Basic Connection - N-audio 12 CHANNEL PROGRAMMABLE LOOPER User Manual

2. Basic connection:

- Plug the guitar into one of the two inputs. If you are using high-quality cables and you don't want any
additional devices in the way of the signal, use the passive input. Note that, because of the cable's
specific capacity, you might experience loss of high frequencies in your sound. In this case, you can use
the buffered input. It is your choice. Experiment and decide which of the two inputs you find better.
- Plug the tuner into the Tuner input jack.
- Connect effects in the corresponding inputs.
- Connect your amp's input to the To Amp jack.
INPUT
Buffered
Passive
TUNER
In
1
Input
To Amp
Out
Effect
Tuner
