Assembly Instructions
& User's Manual
Tabletop Patio Heater
Item #FSMVPT5002
Model #SRPT03
Please keep this instruction manual for future reference
Warning:
READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE OR
OPERATE THIS PRODUCT.
Adult assembly required.
Keep screws and parts out of reach of children.
Customer Service: (866) 814-0585, 8:00am to 8:00pm,
Monday thru Friday Eastern Standard Time
--------------------------------------OR-------------------------------------
(888) 922-2336, 7:00 am to 12:00 am Everyday CST
LiveChat@Academy.com: 24/7
(Made in China)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mosaic SRPT03
Summary of Contents for Mosaic SRPT03
- Page 1 Assembly Instructions & User's Manual Tabletop Patio Heater Item #FSMVPT5002 Model #SRPT03 Please keep this instruction manual for future reference Warning: READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE OR OPERATE THIS PRODUCT. Adult assembly required. Keep screws and parts out of reach of children.
-
Page 2: Warnings And Cautions
WARNINGS AND CAUTIONS Read the instructions before use. This appliance must be installed in accordance with such regulations as are enforced. Standard: ANSI Z83.26-2014 / CSA 2.37-2014 Gas-Fired Outdoor Infrared Patio Heater CAUTION WARNING Installer: Leave the manual with the For Outdoor Use Only user for future use. -
Page 3: Table Of Contents
TABLE OF CONTENTS Warnings and Cautions................1 Table Of Contents ..................2 Tools and Parts..................6 Hardware....................8 Assembly Instructions................9 Safety Check..................13 Operation....................14 Lightin g Operation................15 Operation....................16 Heater Placement ................17 Maintenance and Storage..............18 Trouble Shooting.................. 20 Warranty Information................21 REMINDER BEFORE ASSEMBLY Verify that all parts are included with your heater BEFORE you begin assembly by checking the Parts and Hardware List. - Page 4 WARNINGS AND CAUTIONS NOTE:PLEASE READ THE FOLLOWING SAFETY RULES WARNING: Any guard or other protective device The installation must conform with local codes or, in the absence of local codes, with the removed for servicing the heater must be National Fuel Gas Code, ANSI Z223.1/NFPA 54, replaced prior to operating the heater.
- Page 5 WARNINGS AND CAUTIONS NOTE:PLEASE READ THE FOLLOWING SAFETY RULES WARNING: ithin a partial enclosure which includes an Do not store a spare LP-gas cylinder under or near this appliance; overhead cover and three side walls, as long as 30 percent or more of the horizontal Never fill the cylinder beyond 80 percent full;...
- Page 6 WARNINGS AND CAUTIONS Before beginning assembly of product, make sure all parts are present. If any part is missing or damaged, do not attempt to assemble the product. Contact customer service for replacement parts. SPECIFICATION Certification Rated Heat Input 10000BTU/hr Fuel Gas Supply 16.4oz LP-Gas cylinder...
-
Page 7: Tools And Parts
TOOLS AND PARTS Please check the contents of the packaging to ensure all parts are included. If missing parts please contact customer service. Page 6 of 21... - Page 8 TOOLS AND PARTS Description Picture Quantity Part Reflector Dome Emitter Screen Emitter Screen Shield Burner Column (pre-assembled) Control Knob Door (pre-assembled) Fixed Panel Base Weight Block TOOLS REQUIRED (Not included): Adjustable open end wrench Phillips Screwdriver Page 7 of 21...
-
Page 9: Hardware
HARDWARE Please check the contents of the packaging to ensure all parts are included. If missing parts please contact customer service. Part Description Quantity Picture M6 x 10 Bolt M4 x 10 Bolt M4 x 8 Bolt 6mm Washer M6x 14 Bolt NOTE: Before beginning assembly of product, make sure all parts are present. -
Page 10: Assembly Instructions
ASSEMBLY INSTRUCTIONS Choose a soft and level location for assembly. Remove all parts from the packaging, and check for missing parts. If missing parts please contact customer service. Step 1 Step 1 Attach door (F) and fixed panel (G) to base (H) with (7) M4 x 8 bolts (CC). - Page 11 ASSEMBLY INSTRUCTIONS Choose a soft and level location for assembly. Remove all parts from the packaging, and check for missing parts. If missing parts please contact customer service. Step 3 Step 3 Attach the burner column (D) to the fixed panel (G) with (3) M4 x 8 bolts (CC).
