Pro-Link)
Message Event Buttons (Pro-Link) Pressing the 8 (MSG) key allows you to select an event button from a list of the 64 text messages. You are first prompted to select the message: MESSAGE: ↓ ENTER MESSAGE The message may be entered by entering the message number followed by the ' # ' key or by using the arrow keys to scroll through the list of messages.
Page 77: Unit Toggle Command
WHEN LINK 1 ON: Porch Light STATUS When “Link 1 On” is received on the UPB network, Lumina sends a status request message to the UPB Wall Switch (named Porch Light) to acquire its current status. This “Status Request” program is particularly beneficial to keep the current state of UPB devices that are altered by a “lighting scene”...
Page 78: Lumina Mode Commands
Lumina Mode Commands Press the 2 (MODE) key to set the Lumina mode – See Mode. The following menu is displayed: 1=HOME 2=SLEEP ↓ 3=AWAY 4=VACATION 5=PARTY 6=SPECIAL ↑ Select (1-6) to set the desired Lumina mode. Program Button Commands Select the 3 (BUTTON) key to program a macro button.
Page 79: Program Video Commands
IF Porch Light: 0=OFF 1=ON Program Lumina Mode Conditions Press the 2 (MODE) key to specify that the program should only execute if Lumina is currently set to the desired mode. Select the Lumina mode from the following menu: 1=HOME...
Page 80: Program Zone Conditions
INCLUDE DELAY? 0=NO 1=YES Program Zone Conditions Select the 3 (ZONE) key to specify that the program should only execute if a specified zone is either Secure or Not Ready. The display prompts you for the zone number: ZONE: ↓ ENTER ZONE Enter the zone number followed by the ' # ' key, or use the arrow keys to select the zone.
Page 81: Set Up Dial
My Phone Number My Phone Number is the phone number that will be announced when the Lumina dials out in the event of an alarm. It should be set to the phone number of the premises where your system is installed.
Page 82: Dial Out Number 1
DIAL OUT 1 OFF Dial Out Number 1 has two times associated with it, an On and Off time. The Lumina will only call this number if the time and days are between the Dial Out 1 On and Dial Out 1 Off times and dates.
Page 83: Set Up Area
Beep On Trouble If the Lumina detects any troubles with itself or one of the zones connected to it, it will display a message on the screen and beep the keypad twice per second, continuously (i.e. beep beep...beep beep...). You can silence this sound by pressing the ' * ' key.
Page 84: House Codes 1-4 Format
2. When the House Code is configured as UPB, RadioRA, or CentraLite, “House Code All Off” does not affect the state of the installed devices; however, if this setup item is set to “Yes”, Lumina will change the status of all units on that House Code to “Off”...
Page 85: Time Clocks
Prime Meridian, and time zone. These items should be set to the proper values for the location where the Lumina is installed. The latitude and longitude for a particular location may be obtained from an almanac or map of the area. These values should be entered to the nearest degree.
Page 86: Daylight Savings
It is not necessary to alter the time zone to compensate for daylight savings time, the Lumina will automatically adjust its calculations for sunrise and sunset, and time when daylight savings time begins and ends. LATITUDE: 0-60 LATITUDE N/S: 1=NORTH 2=SOUTH...
Page 87: Controller Ip Address
Controller IP Address The controller’s local network IP address is used to identify the Lumina controller on the network. To view and assign the ↓ controller’s local network IP address, from the Set Up menu, press the 6 (MISC) key. Using the down arrow key (...
Page 88: Set Up Names
There are two ways to enter a name for units, zones, buttons, and temperatures: 1) Lumina has a list of predefined names that you to select from (Quick-Set Names) 2) You can enter the two-digit code shown in Appendix C for each character in the name Note: To assign names to codes and messages, you must use the two-digit codes as shown in Appendix C.
Page 89: Delete A Name
Set Up Voice The Lumina can be set up to speak descriptive names such as "FRONT DOOR" for control zones, units, buttons, codes, temperatures, and messages. These names will be spoken over the telephone along with the item number that is normally spoken.
Page 90: Installer Setup
When “Status Tracking” is enabled, this is done automatically after a scene is executed. The value set for the UPB Status Time is the amount of seconds that the Lumina controller waits before requesting status after a scene is executed.
Page 91: X-10 3-Phase
Receiver are Zones 33-48 on the Lumina. Zone Resistors This item is used to specify if the 1000-ohm end-of-line zone resistors will be used with zone inputs on the Lumina. If this item is set to "Yes", all zones are required to use an end-of-line resistor.
Page 92: Zone Types
TROUBLE This zone type can be used to monitor the status of an external device, such as the battery status of a wireless receiver or the HAI Touchscreen Hub. It can also used to record events in the event log (i.e. driveway activation, opening of a gate, etc.).
Page 93: Setup Temperatures
Thermostat Type If HAI thermostats are part of the system, this item specifies the thermostat type for each thermostat (this enables the thermostat). When any Thermostat Type is changed from the default setting of "Not Used", Zone 16 and Output 8 is automatically configured for thermostats.
Page 94: Setup Miscellaneous
Dead Line Detect NOTE: To disable Lumina from detecting a dead line, set this item to '0'; otherwise adjust only under direction of HAI. This item adjusts the threshold that is used to determine when the phone line goes dead.
Page 95: Pickup After Hangup
Clock Adjustment If the clock on your Lumina is running faster or slower than the actual time, you can have the Lumina automatically compensate up to 29 seconds per day. The Lumina will add or subtract the selected amount of time daily.
Page 96: Setup Expansion
Serial 1 Rate "Serial 1 Rate" selects the baud rate used for the first built-in serial interface (J1 Serial) on the Lumina controller. Select the baud rate for the first built-in serial interface from the list. Use the arrow keys to select the baud rate then press the ' # ' key.
