Summary of Contents for Maytel MC-11
- Page 1 MC-11 USER MANUAL...
-
Page 2: Table Of Contents
Title MC-11 Intercom User Manual Version V1.0 Release 2015.10. CONTENTS 1. MC-11 INTERCOM FEATURES ..................3 1.1. B ..........................4 UTTONS 1.2. V ........................4 OLUME ONTROL 1.3. G ........................4 ROUP SETTING 1.4. ID S ..........................5 ETTING 1.5. TALK F ........................ -
Page 3: Intercom Features
Title MC-11 Intercom user Manual Version V1.0 Release 2015.10. 1. MC-11 intercom Features Antenna MODE Mode Button Talk Button UP Button Power Button Down Button Headset Jack USB Jack AUX Jack... -
Page 4: Buttons
Down VOL: To set volume level lower 1.2. Volume Control MC-11 intercom has volume control function that serves user to change volume level wanted. How to set VOL is displayed right after power is turned on. The default mode is volume control ... -
Page 5: Id Setting
1.5. TALK Function MC-11 intercom serves TALK function to let users start to talk with others. In case of Master, the default talk mode in ON, and in case of Slaves the default talk mode is in inactive state. Therefore Master can start to talk after power is turned on, Slaves are required to press Mode button then Talk function is activated. - Page 6 Title MC-11 Intercom User Manual Version V1.0 Release 2015.10. persons can keep talking.
-
Page 7: Specifications
Title MC-11 Intercom user Manual Version V1.0 Release 2015.10. 1.6. SPECIFICATIONS ITEM SPECIFICATION Radio Frequency Type ISM 903MHz ~ 926.5MHz Type Wireless Intercom Unit Radio Interface ISM 2.4GHz: GFSK Modulation with Frequency Hopping Voice Codec 16bit/8KHz Rx Sensitivity -95dBm Voice Latency <... - Page 8 MC-11 Channel Table Frequency range : 903MHz ~926.5MHz Channel Frequency Channel Frequency Channel Frequency 903.5 913.5 923.5 904.5 914.5 924.5 905.5 915.5 925.5 906.5 916.5 926.5 907.5 917.5 908.5 918.5 909.5 919.5 910.5 920.5 911.5 921.5 912.5 922.5...
- Page 9 FCC Information to User This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 10 European CE notice to users and product statements This product is CE marked according to the provisions of the R&TTE Directive(99/5/EC). Hereby, Maytel Co., Ltd declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
- Page 11 Manufacturer Address : 417 Doosan Venture Digm 126-1, Pyeongchon-dong, Dongan-gu, Anyang-si, 431-070, South Korea To locate in-country Maytel Co., Ltd, distributors of the Multicom please refer to the Maytel Co., Ltd Website http://swmaytel@naver.com These distributor(s) represent local contacts for this product.
- Page 12 Maytel Co., Ltd 417 Doosan Venture Digm 126-1, Pyeongchon-dong, Dongan-gu, Anyang-si, 431-070, South Korea declare under our sole responsibility that the product(s) Multicom – MC-11 to which this declaration relate(s) is in conformance with the following standards: EN 301 489-1 V1.9.2:2011 EN 301 489-17 V2.2.1:2012...
