Argo Moon Operating Instructions Manual

Ultrasonic humidifier
Hide thumbs

Advertisement

Quick Links

Download this manual
EN
ULTRASONIC HUMIDIFIER
MOON
OPERATING INSTRUCTIONS
Read the instructions carefully before operating the appliance or carrying out maintenance
operations. Observe all the safety instructions; failure to observe the instructions may lead to
accidents and/or damage. Keep these instructions in a safe place for future reference.
V 05/20
13

Advertisement

loading
Need help?

Need help?

Do you have a question about the Moon and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Argo Moon

Summary of Contents for Argo Moon

  • Page 1 ULTRASONIC HUMIDIFIER MOON OPERATING INSTRUCTIONS Read the instructions carefully before operating the appliance or carrying out maintenance operations. Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or damage. Keep these instructions in a safe place for future reference.
  • Page 2 GENERAL OPERATING AND SAFETY INSTRUCTIONS  The appliance is a highly effective humidifier: only use this humidifier as described in this manual. Any other use not recommended by the manufacturer may cause fire, electric shock or malfunctions.  Ensure that the mains voltage complies with that indicated on the data plate (220-240V/50-60 Hz).
  • Page 3 humidity or “white dust” contained in the mist may cause the appliances to malfunction.  In the event of an anomaly (like burning smell or abnormal noise), switch the appliance off and unplug it immediately. Do not dismantle, repair or modify this product freely. In the event of a malfunction, contact the after-sales service centre directly.
  • Page 4  Do not place the appliance close to furniture or curtains. The mist may wet the furniture or curtains causing them to fade or deform. Also, the white powder contained in the steam could alter the furniture's surface: therefore you should avoid directing the steam jet directly towards furniture.
  • Page 5  During winter season, the water in the tank may freeze and cause the appliance malfunction. Remove the water from the tank.  Carry out maintenance on the appliance by regularly and thoroughly cleaning the tank and nebuliser. Continuous operation of the appliance with dirt residues may lead to faults and malfunctions.

  • Page 6: Description Of Parts

    DESCRIPTION OF PARTS 1. Mist outlet cover 9. Fragrance sponge 17. Supporter 2. Mist outlet 10. Filter box+ sponge 18. Water tank light 3. Water level 11. Top cover 19. Light ring 4. Mist reinforcement 12. Water tank 20. Bottom cover 5.

  • Page 7: How To Use The Appliance

    HOW TO USE THE APPLIANCE Position the appliance on a flat, stable surface. Take off the mist outlet cover and put is aside; add water directly into the water tank and then place back the water tank. When placing the water tank, be sure to steadily hold it and align it well (water level should be lower than the highest water level), then put back the mist outlet cover.
  • Page 8 USE OF CENTRAL BUTTON Below, some indications for the correct use of the central button. Operation Status Plug the power adapter Light LED turns to red, start atomization. Short-press the button Switch the mode in the following order: Intelligent, Level 1, Level 2, Level 3, atomization Short-press the button for 2 seconds Under working status, long-press the button to turn on/off the...
  • Page 9 CLEANING AND MAINTENANCE MAINTENANCE OF THE HUMIDIFIER’S EXTERIOR SURFACE Warning Always unplug the appliance before cleaning it, otherwise electric shocks and malfunctions may occur. Use a damp and soft cloth to clean the humidifier’s exterior surface. Warning Do not wet the appliance or immerse it in water, otherwise electric shocks may occur. Do not use solvents, petrol, xylene, talcum powder or brushes to clean the unit: these may damage the surface or colour of the casing CLEANING OF ATOMIZER...

  • Page 10: Cleaning Of Filter

    Warning Do not use metal brushes, metal blades, abrasive brushes or talcum powder to clean the nebuliser surface. These products may deform the nebuliser or cause abrasions, thereby leading to reduced mist emission and other malfunctions. Warning Avoid heavy knocks to the water tank as this may cause water leakages. Interrupt humidifier operation immediately in the event of leakages and contact the technical assistance service directly.
  • Page 11 POTENTIAL FAULTS AND SOLUTIONS If the humidifier has some operating anomalies, consult the table below to resolve any anomalies. If they persist, contact an authorized service center for the repair of the appliance. PROBLEM POTENTIAL CAUSE SOLUTION The plug is not connected properly Connect the plug The humidifier is not working Low water level in the water channel...
  • Page 12 INFORMATION ON THE CORRECT DISPOSAL OF THE PRODUCT, PURSUANT DIRECTIVE 2012/19/EU ON WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT" At the end of its useful life, this appliance must not be disposed of together with household waste. We call your attention to the crucial role played by the consumer in the reuse, recycling and other forms of recovery of such waste.
