Technical Data; Icons - Trumpf TruTool TPC 165 Operator's Manual

Voltage
Frequency
Working speed
Nominal power consumption
Idle stroke rate n
0
Cutting track width
Weight
Safety class

Technical data

Icon Name
Read operator's manual
Wear safety glasses.
E848EN_00
2.2 Technical data
Other countries
Values
230 V 120 V
50/60 Hz 50/60 Hz
4 m/min 4 m/min
1400 W 1400 W
2300/min 2300/min
4 mm 4 mm
9.6 kg 9.6 kg
II / II /
Individual material thickness for
steel up to 400 N/mm
2
With insulation made of polyur-
ethane foam (PUR) and polyisocya-
nurate foam (PIR)
Permissible material thicknesses
Blade 165
Minimum cutouts
2.3

Icons

Note
The following symbols are important for reading and understand-
ing the operator's manual. The correct interpretation of the sym-
bols will help you operate the machine better and safer.
Meaning
Read the operator's manual and safety information in
their entirety before starting up the machine. Closely
follow the instructions given.
Chips could fly out of the tool.
USA
110 V 120 V
50/60 Hz 50/60 Hz
4 m/min 9.8 ft/min
1400 W 1400 W
2300/min 2300/min
4 mm 4 mm
9.6 kg 21.2 lbs
II / II /
Other countries USA
Permissible material thicknesses
0.9 mm 0.9 mm
(0.035 in)
165 mm 165 mm (6.4 in)
Other countries USA
Minimum cutouts
340 x 340 mm 340 x 340 mm
(13.5 x 13.5 in)
Technical data
Tab. 1
Tab. 2
Tab. 3
9
