Titan CONNECTED X User Manual

Smart watch activity tracker
Hide thumbs

Advertisement

Table of Contents

SMART WATCH ACTIVITY TRACKER
U s e r M a n u a l

Advertisement

Table of Contents
loading

Related Manuals for Titan CONNECTED X

Summary of Contents for Titan CONNECTED X

  • Page 1 SMART WATCH ACTIVITY TRACKER U s e r M a n u a l...
  • Page 2 Catalogue ��������������� 01 1 Packing List �������������� 02 2 Product Detials ������������ 03 3 Working Condition ������������� 04 4 Waterproof Level �������������� 05 5 Watch Battery ����������� 06 6 Charging Instructions ��������������� 08 7 Wear Watch ��������������� 09 8 Install APP ���������������...
  • Page 3 �������������� 30 （3） Music Control ������������� 31 （4） Remote Camera ��������� 31 （5） Search for the Mobile Phone ������������� 32 （6） Setting Interface 15 Menu Three ������������ 35 （1） Remind Interface ������������ 36 （2） Stopwatch Interface ������������ 37 （3） Countdown Interface �������������...

  • Page 4: Packing List

    １. Packing List A： Smart watch B： User manual C： Charging dock D： Charging cable...

  • Page 5: Product Details

    2. Product Details Touch Screen Up Key Physical Down Key Watch Hands Heat Rate Lenses Charging Charger Port Contact Surface Charge Lamp...

  • Page 6: Working Condition

    3. Working Condition Working temperature -10°C~55°C Working humidity 0~100%...
  • Page 7 4. Waterproof Level The watch can withstand the pressure equivalent to 30 meters water depth, suitable for daily use, is not recommended to wear when swimming in the pool or shallows, can not be used for diving, does not support bathing and sauna.
  • Page 8 5. Watch Battery （1） The smart part can be used for about 3 days when the watch is fully charged. （2） If the watch shows low battery power, the smart part function will be automatically turned off, but the watch hands can continue to operate normally for about 30 days.

  • Page 9: Charging Instructions

    6. Charging Instructions （1） Connect the USB cable to the USB power adapter. （2） Connect the other end of the USB cable to the charging dock. （3） Plug the USB power adapter into a power outlet. （4） Press the back of the watch into the charging cradle to charge the watch.
  • Page 10 3） If there is an obstacle between the watch and the charging dock, the watch may not charge properly. 4） When the battery is low, please charge it in time. After the watch is charged, please disconnect the charging power. 5）...
  • Page 11 7. Wearing the Watch (1) Wear the watch on your wrist, just behind the wrist bone and fasten it well using the buckle. (2) The watch must be comfortably tight on your wrist such that there is no gap between the watch and your wrist. This is important so that the Heart Rate sensor, which is at the back of the watch, is always in contact with your skin.

  • Page 12: Installing The Mobile App

    8. Installing the mobile APP Apple App Store (iOS users) Use the Search tab to look for “Titan Connected X” App. Download the App and let it install. The Titan Connected X App supports iOS 9.0 and above Google Play Store (Android users) Use the Search tab to look for “Titan Connected X”...
  • Page 13 9. Pairing the Watch (1) Turn on your phone's Bluetooth and open the APP on your phone. Note： 1) If you are a new user, you need to create a new account. 2) If you have registered an account, log in using the APP with your email address and password.

  • Page 14: Time Calibration

    10. Time Calibration ((1) After the watch is successfully paired to the App, follow the instructions on the App to scan the watch for time calibration (2) Ensure that the watch fits into the outline that is shown on the app screen and your camera is pointing exactly on your watch (3) When the time calibration is complete, click the "Home"...

