Access Power Controllers
Installation Guide
Models Include:
Maximal3DV
- 12VDC @ 5A or 24VDC @ 5.4A.
- Sixteen (16) PTC protected outputs.
Maximal5DV
- 12VDC @ 9A.
- Sixteen (16) PTC protected outputs.
Maximal7DV
- 24VDC @ 9.4A.
- Sixteen (16) PTC protected outputs.
Rev. 061307
More than just power.
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Maximal3DV and is the answer not in the manual?

Questions and answers

Related Manuals for maximal Maximal3DV

Summary of Contents for maximal Maximal3DV

  • Page 1 Access Power Controllers Installation Guide Models Include: Maximal3DV - 12VDC @ 5A or 24VDC @ 5.4A. - Sixteen (16) PTC protected outputs. Maximal5DV - 12VDC @ 9A. - Sixteen (16) PTC protected outputs. Maximal7DV - 24VDC @ 9.4A. - Sixteen (16) PTC protected outputs.

  • Page 2: Table Of Contents

    Access Power Controller Typical Application Diagram (for each ACM8CB) . . . . . . . . . . . . . pg. 7 Maximal3DV and Maximal5DV Battery Hookup and Tamper Switch Installation . . . . . . . . pg. 8 Maximal7DV Battery Hookup and Tamper Switch Installation .

  • Page 3: Maximaldv Series Overview

    • Enclosure accommodates up to four (4) 12VDC/12AH batteries . Enclosure dimensions (H x W x D): 26” x 19” x 6 .25” (660 .4mm x 482 .6mm x 158 .8mm) . Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC) - 3 -...

  • Page 4: Maximaldv Installation Instructions

    FACP form “C” contacts can be use to trigger reporting or signaling devices . These contact switch upon a fire alarm input trigger to the ACM8CB boards . - 4 - Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC)

  • Page 5: Maintenance

    No DC output . Short circuit or thermal overload condition . No DC output . Loss of AC . Discharged battery . Red (Bat) Battery Status Normal operating condition . Battery fail/low battery . Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC) - 5 -...

  • Page 6: Access Power Controller Led Diagnostics

    L, G, N Connect 220VAC 50/60Hz to these terminals: L to hot, N to neutral . Maximal3DV - 12VDC @ 5A or 24VDC @ 5 .4A to ACM8CB boards . + DC – Maximal5DV - 12VDC @ 9A to ACM8CB boards .

  • Page 7: Power Supply Board Output Voltage Settings

    Door Holders Intact = One P/S Input Intact = DC Input Cut = Dual P/S Input Cut = AC Input J2 J1 NC C NO COM OUTPUT 8 Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC) - 7 -...

  • Page 8: Maximal3Dv And Maximal5Dv Battery Hookup And Tamper Switch Installation

    Fig. 3a Optional 12VDC Battery* Honeywell Model 112 Fig. 3b Tamper Switch Enclosure or equivalent Edge of (Not Included) Enclosure to Access Control Panel or U.L. Listed Reporting Device - 8 - Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC)

  • Page 9: Maximal7Dv Battery Hookup And Tamper Switch Installation

    **24VDC operation: Connect two (2) 12VDC batteries in series Fig. 4a Honeywell Model 112 Tamper Switch Enclosure or equivalent Edge of (Not Included) Enclosure to Access Control Panel or U.L. Listed Reporting Device Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC) - 9 -...

  • Page 10: Nec Power-Limited Wiring Requirements For Maximal3Dv

    Battery Connections (non power-limited) Fig. 5a Incorrect Wire Correct Wire Handling Handling External Jacketed Shield Wire Insulation Pull back Solid Copper external jacketed Conductors shield approx. 1/2”. - 10 - Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC)

  • Page 11: Nec Power-Limited Wiring Requirements For Maximal5Dv

    Battery Connections (non power-limited) Fig. 6a Incorrect Wire Correct Wire Handling Handling External Jacketed Shield Wire Insulation Pull back Solid Copper external jacketed Conductors shield approx. 1/2”. Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC) - 11 -...

  • Page 12: Nec Power-Limited Wiring Requirements For Maximal7Dv

    Fig. 7a Incorrect Wire Correct Wire Handling Handling External Jacketed Shield Battery Connections (non power-limited) Wire Insulation Pull back Solid Copper external jacketed Conductors shield approx. 1/2”. - 12 - Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC)

  • Page 13: Facp Hook-Up Diagrams

    Fig. 9 Normally Open - Non-Latching FACP trigger input: N.O. TRIGGER INPUT Fig. 10 Normally Open FACP Latching trigger input with reset: N.O. TRIGGER INPUT N.C. RESET SWITCH JUMPER Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC) - 13 -...
  • Page 14 Fig. 11 Normally Closed - Non-Latching FACP trigger input: N.C. DRY TRIGGER INPUT JUMPER Fig. 12 Normally Closed - Latching FACP trigger input with reset: N.C. RESET SWITCH N.C. TRIGGER JUMPER INPUT - 14 - Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC)
  • Page 15 Notes: Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC) - 15 -...

  • Page 16: Enclosure Dimensions

    140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www .altronix .com | e-mail: info@altronix .com | Lifetime Warranty | Made in U .S .A . MEMBER IIMaximal3DV/5DV/7DV Series G26R - 16 - Maximal3DV / Maximal5DV / Maximal7DV Access Power Controllers (PTC)