Page 97: Serial 1 Function
Serial 4 Rate "Serial 4 Rate" selects the baud rate used when a Serial Interface Module is added to the Lumina system. If a Serial Interface Module is installed, select its baud rate then press the ' # ' key.
Page 98: Set Up Address
Pick up an inside phone and press the ' # ' key on the telephone within 5 seconds of picking up the phone. The Lumina will respond with a menu. Press 8 on the telephone keypad, then 8. The unit will say "ADDRESS IS:" then the Lumina will play back the message stored in the Address memory if one has been entered by your installer.
Page 99: Lumina Specifications
AUX 12 VDC SWITCH 12 VDC CONSOLE OUTPUTS 1 - 8 100 mA UNDERWRITER'S LABORATORIES (UL) LISTING The 44A00-1 Lumina controllers and keypads have been tested and Listed by UL for the following applications: • Enclosed Energy Management Equipment Page 91...
Page 100: Federal Communication Commission Notice
FEDERAL COMMUNICATION COMMISSION NOTICE: This equipment complies with Part 68 of FCC Rules. On the door, inside of the Lumina enclosure, is a label that contains, among other information, the FCC registration number and Ringer Equivalence Number (REN) for this equipment. If requested, provide this information to your telephone company.
Page 101: Canadian Industry Canada Notice
IF YOU HAVE TROUBLE WITH YOUR PHONES ...and you suspect that your Lumina is causing the trouble, disconnect the Controller from the phone lines by removing the PHONE LINE cable from BOTH THE PROCESSOR BOARD AND THE RJ31X JACK INSIDE THE CONTROLLER ENCLOSURE.
Page 102: Appendix A - Understanding Hlc
HLC format is a defined structure for configuring, programming, and operating all the HLC lighting devices in a home. Room Controllers control up to 7 lighting loads in a room. House Controllers control up to 8 Rooms of HLC lighting. Lumina Room Controllers set the Lumina mode.
Page 103: About Room Controllers
Room Controllers also keep track of when individual switches in a room are turned on and off. When all of the lighting loads in a room are turned off, the “Off” indicator is illuminated. If any of the lighting loads in a room are turned on at an HAI UPB™ Wall Switch or Dimmer, the “On”...
Page 104: About Lumina Mode Controllers
For example, Unit 8, 16, 24, 32, 40, 48, 56, and 64 may be used for Lumina Mode Controller. This allows you to have up to 8 Lumina Mode Controllers throughout the house.
Page 105 APPENDIX A – UNDERSTANDING HLC Page 97...
Page 106: Appendix B - Hlc Planner
Lighting Load Room Controller Unit 8 Lighting Load House Mode Room 2 is the Kitchen. The Kitchen consists of 1 Room Controller, 6 Lighting Loads, and one Lumina Mode Controller. ROOM 2: Kitchen Unit Unit Number HLC Device Type Name...
Page 107 APPENDIX B – HLC PLANNER WORKSHEET ROOM 1: Unit Unit Number HLC Device Type Name Unit 1 Room Controller Unit 2 Lighting Load Room Controller Unit 3 Lighting Load Room Controller Unit 4 Lighting Load Room Controller Unit 5 Lighting Load Room Controller Unit 6 Lighting Load...
Page 108 APPENDIX B – HLC PLANNER WORKSHEET ROOM 5: Unit Unit Number HLC Device Type Name Unit 33 Room Controller Unit 34 Lighting Load Room Controller Unit 35 Lighting Load Room Controller Unit 36 Lighting Load Room Controller Unit 37 Lighting Load Room Controller Unit 38 Lighting Load...
Page 109: Appendix C - Text Description Character Codes
APPENDIX C - TEXT DESCRIPTION CHARACTER CODES CODE CHAR CODE CHAR CODE CHAR CODE CHAR SPACE " < & > ¥ × ¯ à ß Page 101...
Page 110: Appendix D - Voice Description Codes
APPENDIX D – VOICE DESCRIPTION CODES CODE DESCRIPTION CODE DESCRIPTION CODE DESCRIPTION (ADDRESS MSG) BOUDOIR DECREASE (BEEP) BOY'S DEGREES (MEMO MESSAGE) BREAK DELAYED (PAUSE) BREAKFAST (SHORT PAUSE) BRIGHTER DENIED A. M. BUILDING DESK ABOVE BURGLAR DETECTED AC POWER BUTTON DETECTOR ACCESS BYPASS DEVICE...
Page 111 CODE DESCRIPTION CODE DESCRIPTION CODE DESCRIPTION FILE HOUSE MECHANICAL FILTER HUMIDITY MEDICAL FIRE HUNDRED MEDICATION FIRST IMMEDIATELY MEETING FIVE MENU FLAG INCREASE MESSAGE FLOOD INFRARED METER FLOOR INPUT FLOW INSIDE MIDDLE FORCE INSTANT MIDNIGHT FORTY INTERIOR MINUS FOUNDATION INTERNET MINUTES FOUNTAIN INTRUSION MOBILE...
Page 112 CODE DESCRIPTION CODE DESCRIPTION CODE DESCRIPTION OVERHEAD SCHOOL TEEN P. M. SCREEN TELLER PANIC SECOND TEMPERATURE PANTRY SECONDS TEMPORARY PARKING SECURE PARLOR SECURITY TENANT PARTY SEND THANK YOU PATIO SENSOR THEATER PAUSE SEPTEMBER THEN SERVICE THERMOSTAT PERIMETER THIRD PERSONNEL SETTING THIRTEEN SEVEN THIRTY...
Page 113 CODE DESCRIPTION CODE DESCRIPTION WINE WORK WING YARD WINTER WOOD ZONE Page 105...