  • Page 15: Touch Screen Operation

    (1) Touch screen operation Click Double click Long press Swipe left Swipe right Swipe up Swipe down (2) Key describtion Up key： Turn on the screen; return to the home page; turn on the standby mode; long press for 5 seconds to turn on/off...
  • Page 16 Note: 1) If you restart the watch, the activity data will not be deleted. 2) By default, if the watch is operated without any human on any interface, the screen will be darkrn after 5 seconds and will be automatically turned off after 10 seconds. You can change this setting from the settings option in the app.
  • Page 17 Click the menu icon to enter the icon function. Partly Cloudy 20° Double click on any interface to return to the previous layer. Long press the watch face, swipe left or right to select the replacement watch face.
  • Page 18 Swipe left to access the menu one. Swipe right to access menu three. Swipe up to access the shortcut menu. Swipe down to access the message center. (The watch pointer turns to show 9:15)

  • Page 19: Shortcut Menu

    12. Shortcut Menu Partly Cloudy 20° (1) Flight mode When the icon is , the flight mode is off and Bluetooth is not connected; when the icon is , the flight mode is on; when the icon is , the flight mode is off and Bluetooth is connected.
  • Page 20 13. Menu One (1) Heart rate interface 5 min ago 1) Swipe to the menu one on the watch, click the icon on the screen, and then click the screen to start the heart rate monitoring. The green light appears on the back of the watch and the heart rate begins to be measured.
  • Page 21 2） If you want to monitor your heart rate all the time, please turn on “Auto track” in “Heart Rate” in “Settings” on APP to set your desired heart rate monitoring “Frequency” . Heart Rate Auto track Frequency 5 min HR range alert Cancel...
  • Page 22 Heart rate is too high Heart rate is too low 3) You can also set "Low HR limit" and "Hight HR limit" in the "HR range alert" in the APP. 4) If heart rate monitoring fails, try again after 3 seconds. Note: Turning on heart rate monitoring will consume a lot of power.
  • Page 23 (2) Weather Interface 1) Swipe to the menu one on the watch, click the icon on the screen to see the weather conditions of the day, slide up to see the weather forecast for the next 3 days. 2) You can also click on “Device settings” in the “Settings” on the APP, click “Weather”...
  • Page 24 Weather Paris Paris，France Paris, TX， United States Paris, TN， United States Paris, KY， United States Activity Reminder Settings...

  • Page 25: Activity Data

    (3) Activity Data Steps Distance Calories Activity Time 1) Swipe to the menu one on the watch and click the icon on the screen to see the number of walking steps, movement distance, calories burned, and activity time. 2) You can also sync exercise data on the APP main interface, view your historical exercise data, and click on each activity to see daily, weekly, or monthly details.
  • Page 26 Isiah Thomas Netherlands STEPS January 12th 2018 Today Week Month Complete Steps Steps Heart rate steps Distance Calories kcal Active time Sleep hours Activity Reminder Settings Activity Reminder Settings Main interface Daily time interface STEPS STEPS January 12th 2018 January 12th 2018 Today Week Month...

  • Page 27: Missed Calls

    (4) Missed Calls Jennifer 13:00 28/06 Nick 12:30 Lucas 12:00 1) Swipe to the menu one on the watch and click the icon on the screen to view missed call information. 2) You can also scroll down the watch main time screen to the message center to view missed call information.
  • Page 28 (5) MSM Interface 09:20 28/06 Let’s have coffer today ok? I’m av... I’m on the b... 09:00 Hi, Jack ! ... 08:00 1) Swipe to the menu one on the watch, click the icon on the screen to read the content of the message. 2) Long press the screen to delete all SMS messages.
  • Page 29 (6) Social Notification 08:20 28/06 Hi, Lucas, come to the coffee sho... I’m on the b... 08:00 Hi, Jack ! ... 08:30 1) Swipe to the menu one on the watch and click the icon on the screen to see the content of the message. 2) Long press the screen to delete all notification information.
  • Page 30 14. Menu Two (1) Alarm Clock Interface 07:00 06:15 06:55 06:45 1) Click "Wake up" on the APP reminder interface to set the alarm time and type of alarm. 2) Swipe to the menu two on the watch. Click the icon on the screen to switch the alarm.
  • Page 31 9:41 AM 58 % Reminder Meeting Wakeup Sleep Medicine Drink Sport Bills Customize Activity Reminder Settings (2) Sleep Interface Last Night...
  • Page 32 1) Swipe on the watch to the menu two and click the icon on the screen to check the last sleep time. 2) Swipe up the screen . Click the icon to start recording sleep. Click again to end sleep monitoring. 3) You can also click on “Device settings”...