- Page 12 ASSEMBLY INSTRUCTIONS Choose a soft and level location for assembly. Remove all parts from the packaging, and check for missing parts. If missing parts please contact customer service. Step 5 Step 5 Attach reflector dome (A) to emitter screen (B) with (3) M6 x 10 bolts (AA).
- Page 13 ASSEMBLY INSTRUCTIONS Choose a soft and level location for assembly. Remove all parts from the packaging, and check for missing parts. If missing parts please contact customer service. Step 7 Step 7 Align the nozzle of the LP cylinder (not included) with the regulator and turn counter clockwise to tighten.
-
Page 14: Safety Check
SAFETY CHECK Check for leak Your patio heater connections have been checked for leakage. To check the connections at the tube/regulator/cylinder. 1) Make leakage solution by mixing 1 part liquid dish soap and 3 parts water. 2) Spoon several drops (or use squirt bottle) of the solution onto the tube/regulator/cylinder connections. -
Page 15: Operation
OPERATION This product is equipped with ODS (Oxygen Deprivation System) WARNING: DO NOT ATTEMPT TO OPERATE HEATER UNTIL YOU HAVE READ AND UNDERSTAND ALL PRECAUTION . FAILURE TO DO SO CAN RESULT IN SERIOUS PERSONAL INJURY, DEATH, OR PROPERTY DAMAGE. Before turning gas supply ON Before Lighting Your heater was designed and approved for... -
Page 16: Lightin G Operation
OPERATION Lighting instructions WARNING 1. Turn the control knob to "OFF" position. FOR YOUR SAFETY: 2. Open base assembly door. If at any time you are unable to 3. Turn counter-clockwise to connect cylinder with regulator light burner and smell gas, wait 5 inlet. -
Page 17: Operation
OPERATION CAUTION: AVOID INHALING FUMES EMITTED FROM THE HEATER’S FIRST USE. SMOKE AND ODOR FROM THE BURNING OF OILS USED IN MANUFACTURING WILL APPEAR. BOTH SMOKE AND ODOR WILL DISSIPATE AFTER APPROXIMATELY 30 MINUTES. THE HEATER SHOULD NOT PRODUCE THICK BLACK SMOKE. NOTE: The burner may be noisy when initially turned on. -
Page 18: Heater Placement
HEATER PLACEMENT CAUTION: WHEN CERTAIN MATERIALS OR ITEMS ARE LEFT, ABOVE, BESIDE OR UNDER THIS HEATER WHILE IN USE, THEY WILL BE SUBJECT TO RADIANT HEAT AND COULD BE SERIOUSLY DAMAGED. This heater is primarily used for the heating of CEILING/OVERHANG outdoor patios, decks, spas, pools and open working areas. -
Page 19: Maintenance And Storage
MAINTENANCE AND STORAGE CLEANING AND MAINTENANCE : To enjoy years of outstanding performance from your heater make sure you perform the following maintenance Yellow Tip activities on a regular basis: Primarily Blue Flame Keep exterior surfaces clean. Use warm soapy water for cleaning. Never use flammable or corrosive cleaning agents. - Page 20 MAINTENANCE AND STORAGE STORAGE: Between uses: Turn the control knob to "OFF" position. Turn clockwise to disconnect cylinder from regulator. Store heater upright in an area sheltered from direct contact with inclement weather (such as rain, sleet, hail, snow, dust and debris). NOTE: Wait until heater is cool before If desired, cover heater to protect exterior surfaces and...
-
Page 21: Trouble Shooting
TROUBLE SHOOTING Replace tank Replace tank or 1 (888) 922-2336. Page 20 of 21... -
Page 22: Warranty Information
WARRANTY INFORMATION The appliance has been manufactured under the highest standards of quality and workmanship. We warrant to the original consumer purchaser that all aspects of this product will be free of defects in material and workmanship for one (1) year from the date of purchase. A replacement for any defective part will be supplied free of charge for installation by the consumer.