  • Page 33: Music Control

    (3) Music Control Almost Lover(A... 1) Open the phone default music player APP. Note: Android phones use Google Play Music Player and Apple Mobile Phone use Apple Music Player. 2) Swipe to the menu two on the watch, and click the icon on the screen to control music play/pause, previous/next and volume adjustment.
  • Page 34 (4) Remote Camera 1) Open APP and click "Camera" in "Device settings" in "Settings". 2) Swipe on the watch to the menu two, click the icon on the screen, and click the screen to take a photo. (5) Search for the Mobile Phone 1) Swipe to the menu two on the watch, click the v icon on the screen and after the screen is clicked, the phone will...

  • Page 35: Setting Interface

    (6) Setting Interface Sounds Display Advanced settings Sounds settings 1) Swipe to the menu two on the watch, click the v icon on the screen, click "Sounds", click "Vibration" to turn it on or off; 2) Click"Sounds" to turn it on or off, 3) Click "Do not disturb mode"...

  • Page 36: Advanced Settings

    Advanced settings 1) Swipe to the menu two on the watch, click the icon on the screen, click "Advanced settings", click "Watch face", slide the screen left or right to change the watch face. You can also click on the APP "Settings" in the "Device settings", click "Watch face"...
  • Page 37 2) Click “Calibration” to manually calibrate the time; 3) click “Language” to set the watch language; 4) swipe up to click “Left mode” to turn it on or off; 5) Click “Device info” to view the watch's information; 6) click “Reset” to clear the watch's data. This will erase all data from your smart watch...
  • Page 38 15. Menu Three (1) Reminder Interface 12:30 Meeting 12:30 Sport 12:30 1) Swipe to the menu three on the watch, click the icon on the screen to view the reminders that have been set on the APP (except the alarm clock).
  • Page 39 (2) Stopwatch Interface 00:00,0 1) Swipe to the menu three on the watch, click the icon on the screen, click the green button to start timing, click again to pause, and click the yellow button to reset. (3) Countdown Interface 1:00:00 1) Swipe up to themenu three on the watch, click the icon on the screen, click on the time to set the time.
  • Page 40 (4) Schedule Interface 09:20 28/06 Marketing weekily meet ing conf r... Meeting in ro... 09:00 Room bow... 08:00 1) Sliding to the menu three on the watch, click the icon on the screen to view the events and time set on the mobile calendar.
  • Page 41 16. Clean Watch (1) It is recommended that you wipe the watch band in time after exercise or after a long period of use. The accumulation of sweat and other dirt under the watch band can cause skin irritation. (2) Use water or alcohol to wipe the watch. Do not use soap, detergent, household cleaners, or abrasive cleaners to clean the watchband.

  • Page 42: Troubleshooting

    17. Troubleshooting (1) Unable to Pair the Watch with the App 1) Ensure that the mobile phone network, phone’ s bluetooth and Location are available and turned on.. 2) Ensure that the watch and the phone are in close proximity (within the connectivity range of 10 meters or less).
  • Page 43 18. Precautions (1) Please check local laws and regulations to determine the correct way to handle batteries and electronic devices in your area. (2) If there is no local regulation on the disposal of e-waste, please place your product and its battery in a trash can for electronic equipment.

  • Page 44: Fcc Statement

    19. FCC Statement This device complies with Part 15 of the FCC Rules. The operation is subject to the following two conditions: (1) This device will not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Failure to explicitly change or modify the approval of the party responsible for compliance may void the user's...
  • Page 45 This equipment generates and may radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, it can be determined by turning the equipment off...
